Table Of Contents - heat-timer HTC Installation And Operation Manual

01
OVERVIEW
HTC ACTUATOR ONLY FOR REPLACEMENT
ETV STAINLESS VALVE AND ACTUATOR KITS
IP 65 RATED HTC ACTUATOR
ETV VALVE AND HTC ACTUATOR DIMENSIONAL
SPECIFICATIONS
02
INSTALLATION GUIDELINES
MANUAL OVERRIDE OPERATION
WIRE TERMINAL ACCESS
03
APPLICATIONS
ETV VALVE AND ACTUATOR INSTALLATIONS-
DUAL VALVE APPLICATIONS
REPLACEMENT OF THE ETV PLUS M800 ACTUATOR
REPLACEMENT OF THE ETV PLUS TR1000 ACTUATOR 10
REPLACEMENT OF AN EXISTING HTC ACTUATOR
INSTALLATION ON BRONZE VALVE BODY
INSTALLATION ON STAINLESS STEEL VALVE BODY

TABLE OF CONTENTS

4
4
4
4
5
5
6
7
7
8
8
8
12
14
15
04
WIRING
GENERAL WIRING
24V FLOATING
ETV WIRING
ETV PLUS WIRING
ETV PLATINUM PLUS WIRING
MODULATION CURRENT VOLTAGE
MODULATION 4-20mA
05
CONFIGURATION AND SETTINGS
DIP SWITCHES AND CAPACITOR JUMPER
VALVE INSTALLATION-
ALTERNATE CONFIGURATION
DIP SWITCH SETTING-OPTIONAL SETTINGS
LED STATUS
CALIBRATION
STARTUP
IP 65 INSULATION KIT
06
NOTES
16
16
17
17
18
18
19
19
20
20
21
21
23
23
24
24
25
