Introduction

The CC2420 is a true single-chip 2.4 GHz IEEE 802.15.4 compliant RF transceiver designed
for low-power and low-voltage wireless applications. The CC2420DK development kit is a
powerful and flexible tool specifically designed to make it easy for the user to evaluate the RF
performance of the CC2420 and to minimize the time spent on evaluation.
The Development Kit includes two CC2400EB Evaluation Boards and two CC2420EM
Evaluation Modules. The Evaluation Modules contain the CC2420 chip and required external
components.
The Evaluation Board serves as a motherboard for the Evaluation Modules. The Evaluation
Board provides a USB port, a serial port, buttons, LEDs, voltage regulator, configuration
jumpers and connectors to make it easy to interface the CC2420 with the SmartRF
software and various test equipment. The CC2400EB Evaluation Board is the same as for the
CC2400DK.
This User Manual describes how to use the Development Kit. SmartRF
documented in its own user manual.
®
Your SmartRF CC2420DK Development Kit should contain the following items:
Item
Evaluation Board (CC2400EB)
Evaluation Module (CC2420EM)
Quick Start instructions
Antenna, 50Ω quarter-wave monopole, SMA male connector
SMA to BNC adapters
USB cable
CC2420 sample kit
Kit contents
SWRU045
®
Studio
®
Studio is
Number of articles
2
2
1
2
4
2
1
Page 3 of 32
