- Assemble bracket as shown below.
- Do not tighten!
6
1
Attach bracket assembly to linkage as shown below.
6
3
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Designed and manufactured by AMP Research
7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other US and Worldwide patents pending. Made in USA © 2009 AMP Research
Three-year limited warranty. Professional installation is recommended.
www.amp-research.com
3
5
6
7
. Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221;
®
APPLICATION
Ford Super Duty
F250/ F350
8
Vice
3" Extension
6" Extension
- Secure linkage in a vice to attach bracket.
13mm
2
13mm
8
!
- Torque bolt to 33ft-lbs/ 44N·m
4
1/3
AMP PART # 75330-01A
2023
Torque wrench
13mm Box Wrench
15 & 21mm
13 & 15
(Deep Well)
!
- Torque bolt to 16ft-lbs/ 22N·m
IM75330 rev 06.01.23
