SES-X-FA8LTT01 AUDIO FIBER EXTENDER

Set Up Instructions

1. Secure the units in a safe location, where they will not be subject to impact and where there is room around the
unit so nothing will interfere with the fiber optic cabling causing it to bend sharply in a tight radius in any way that
can severely affect the signal transfer.
2. Use proper cable management and handling for routing fiber optic cable.
3. Carefully connect your source(s) to the transmitter input(s) and the receiver unit output(s) to your receiving device
input(s) using the XLR connectors on the transmitter and on the receiver unit.
4. CLEAN* the ST fiber optical cable contacts that will be used for connecting the Tx and Rx units and attach the fiber
cable to the ST connections and secure, as you would secure a bayonet BNC. While pressing lightly in on the
connector, twist it in a clockwise direction about 1/8 to 1/4 of a turn and then release. The connector should stay
inserted and have backwards spring pressure holding the bayonet in place.
5. Connect the included power supplies to the transmitter and receiver units, and plug them both into an AC power
source (100-240VAC 50/60Hz).
* CLEAN: All fiber optical cable contacts require cleaning each time before inserting into a device's outputs or
inputs. Failure to clean the contacts can damage the unit's optics over time and can also permanently damage
the cable and the device.
Use cleaning kits designed specifically for fiber optics.

SPECIFICATIONS

Total Harmonic Distortion
Signal to Noise Ratio
Maximum Balanced Input Signal
Max Line Input/Output Voltage
Optical Wavelength
Frequency Response
Sample Rate
Input Power
Unit Dimensions Each Unit
Power Consumption
Unity Gain 0dB
<0.05%
> 90dB Ref. 4dBu, A Weighting
18dBu
17.4Vp-p
1310nm
20Hz—20KHz
48KHz, 24K bit rate
12VDC
6.25 x 6.25 x 1.25 inch with flanges/plugs
<1W
Includes (2) 12VDC/2A Power Adapters
