The HTC (Blue Oval) Actuator is available in 2 main configurations—the standard configuration and the configuration
with the Loss of Power (LOP) Capacitor. The HTC is also available with IP 65 rating that allows outdoor installation
of the valve and actuator, but not the Heat Timer controller. The HTC actuator with IP 65 is only available with
the LOP Capacitor. Finally, the HTC actuator can accept either a current voltage input signal or a floating (OPEN/
CLOSE) signal.
The HTC Actuator is a direct replacement of the earlier actuators, M800 and TR1000 models, found on ETV Plus—
electronic tempering valves installations. The HTC Actuator is also found in the valve and actuator only kits used in
dual valve applications for the current ETV Platinum Plus applications. The following is a listing of part numbers on
the HTC Actuator can be ordered:

HTC ACTUATOR ONLY FOR REPLACEMENT

HTC Actuator Standard (without LOP Capacitor) P/N 905040-00
HTC Actuator with LOP Capacitor
HTC Actuator with IP 65 Rating

ETV STAINLESS VALVE AND ACTUATOR KITS

STAINLESS STEAL VALVE
AND ACTUATOR
½"
¾"
1"
1 ¼"
1 ½"
2"
2 ½"

IP 65 RATED HTC ACTUATOR

When ordering an ETV Platinum PLUS complete assembly or an ETV
Valve and Actuator kit (as describe above) or the HTC actuator as a
replacement only, the following part number extension is required: -65.
Example: If you have an application requiring a 2 inch ETV Platinum
PLUS complete assembly (P/N 915675-00) that is to have the valve and
actuator installed outdoors, then you would order the following:
P/N 915675-65.
|
4
HEAT-TIMER CORP.
P/N 905048-00
P/N 905048-65
CV PART NUMBER
5 915640-00
7 915641-00
12 915642-00
18 915643-00
29 915644-00
46 915645-00
73 915646-00
01

OVERVIEW

NOTE
The kits include ETV stainless
steel valve body, the HTC
actuator and a 24V transformer.
NOTE
An IP 65 rate actuator will allow
the valve and actuator to be
mounted outdoors, The Heat-
Timer controller is NOT approved
for outdoor installations.
059297-00 REV. H
