Variations; Opening The Variations Dialog Box - Minolta Dimage Scan Multi Instruction Manual

OPENING THE VARIATIONS DIALOG BOX

Open the Variations dialog box by clicking
on in the Prescan window.
• The Variations dialog box will appear.
VARIATIONS DIALOG BOX – NAMES OF PARTS
Grayscale
Represents changes in brightness, contrast,
and color.
R, G, and B sliders
Use to make color changes.
Control image
Shows the unchanged prescan.
Full Screen Display button
Displays the Control and Preview images so
they fill the monitor screen. The Control will be
at the top or the left, while the Preview will be
at the bottom or right.
Help button
Click on the help button to launch the help file.
• Only the area inside the cropping frame appears in the variations dialog box.

VARIATIONS

Contrast slider
Brightness slider
Preview image
Shows the prescan with the changes.
Reset button
Cancels the changes without closing the Variations
dialog box.
Cancel button
Closes the Variations dialog box without making
changes.
OK button
Applies the changes and closes the Variations dialog
box.
31
