MANUAL FOCUS

Use manual focus to focus on a specific area of the image or to reduce the appearance of grain in grainy film (such as
high-speed or pushed film) by slightly defocusing it.
1. Press the Manual Focus button in the
Prescan window.
• The pointer will change to the Manual Focus icon.
• Click on the Manual Focus button again to escape
the function.
2. Click on the area of the image to be in
sharp focus.
• The Focus Control dialog box will appear.
3. Adjust the slider until the black and gray
lines are at their longest for maximum
focus.
• Click and drag the slider to the left and right. Click
on the slider arrow to make a small change. Click
on the slider bar to make a larger change.
• To slightly defocus, adjust the sliders until the black
bar is a little shorter than the gray bar.
4. Click on OK.
• A new prescan will begin.
• The prescanned image will appear in the Prescan
window when complete.
29
