Texas Instruments Chipcon CC2420DK User Manual page 25

Reference Description
C104 Capacitor 0603
C105 Capacitor 0603
C106 Capacitor 1206
D1 Schottky diode, 2A
D2 LED, green, SMD
D3 LED, red, SMD
D4 LED, yellow, SMD
D5 LED, blue, SMD
H1 Circuit board support
H2 Circuit board support
H3 Circuit board support
H4 Circuit board support
P1 D-SUB, 9 pin, female
P2 5-pin terminal, screw
P3 5-pin terminal, screw
P4 DC jack, 2.5mm center
pin
P5 Pin row connector,
2x10
P6 SMA connector
P7 SMA connector
P8 SMA connector
P9 SMA connector
P10 Pin row connector, 2x5
P11 Pin row connector, 2x5
P12 Pin row connector, 2x5
P13 SMD pinrow header
P14 SMD pinrow header
P15 USB B-type connector
P16 Low-profile pin row
connector, 1x6
P17 Pin row connector,
2x10
P18 Low-profile pin row
connector, 1x6
Bill of materials, CC2400EB Evaluation Board
Value
100 nF, 10%
33 nF, 10%
2.2 µF, 10%
SWRU045
Part
C_100N_0603_X7R_K_50
C_33N_0603_X7R_K_25
C_2U2_1206_X7R_K_10
20BQ030, International Rectifier
LED_CL150GCD, Citizen
LED_CL150URCD, Citizen
LED_CL150YCD, Citizen
LED_EL15-21UBC, Everlight
Distance 12.5mm
Distance 12.5mm
Distance 12.5mm
Distance 12.5mm
DSUB_9F
SCREW_TERM_5
SCREW_TERM_5
DC_JACK_2.5
PINROW_2_10
SMA (Right angle)
SMA (Right angle)
SMA (Right angle)
SMA (Right angle)
PINROW_2X5
PINROW_2X5
PINROW_2X5
SMD_HEADER_2x10 (Samtec TFM-
110-02-S-D-A-K-TR)
SMD_HEADER_2x10 (Samtec TFM-
110-02-S-D-A-K-TR)
USB_B (AMP 787780-1)
CON6_FEMALE_LP (Preci-DIP 801-
91-006-10-012)
PINROW_2X10
CON6_FEMALE_LP (Preci-DIP 801-
91-006-10-012)
Page 25 of 32
