COLOR BALANCE ADJUSTMENT – INDIVIDUAL CHANNELS
Changing the slider positions for individual channels affects the color balance of the image.
1. Make sure RGB Synchro is off.
2. Click on and move the R, G, and B
sliders to the desired locations.
• Changes are automatically applied to the Preview
image.
• Click on
to view a full-screen display of the
Control and Preview images.
3. Click on
and hold to view the output
level histograms.
APPLYING OR CANCELLING CORRECTIONS
Click on
to apply the changes.
Click on
to close the dialog box without making changes.
Click on
to cancel the changes without closing the dialog box.
37
