Knick Stratos Eco 2405 CondI User Manual

Hide thumbs Also See for Stratos Eco 2405 CondI:
Table of Contents

Advertisement

Quick Links

Download this manual
Stratos® Eco 2405 CondI
User Manual
Latest Product Information: www.knick.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stratos Eco 2405 CondI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Knick Stratos Eco 2405 CondI

Summary of Contents for Knick Stratos Eco 2405 CondI

  • Page 1 Stratos® Eco 2405 CondI User Manual Latest Product Information: www.knick.de...
  • Page 2 Please observe the applicable local or national regulations concerning the disposal of “waste electrical and electronic equipment”. Knick Elektronische Messgeräte GmbH & Co. KG Beuckestraße 22 14163 Berlin Germany Phone: +49 30 80191-0 Fax: +49 30 80191-200 Web: www.knick.de Email: info@knick.de...

  • Page 3: Table Of Contents

    Table of Contents Safety Information ................. 5 Intended Use ....................7 Registered Trademarks .................7 Provided Documentation ............. 8 Overview of Stratos Eco 2405 CondI .......... 9 Assembly ..................10 Package Contents ..................10 Mounting Plan ....................11 Pipe Mounting, Panel Mounting .............12 Installation and Connection ............14 Installation Instructions ................14...
  • Page 4 Table of Contents Temperature Compensation ..............52 Alarm Settings ....................54 Limit Function ....................56 Controlling a Rinsing Probe ..............58 Connecting a Rinsing System ..............59 Parameters ..................60 Factory Settings of Parameters ...............60 Parameters – Individual Settings ............62 Calibration ..................64 Calibration by Input of Cell Factor ............66 Calibration with Calibration Solution ..........68 Product Calibration ..................70 Zero Calibration in Air ................72...

  • Page 5: Safety Information

    Safety Information Safety information – Be sure to read and observe the following instructions! The device has been manufactured using state of the art technology and it complies with applicable safety regulations. When operating the device, certain conditions may nevertheless lead to danger for the operator or damage to the device.

  • Page 7: Intended Use

    Intended Use The Stratos Eco 2405 CondI is used for measurement of electrical conductivity and temperature in liquids using electrodeless (toroidal) sensors. Fields of application are: biotechnology, chemical industry, environment, food processing, water/waste-water treatment. The sturdy molded enclosure can be fixed into a control panel or mounted on a wall or at a post.

  • Page 8: Provided Documentation

    Provided Documentation Safety Instructions In official EU languages and others. Quickstart Guides In German, English, French, Russian, Finnish, Swedish, Spanish, Portuguese, and Chinese. • Installation and Commissioning • Operation • Menu structure • Calibration • Error messages and recommended actions Test Report 2.2 according to EN 10204...

  • Page 9: Overview Of Stratos Eco 2405 Condi

    Overview Overview of Stratos Eco 2405 CondI CondI input + Output 1 Output 1 receive hi – Output 1/2 receive hi + Output 2 drain Output 2 send lo send hi Relay Shield Relay Not in use Alarm Alarm Alarm...

  • Page 10: Assembly

    Assembly Package Contents Check the shipment for transport damage and completeness. The package should contain: • Front unit • Rear unit • Bag containing small parts • Documentation • Passcode sticker 1 Jumper (2 x) 6 Sealing insert (1 x) 2 Washer (1 x), for conduit mounting: 7 Rubber reducer (1 x) Place washer between enclosure and...

  • Page 11: Mounting Plan

    Assembly Mounting Plan 1 Cable gland (3 x) 2 Knockouts for cable gland or 1/2“ conduit, ø 21.5 mm (2 knockouts) Conduits not included! 3 Knockout for pipe mounting (4 x) 4 Knockout for wall mounting (2 x) Fig.: Mounting plan (All dimensions in mm!)

  • Page 12: Pipe Mounting, Panel Mounting

    Assembly Pipe Mounting, Panel Mounting 1 ZU 0276 protective hood (if required) 2 Hose clamp with worm gear drive to DIN 3017 (2 x) 3 Pipe-mount plate (1 x) 4 For vertical or horizontal posts or pipes 5 Self-tapping screw (4 x) Fig.: ZU 0274 pipe-mount kit (All dimensions in mm!) Fig.: ZU 0276 protective hood for wall and pipe mounting (All dimensions in mm!)
  • Page 13 Assembly 1 Screw (4 x) max. 25 2 Gasket (1 x) 3 Control panel 4 Span piece (4 x) 5 Threaded sleeve (4 x) Panel cut-out 138 x 138 mm (DIN 43700) 1...22 Fig.: ZU 0275 panel-mount kit (All dimensions in mm!)

  • Page 14: Installation And Connection

    20.5 ... 253 V AC/DC. • All parameters must be set by a system administrator prior to commissioning. The terminals are suitable for single wires and flexible leads up to 2.5 mm (AWG 14). Terminal Assignments Fig.: Stratos Eco 2405 CondI terminal assignments...
  • Page 15 Installation and Connection 1 Terminals for temperature probe and outer shield 2 Terminals for sensor 3 Terminals for power supply Fig.: Information on installation, rear side of device Division 2 Wiring The connections to the device must be installed in accordance with the National Electric Code (ANSI NFPA 70) Division 2 hazardous (classified) location non-incendive wiring techniques.

  • Page 16: Preparing The Shield Connection

    Installation and Connection Preparing the Shield Connection Pre-assembled special cable for SE655 / SE656 sensor • Insert the special cable through the cable entry into the terminal compartment. • Remove the already separated part of the cable insulation (1). • Turn the shielding mesh (2) over the cable insulation (3).

  • Page 17: Wiring Examples

    Wiring Examples SE655 / SE656 Sensor Connecting the pre-assembled cable Stratos Eco 2405 CondI * Connect the shield wire (green/yellow) to the shielding mesh of the special cable using a crimp ring (see ”Preparing the Shield Connection”).

  • Page 18: Se660 Sensor

    Wiring Examples SE660 Sensor Connecting the pre-assembled cable Stratos Eco 2405 CondI * Connect the shield wire (green/yellow) to the shielding mesh of the special cable using a crimp ring (see ”Preparing the Shield Connection”).

  • Page 19: Sensors From Other Manufacturers

    Sensors From Other Manufacturers For special applications (chemical resistance, type of mounting), you can also connect sensors from other manufacturers. Permissible ranges for the Stratos Eco 2405 CondI as well as terminal assignments and factory settings for these sensors are available on request.

  • Page 20: Protective Wiring Of Relay Outputs

    Protective Wiring of Relay Outputs Protective Wiring of Relay Contacts Relay contacts are subjected to electrical erosion. Especially with inductive and capacitive loads, the service life of the contacts will be reduced. For suppression of sparks and arcing, components such as RC combinations, nonlinear resistors, series resistors and diodes should be used.
  • Page 21 Protective Wiring of Relay Outputs Typical Protective Wiring Measures A: DC application with inductive load B: AC/DC applications with capacitive load C: Connection of incandescent lamps A1 Inductive load A2 Free-wheeling diode, e.g. 1N4007 (Observe polarity) A3 Contact B1 Capacitive load B2 Resistor, e.g.

  • Page 22: User Interface And Display

    User Interface and Display User Interface 1 Display 3 Alarm LED 2 Mode indicators (no keys), 4 Keypad from left to right: - Measuring mode - Calibration mode - Alarm - Wash contact - Configuration mode...
  • Page 23 User Interface and Display Display 9 10 1 Passcode entry 14 Secondary display 2 Not in use 15 Manual temperature specification 3 Temperature 16 Hold mode active 4 Current output 17 Waiting time running 5 Limit values 18 Sensor data 6 Alarm 19 Main display 7 Sensocheck...

  • Page 24: Operation: Keypad

    User Interface and Display Operation: Keypad Start, end calibration conf Start, end configuration • Select digit position  (selected position blinks) • Menu navigation • Edit digit  • Menu navigation enter • Calibration: Continue in program sequence • Configuration: Confirm entries, next configuration step •...

  • Page 25: Safety Functions

    Safety Functions Sensocheck, Sensoface Sensor Monitoring Sensocheck continuously monitors the sensor and its wiring. Sensocheck can be switched off (Configuration, Pg 54). Sensoface provides information on the conductivity sensor condition. The primary coil and its lines are continuously monitored for short circuits, the secondary coil and its lines are checked for open circuits.

  • Page 26: Hold Mode

    Safety Functions Hold Mode Display: The Hold mode is a safety state during configuration and calibration. Output current is frozen (Last) or set to a fixed value (Fix). Alarm and limit contacts are disabled. If the calibration or configuration mode is exited, the device remains in the Hold mode for safety reasons.
  • Page 27 Safety Functions Alarm Alarm delay is 10 seconds. During an error message the alarm LED blinks. Error messages can also be signaled by a 22 mA output current. The alarm contact is activated by alarm or power failure, see also Pg 55.

  • Page 28: Configuration

    Configuration In the Configuration mode you set the device parameters. Activation conf Activate by pressing conf Enter passcode “1200“ Edit parameter using  and , confirm/proceed using enter. (End by pressing conf, then enter.) HOLD The output current is frozen (at its last value or at a preset fixed value, depend- ing on the configuration), limit and During configu-...

  • Page 29: Menu Structure Of Configuration

    Configuration Menu Structure of Configuration The configuration steps are assigned to different menu groups. Using the arrow keys, you can jump between the individual menu groups. Each menu group contains menu items for setting the parameters. Pressing enter opens a menu item. The values are edited using the arrow keys.

  • Page 30: Overview Of Configuration Steps

    Configuration Overview of Configuration Steps Code Menu Selection / Default out1 Output 1 o1.SnSR Sensor selection * SE655/SE656/SE660/other other Enter cell factor xx.xxx c Enter transfer ratio xxx.xx Select measuring frequency 8 kHz / 12 kHz Select temperature probe Pt100/Pt1000/NTC100 o1.UnIT Select process variable mS/cm, S/m, Conc, SAL...
  • Page 31 Configuration Code Menu Selection / Default ALrt Alarm settings AL.SnSO Select Sensocheck ON / OFF rLAY Relay 1: Limit L1.FCT Select contact function Lo / Hi L1.tYP Select contact response N/O / N/C L1.LEVL Enter setpoint xxxx L1.HYS Enter hysteresis xxxx L1.dLY Enter delay...

  • Page 32: Output 1

    Configuration Output 1 Selecting the sensor 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 33).
  • Page 33 Configuration Code Display Action Choices Select sensor: SE660 Select usingkey. (SE655/ Press enter to proceed. SE656/ SE660/ Please note: After each other see sensor selection the nomi- Pg 35) nal cell factor of the sensor is saved. To adjust the cell factor to the device, calibrate the sensor afterwards! Note: Characters represented in gray are blinking and can be edited.
  • Page 34 Configuration Output 1 Selecting sensor parameters and temperature probe 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 35).
  • Page 35 Configuration Code Display Action Selection When you have selected “other“, the sensor param- eters are entered separately: Enter cell factor: Select position usingkey and edit number using , press enter to confirm. Enter transfer ratio: Press enter to proceed 8 kHz Select meas.
  • Page 36 Configuration Output 1 Select process variable 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 37).
  • Page 37 Configuration Code Display Action Choices Select process variable: 000.0 mS (0.000 mS Select usingkey, 00.00 mS Press enter to proceed. 000.0 mS 0000 mS 0.000 S/m 00.00 S/m Conductivity: 000.0 SAL 0.000 ... 9.999 mS/cm 00.00 % (Conc)) 00.00 ... 99.99 mS/cm 000.0 ...
  • Page 38 Configuration Output 1 Concentration measurement: Select process solutions 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 39).
  • Page 39 Configuration Code Display Action Choices Only with 00.00 % Conc -01-SOL can you select the process (-01-SOL solution. -02-SOL Select using arrow key -03-SOL -04-SOL -01- NaCl -05-SOL) (0.00 ... 9.99 % by wt) (0 ... 120 °C) -02- HCl (0.00 ...
  • Page 40 Configuration Output 1 Output current range: Current start / end 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 41).
  • Page 41 Configuration Code Display Action Choices Set output current range 4-20 mA Select using key, (0 - 20 mA/ press enter to proceed. 4 - 20 mA) 000.0 mS Current start Enter lower end of scale. (xxx.x mS) Select using key, edit number using key, press enter to proceed.
  • Page 42 Configuration Output 1 Time constant of output filter 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 43).
  • Page 43 Configuration Code Display Action Choices Time constant of output filter 0 sec 0 ... 120 sec Default setting: 0 s (inactive). To specify a time constant: Select usingkey, edit number using  key, press enter to proceed. Time Constant of Output Filter (Attenuation) To smoothen the current output, a low-pass filter with adjustable filter time constant can be switched on.
  • Page 44 Configuration Output 1 Output current during Error and HOLD 1 Press conf key. conf 2 Enter passcode 1200. 3 Output 1 menu group is displayed. All items of this menu group are indicated by the “o1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 45).
  • Page 45 Configuration Code Display Action Choices 22 mA signal for error (OFF / ON) message Select usingkey, press enter to proceed. LAST Output signal during HOLD LAST: During HOLD the last (LAST / FIX) measured value is main- tained at the output FIX: During HOLD a value (to be entered) is maintained at the output...

  • Page 46: Output 2

    Configuration Output 2 Temperature unit and probe, output current 1 Press conf key. conf 2 Enter passcode 1200. 3 Select Output 2 menu group using arrow keys. All items of this menu group are indi- cated by the “o2. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 47).
  • Page 47 Configuration Code Display Action Choices Specify temperature unit °C Select usingkey, (°C / °F) press enter to proceed. 4 - 20 mA Select output current range Select usingkey, (4 - 20 mA/ press enter to proceed. 0 - 20 mA) 000.0 °C Current start: Enter lower end of scale.
  • Page 48 Configuration Output 2 Time constant of output filter 1 Press conf key. conf 2 Enter passcode 1200. 3 Select Output 2 menu group using arrow keys. All items of this menu group are indi- cated by the “o2. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 49).
  • Page 49 Configuration Code Display Action Choices Time constant of output filter 0 sec Default setting: (0 ... 120 sec) 0 sec (inactive). To specify a time constant: Select using , edit number using , press enter to proceed. Time Constant of Output Filter To smoothen the current output, a low-pass filter with adjustable filter time constant can be switched on.
  • Page 50 Configuration Output 2 Temperature error, output current during HOLD 1 Press conf key. conf 2 Enter passcode 1200. 3 Select Output 2 menu group using arrow keys. All items of this menu group are indi- cated by the “o2. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 51).
  • Page 51 Configuration Code Display Action Choices 22 mA signal for error (OFF / ON) message Select usingkey, press enter to proceed. LAST Output signal during HOLD LAST: During HOLD the last (LAST / FIX) measured value is main- tained at the output FIX: During HOLD a value (to be entered) is maintained at the output...

  • Page 52: Temperature Compensation

    Configuration Temperature Compensation Temp compensation selection 1 Press conf key. conf 2 Enter passcode 1200. 3 Select Temperature compensation menu group using arrow keys. All items of this menu group are indicated by the “tc. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 53).
  • Page 53 Configuration Code Display Action Choices Select temp compensation (OFF OFF: Temperature compen- sation switched off nLF) Select usingkey, press enter to proceed. LIN: Linear temperature compensation with entry of temperature coefficient and reference temperature nLF: Temperature compensa- tion for natural waters to EN 27888 02.00%/K Only with linear tempera-...

  • Page 54: Alarm Settings

    Configuration Alarm Settings 1 Press conf key. conf 2 Enter passcode 1200. 3 Select Alarm settings menu group using arrow keys. All items of this menu group are indicated by the “AL. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 55).
  • Page 55 Configuration Code Display Action Choices Select Sensocheck (continuous monitoring of (ON / OFF) sensor) Select usingkey, press enter to proceed. Alarm Contact Alarm The alarm contact is closed during normal operation (N/C). It opens in the case of alarm or power outage.

  • Page 56: Limit Function

    Configuration Limit Function Relay 1 Press conf key. conf 2 Enter passcode 1200. 3 Select Limit function menu group using arrow keys. All items of this menu group are indicated by the “L1. ” code. 4 Press enter to select menu, edit using arrow keys (see Pg 57).
  • Page 57 Configuration Code Display Action Selection Contact function (see below for function (Lo/Hi) principle) Select usingkey, press enter to proceed. Contact response N/C: normally closed contact (N/O N/O: normally open contact N/C) Select usingkey, press enter to proceed. 000.0 mS Setpoint Select usingkey, (xxx.x mS) edit number using key,...

  • Page 58: Controlling A Rinsing Probe

    Configuration Controlling a Rinsing Probe conf “Clean” contact 1 Press conf key. 1 Press conf key. 2 Enter passcode 1200. 2 Enter passcode 1200. 3 Select Limit function menu group using 3 Select Rinsing probes menu group using arrow keys. All items of this menu group are arrow keys.

  • Page 59: Connecting A Rinsing System

    Configuration Code Display Action Choices Rinsing interval 0000 h Select using  key, enter (x.xxx h) number using  press enter to proceed. 0060 sec Rinse duration Select using  key, (xxxx sec) enter number using  press enter to proceed. Contact response N/C: normally closed contact (N/O)

  • Page 60: Parameters

    Parameters Factory Settings of Parameters Activation: Simultaneously press conf + right arrow key and enter passcode “4321“. The lower display line reads “Clear“. To prevent accidental resetting, “NO“ is set as default (blinking in the main display). Press one of the arrow keys to select “YES“ and confirm by pressing enter.
  • Page 61 Parameters Code Parameter Factory setting Temp compensation tc. LIN Temp coefficient 02.00%/K AL.SnSO Sensocheck L1.FCT Contact function L1.tYP Contact response L1.LEVL Setpoint 000.0 mS L1.HYS Hysteresis 001.0 mS L1.dLY Delay 0010 sec Rinsing interval Rinse duration Contact type Please note: Fill in your configuration data on the following pages.

  • Page 62: Parameters - Individual Settings

    Parameters Parameters – Individual Settings Code Parameters Setting o1.SnSR Sensor o1.UnIT Process variable o1.CoNC Solution (Conc) o1. rNG 0/4-20 mA o1. 4mA Current start o1.20mA Current end o1.FtME Filter time o1.FAIL 22mA signal o1.HoLD HOLD response o1.FIX Fix current o2.UnIT Unit °C / °F o2.rNG 0/4 ...20mA...
  • Page 63 Parameters Code Parameter Setting o2.FtME Filter time o2.FAIL 22mA signal o2.HoLD HOLD response o2.FIX Fix current Temp compensation tc. LIN Temp coefficient AL.SnSO Sensocheck L1.FCT Contact function L1.tYP Contact response L1.LEVL Setpoint L1.HYS Hysteresis L1.dLY Delay Rinsing interval Rinse duration Contact type...

  • Page 64: Calibration

    Calibration Calibration adjusts the device to the sensor. Activation Activate by pressing cal Enter passcode: • Entry of cell factor 1100 • With calibration solution 0110 • Product calibration 1105 • Zero point 1001 • Temp probe adjustment 1015 Select using  key. Edit parameter using .
  • Page 65 Calibration Information on Calibration Calibration adapts the device to the conductivity sensor. Calibration can be performed by: • Entry of cell factor • Determining the cell factor with a known calibration solution (calibration standard) taking account of the temperature • Product calibration •...

  • Page 66: Calibration By Input Of Cell Factor

    Calibration Calibration by Input of Cell Factor Input of cell factor with simultaneous display of conductivity and temperature (without temperature compensation) Display Action Remark Press cal key, Device is in the Hold enter code 1100. mode. Select using  key, If an invalid code is edit number using ...
  • Page 67 Calibration Display Action Remark Conductivity and temperature are displayed. The measured value is shown in After end of calibra- the main display alternately with tion, the outputs “Hold”. “enter” blinks. remain in Hold mode End calibration by pressing for approx. 20 sec. enter.

  • Page 68: Calibration With Calibration Solution

    Calibration Calibration with Calibration Solution Input of temperature-corrected value of calibration solution (calibra- tion standard) with simultaneous display of cell factor and zero point Display Action Remark Press cal key, If an invalid code is enter code 0110. entered, the device Select using ...
  • Page 69 Calibration Display Action Remark The determined cell factor and zero point are displayed. Press enter to confirm. The device now displays the conductivity and temperature. Clean sensor and re-place it After end of calibra- in the process. The measured tion, the outputs value is shown in the main remain in Hold mode display alternately with “Hold”.

  • Page 70: Product Calibration

    Calibration Product Calibration Calibration by comparison The measurement is only interrupted briefly. During product cali- bration the sensor remains in the process. Calibration is without TC correction. Procedure: The currently measured value is stored in the device for comparison. A sample is measured using a portable meter. The sample value is then entered in the device.
  • Page 71 Calibration Display Action Remark The new cell factor and zero New calibration: Press cal. point are displayed. Press enter to confirm. The new value is shown in the After end of calibra- main display alternately with tion, the outputs “Hold”, “enter” blinks. remain in Hold mode End by pressing enter.

  • Page 72: Zero Calibration In Air

    Calibration Zero Calibration in Air Display Action Remark Press cal key, Device is in the Hold enter code 1001. mode. Presskey to select position, If an invalid code is enter number usingkey, entered, the device Press enter to confirm. returns to measuring mode.
  • Page 73 Calibration Display Action Remark The cell factor and zero point are displayed. Press enter to confirm the calibration data. The device now displays the con- ductivity and temperature. Place sensor in process. After end of calibra- The measured value is shown in tion, the outputs the main display alternately with remain in Hold mode...

  • Page 74: Zero Calibration With Calibration Solution

    Calibration Zero Calibration with Calibration Solution Calibration solution with low conductivity Display Action Remark Press cal key, Device is in the Hold enter code 1001. mode. Presskey to select position, If an invalid code is enter number usingkey. entered, the device Press enter to confirm.

  • Page 75: Temp Probe Adjustment

    Temp Probe Adjustment Display Action Remark Select calibration Wrong settings Press cal key, change the measure- enter code 1015. ment properties! If Presskey to select position, an invalid code is enter number usingkey. entered, the device Press enter to confirm. returns to measuring mode.

  • Page 76: Diagnostics Functions

    Diagnostics Functions Display Action Display of output currents Press enter while in measuring mode. The current at output 1 is shown in the main display, the current at output 2 in the secondary display. After 5 sec the device returns to measuring mode. Display of calibration data (Cal Info) Press cal while in measuring mode and confirm code 0000.
  • Page 77 Diagnostics Functions These functions are used for testing the connected peripherals. Display Action Specify current at output 1 Press conf while in measuring mode and enter code 5555. The current indicated in the main display for output 1 can be edited. Select usingkey, edit number using key.

  • Page 78: Error Messages (Error Codes)

    Error Messages (Error Codes) Problem Error Display Possible causes ERR 01 Sensor Measured value • Wrong cell factor blinks • Measuring range exceeded • SAL > 45 ‰ • Sensor connection or cable defective ERR 02 Unsuitable sensor Measured value Conductance range >...
  • Page 79 Error Messages (Error Codes) Icon Problem Error (blinks) Possible causes ERR 03 Temperature probe Open or short circuit Temperature range exceeded ERR 11 Current output 1 Current below 0 (3.8) mA ERR 12 Current output 1 Current above 20.5 mA ERR 13 Current output 1 Current span too small / too large...

  • Page 80: Operating States

    Operating States Operating status Measure Cal Info 20 s (cal) 0000 Error Info 20 s (conf ) 0000 Calibration (cal) 1100 Temp adjustment (cal) 1015 Product calibration (cal) 1105 Configuration 20 min (conf ) 1200 Sensor monitor 20 min (conf ) 2222 Current source 1 20 min (conf ) 5555...

  • Page 81: Sensoface

    Sensoface The smiley in the display (Sensoface) alerts to sensor problems (defective sensor, defective cable). The conditions for a friendly, neutral, or sad Sensoface are summarized in the following chart. Additional icons refer to the error cause. Sensocheck Continuously monitors the primary coil and its lines for short circuits and the secondary coil and its lines for open circuits.
  • Page 82 Sensoface Display Problem Status Sensor defect Short circuit in primary coil Open circuit in secondary coil (see also Error Messages Err 33 and Err 34, Page 79). Temperature Temperature outside range for TC, error conc, SAL...

  • Page 83: Appendix

    Appendix Product Line and Accessories Devices Order No. Stratos Eco 2405 CondI 2405 CondI Mounting Accessories Pipe-mount kit ZU 0274 Panel-mount kit ZU 0275 Protective hood ZU 0276 Please note: For special applications (chemical resistance, type of mounting), you can also connect sensors from other manufacturers.

  • Page 84: Specifications

    Specifications CondI input Input for electrodeless conductivity sensors: SE 655, SE 656, SE660 and others Display range Conductivity 0.000 ... 1999 mS/cm Concentration 0.00 ... 9.99% by wt Salinity 0.0 ... 45 ‰ (0 ... 35 °C) Ranges Conductivity 0.000 ... 9.999 mS/cm 00.00 ...
  • Page 85 Specifications Sensor standardization Operating modes • Entry of cell factor with simultaneous display of conductivity and temperature • Entry of conductivity of calibration solution with simultaneous display of cell factor and temperature • Product calibration • Zero adjustment • Temperature probe adjustment Permitted cell factor 00.100 ...
  • Page 86 Specifications Output 1 0/4 ... 20 mA, max. 10 V, floating (galvanically connected to output 2) Process variable Conductivity, concentration, or salinity Overrange 22 mA in the case of error messages Output filter (attenuation) Low-pass, filter time constant 0 ... 120 s Measurement error <...
  • Page 87 Specifications Cleaning function Relay contact, floating, for controlling a simple rinsing system or an automatic cleaning system Contact ratings AC< 250 V / < 3 A / < 750 VA DC< 30 V / < 3 A / < 90 W Contact response N/C or N/O Rinse interval...
  • Page 88 Specifications Power supply 24 (-15%)...230 V AC/DC (+10%); appr. 5 VA, 2.5 W AC: 45 ... 65 Hz Overvoltage category II, protection class II Nominal operating conditions Ambient temperature -20 ... +55°C / -4 ... +131 °F Transport/Storage temp -20 ... +70 °C / -4 ... +158 °F Relative humidity 10…95 % not condensing, maximum operating height 2000 m...
  • Page 89 Specifications Enclosure Molded enclosure made of PBT, glass bead reinforced Color Black Mounting • Wall mounting • Pipe mounting: Ø 40 ... 60 mm, 30 ... 45 mm • Panel mounting, cutout to DIN 43 700 Sealed against panel Dimensions H 144 mm, W 144 mm, D 105 mm Ingress protection: IP 65 / NEMA 4X...

  • Page 90: Calibration Solutions

    Calibration Solutions Potassium Chloride Solutions (Conductivity in mS/cm) Temperature Concentration °C 0.01 mol/l 0.1 mol/l 1 mol/l 0.776 7.15 65.41 0.896 8.22 74.14 1.020 9.33 83.19 1.147 10.48 92.52 1.173 10.72 94.41 1.199 10.95 96.31 1.225 11.19 98.22 1.251 11.43 100.14 1.278 11.67...
  • Page 91 Calibration Solutions Sodium Chloride Solutions (Conductivity in mS/cm) Temperature Concentration °C 0.01 mol/l 0.1 mol/l Saturated 0.631 5.786 134.5 0.651 5.965 138.6 0.671 6.145 142.7 0.692 6.327 146.9 0.712 6.510 151.2 0.733 6.695 155.5 0.754 6.881 159.9 0.775 7.068 164.3 0.796 7.257 168.8...

  • Page 92: Concentration Curves

    Concentration Curves -01- Sodium chloride solution NaCl [°C] F [mS/cm] [ C] c [Gew%] c [% by wt] Conductivity versus substance concentration and process temperature for sodium chloride solution (NaCl)
  • Page 93 Concentration Curves -02- Hydrochloric acid HCl [°C] F [mS/cm] [ C] 1000 c [Gew%] c [% by wt] Conductivity versus substance concentration and process temperature for hydrochloric acid (HCl) Source: Haase/Sauermann/Dücker; Z. phys. Chem. New Edition, Vol. 47 (1965)
  • Page 94 Concentration Curves -03- Sodium hydroxide solution NaOH [°C] F [mS/cm] [ C] 1000 c [Gew%] c [% by wt] Conductivity versus substance concentration and process temperature for sodium hydroxide solution (NaOH)
  • Page 95 Concentration Curves -04- Sulfuric acid H [°C] F [mS/cm] [ C] 93,3 82,2 71,1 60,0 48,9 37,8 26,7 15,6 c [Gew%] c [% by wt] Conductivity versus substance concentration and process temperature for sulfuric acid (H Source: Darling; Journal of Chemical and Engineering Data; Vol.9 No. 3, July 1964...
  • Page 96 Concentration Curves -05- Nitric acid HNO [°C] F [mS/cm] [ C] c [Gew%] c [% by wt] Conductivity versus substance concentration and process temperature for nitric acid (HN0 Source: Haase/Sauermann/Dücker; Z. phys. Chem. New Edition, Vol. 47 (1965)

  • Page 97: Safe Operation

    Safe Operation Warnings and Notes to Ensure Safe Operation WARNING! Do not disconnect equipment unless power has been switched off. CAUTION! Clean only with antistatic moistened cloth. CAUTION! Substitution of components may impair suitability for hazardous locations. • The equipment shall be installed and protected from mechanical impact and ultraviolet (UV) sources.
  • Page 98 Safe Operation CAUTION! Use supply wires suitable for 30 °C / 86 °F above ambient and rated at least 250 V. CAUTION! Use signal wires suitable for at least 250V.

  • Page 99: Index

    Index 22 mA signal for error message 45, 51 Accessories 83 Alarm contact 55, 86 Alarm settings 27, 54 Assembly 10 Calibration 64 by input of cell factor 66 Display of calibration data 76 Product calibration 70 with calibration solution 68 Zero calibration in air 72 Zero calibration with calibration solution 74 Calibration solutions 90...
  • Page 100 Index Configuration: Output 2 Output current 46 Output current during HOLD 50 Temperature 46 Temperature error 50 Time constant of output filter 48 Configuration: Rinsing probes 58 Configuration: Temperature compensation 52 Connection 14 Current start / end 41, 47 Device self-test 25 Diagnostics functions 76 Display of calibration data 76 Display of last error message 76...
  • Page 101 Index Installation 14 Intended use 7 Keypad 24 Measurement 75 Mounting plan 11 Operating states 80 Output filter (attenuation) 43, 49 Overview 9 Overview of configuration steps 30 Package contents 10 Panel-mount kit 13 Parameters Factory settings 60 Individual settings 62 Passcodes 103 Pipe mounting 12 Pipe-mount kit 12...
  • Page 102 Index Rinsing probes 58 Rinsing system 59 Safe Operation 97 Safety information 5, 97 Self-test 25 Sensocheck 25, 54, 81 Configuration 55 Sensoface 25, 81 Sensor connection 17 Sensor monitor 76 Shield connection 16 Short instructions 8 Special cable 16 Specifications 84 Temperature compensation 52 Temperature probe 35...

  • Page 103: Passcodes

    Passcodes Calibration Key + passcode Menu item Page CAL info cal + 0000 (display of cell factor, slope) Cell factor adjustment cal + 1100 cal + 0110 Calibration (with standard solution) Product calibration cal + 1105 cal + 1001 Calibration (zero point e.g.
  • Page 104 Knick Elektronische Messgeräte GmbH & Co. KG Headquarters Beuckestraße 22 • 14163 Berlin Germany Phone: +49 30 80191-0 Fax: +49 30 80191-200 info@knick.de www.knick.de Local Contacts www.knick-international.com Copyright 2020 • Subject to change This document was last updated on Nov. 16, 2020 The latest documents are available for download on our website under the corresponding product description.
