Powering an Altix 350 System

007-4417-001
Plug your Altix 350 system into a suitable power outlet, as shown in Figure 1-1 (for non-racked
chassis) or Figure 1-2 (for racked chassis). Refer to the Altix 350 User's Guide for detailed power
requirements.
Figure 1-1
Connecting an Altix 350 Non-Racked System to Power
Positioning and Powering an Altix 350 System
Expansion compute module
Base compute module
3
