Dimensions

Interfaces

Location Connector
Rear Panel Power input: 5.5mm jack / 6-pin ATX
conn.
Optional 2x 3.5mm jacks
2x HDMI
2x mini-DP
2x RJ45
2x USB Type-A
2x USB Type-A
Front Panel Power button
Optional expansion TELs
Right Panel 2x SMA
Optional expansion TELs
Left Panel 2x SMA
Optional expansion TELs
Location Connector
Internal 2x SO-DIMM
M.2 Key-B
M.2 Key-E
M.2 Key-M
TRIP1
TRIP2
4-pin internal USB

Optional TEL expansion modules

TEL
FT.C-LAN2
FT.EC-USB2V4
FT.ED-USB3PCIV4
FT.F-M2NVME for NVMe
FT.F-M2NVME for SATA
FT.H-SER4
FT.HB-DB9
FT.HA-SER1
FT.I-M2B
FT.J-M2E
FT.L-PCIEmini
FT.Q-CAN
FT.S-GPIO
FT.V-TERM4
www.fit-iot.com
Form factor
DDR4 SO-DIMM
M.2 Up to 3060
M.2 2230 or
M.2 up to 2280
Expansion TEL
Expansion TEL
Expansion TEL
Description
Additional 2x Gbit LAN
Additional 4x USB 2.0
Additional 4x USB 3.0
Additional M.2 Key-M for NVMe
Additional M.2 Key-M for SATA
1-4 isolated RS232 or RS485
DB9 connector for FT.H-SER4
1 port RS232
Additional M.2 Key-B for modem
Additional M.2 Key-E for Wi-Fi/BT
Mini PCIe compartment
Isolated CAN bus port
4 – 20 isolated GPIOs
Terminal block 4x for FT.S-GPIO
Tel: +972-48-290-168 | Fax: +972-48-325-251 | www.fit-iot.com
Interface
7V - 12V, up to 60W / 12v – 56V, up to 120W
Optional analog audio (TEL-AUDIO)
HDMI 1.4b (up to 3840 x 2160 @ 30Hz)
DP 1.2 (up to 4096 x 2160 @ 60Hz) Dual mode
2 x RJ45 10/100/1000 Mbps Ethernet
2x USB 2.0
2x USB 3.1
On/Off push button w/ power LED
2x RJ45, DB9, terminal block, etc.
2x SMA antennas for Wi-Fi/BT or cellular modem
2x RJ45, DB9, terminal block, etc.
2x SMA antennas for Wi-Fi/BT or cellular modem
2x RJ45, DB9, terminal block, etc.
Interface
DDR4, up to 3200 MT/s
PCIe Gen 3 x1 + USB 2.0
PCIe Gen 3 x1 + USB 2.0
PCIe Gen 3 x4 / SATA
PCIe Gen 3 x4/ 2x PCIe
PCIe Gen 3 x1 / SATA
USB 2.0
Max. quantity
1
1
2
2
1
1
3
3 per FT.H-SER4
3
2
2
2
3
3
4 per FT.S-GPIO
Page 6 of 19
Hayetsira St. 17, Yokneam, Israel
Usage
2x DDR4 module
LTE/5G modem
Wi-Fi/BT module
NVMe/SATA storage/AI
TEL expansions for TRIP1
TEL expansions for TRIP2
USB TEL expansions
Where connected
TRIP1
TRIP1 / TRIP2
TRIP 1,2
TRIP1
TRIP2
TRIP1 / TRIP2 / int. USB
FT.H-SER4
TRIP1 / TRIP2 / int. USB
TRIP1 / TRIP2
TRIP1 / TRIP2
TRIP1 / TRIP2
TRIP1 / TRIP2 / int. USB
TRIP1 / TRIP2 / int. USB
FT.S-GPIO
Tensor-I22 owner's manual
PN
FC
FEC
FED
FFN
FFS
FH
FHA
FI
FJ
FL
FQ
FS
FV
