Page 1: User Manual
USER MANUAL SES-X-FA2 2-Channel Mic & Line Level Audio over Single Fiber Extender Power: AC Adapters or Battery Operated... - Page 2 SES-X-FA2 AUDIO OVER SINGLE FIBER EXTENDER The SES-X-FA2 battery-operated audio over fiber extender sends 2 channel, balanced mic or line level audio signals up to 12.4 miles over a single mode fiber cable. The transmitter and the receiver each feature two balanced XLR inputs and two XLR outputs, and a simplex ST connector.
- Page 3 SES-X-FA2 AUDIO OVER SINGLE FIBER EXTENDER TRANSMITTER DC Power Jack 3 Position Rocker Switch Power LED Indicator Audio Input Left Audio Input Right Left Channel Mic/Line Switch Right Channel Mic/Line Switch ST Fiber I/O 9V Battery Cover RECEIVER DC Power Jack...
- Page 4 SES-X-FA2 AUDIO OVER SINGLE FIBER EXTENDER Set Up Instructions 1. Secure the units in a safe location, where they will not be subject to impact and where there is room around the unit so nothing will interfere with the fiber optic cabling causing it to bend sharply in a tight radius in any way that can severely affect the signal transfer.
- Page 5 10. There are no user-serviceable parts inside the unit. If the unit requires service contact your au- thorized dealer, or an authorized repair service company. SESCOM SES-X-FA2 User Manual Ver 1a Page 5 ...
- Page 6 SESCOM PO Box 720 • Mt. Marion, NY 12456 • USA 845.246.1915 • sales@sescom.com www.sescom.com ...
