4.15. Generator Replacement - Matrix A30 Service Manual

4.15. Generator Replacement:

1. Remove FRONT COVER (see section 4.10)
2. Remove SIDE COVER (see section 4.11)
3. Remove PEDAL ARM (see
4. Remove CRANK (see section
5. Remove screws fixing the generator base (Fig1)
6. Disconnect the generator cable (Fig2)
7. Reserve step 6-1 to replace a new generator.
Note : The generator body is a whole unit, do not try to disassemble further.
CHAPTER 4: Part Re
section 4.8)
4.9)
Fig1
lacement Guide
Fig2
41
