AMP Research BedStep 75326-01A Application

For jeep wrangler jt 2020

Using a 15mm wrench assemble steel bracket

to Linkage assembly. Torque bolts to 20 ft-lbs.

AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST

Designed and manufactured by AMP Research

Three-year limited warranty. Professional installation is recommended.

15mm

. Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221;

APPLICATION

Jeep Wrangler JT

Locate mounting points on rearmost body mount

on Passenger side of vehicle.Using a 15mm

deep socket to remove conical washer nut. Next

use 21mm socket to back out bolt at frame. Only

remove enough to slide bracket into position.

1/2

AMP PART # 75326-01A

2020

Torque wrench

T25

13mm

15mm

21mm

13 & 21mm

IM75326 rev 07.22.19

www.4x4ok.com

Table of Contents

Need help?

Do you have a question about the BedStep 75326-01A and is the answer not in the manual?

Page 1 . Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221; ® 7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other US and Worldwide patents pending. Made in USA © 2009 AMP Research Three-year limited warranty. Professional installation is recommended. IM75326 rev 07.22.19...
Page 2 Set J Clip nut into position in bed sheetmetal Rotate bracket into position. Insert portion of to use as a bracket attachment point. bracket that attaches to J clip first. Then rotate over front stud and Hitch bolt. Re-use nut from step 2 and hand tighten only.
Page 3 L I MI TE D WARRAN T Y AMP RESEARCH warrants product to be free from defects in material and workmanship, for terms specified below, provided there has been normal use and proper maintenance. All remedies under this warranty are limited to the repair or replacement of any item found by the factory to be defective within the time period specified.
