Male
Catheterization
and Enema
Simulator
LM-109M
Instruction Manual
Thank you for purchasing the Male Catheterization and Enema Simulator.
Please read this instruction manual carefully to ensure correct use of the product,
and store it in a safe place for easy access.
KOKEN CO., LTD.
1-4-14 Koraku, Bunkyo-ku, Tokyo 112-0004 JAPAN
URL:http://www.kokenmpc.co.jp
E-mail:customer@kokenmpc.co.jp
© 2016-2020 KOKEN CO., LTD. C-1-1024-1-01-06
Advertisement
Related Manuals for KOKEN LM-109M
Summary of Contents for KOKEN LM-109M
- Page 1 Please read this instruction manual carefully to ensure correct use of the product, and store it in a safe place for easy access. KOKEN CO., LTD. 1-4-14 Koraku, Bunkyo-ku, Tokyo 112-0004 JAPAN URL:http://www.kokenmpc.co.jp E-mail:customer@kokenmpc.co.jp © 2016-2020 KOKEN CO., LTD. C-1-1024-1-01-06...
- Page 2 10000...
- Page 3 Handling and Safety Precautions These precautions should be strictly observed in order to ensure safe, long-term use of the product. The following precautions should be observed particularly strictly: 1. This simulator is made to have the same feel as that of a living body. Undue handling may cause breakage of the simulator.
- Page 4 11. When indwelling the catheter, please inflate the balloon after inserting the catheter apart from the balloon end portion by a distance equal to or greater than 23 cm. Indwelling of the catheter in an intermediate of the valve causes the valve and the catheter to be broken. 12.
-
Page 5: Table Of Contents
Table of Contents 1. Outline and Features 2. Components and Configuration 3. Handling Method 4. Washing and Storage Methods 5. Specifications 6. Replacement Parts (Sold Separately) -
Page 6: Outline And Features
1. Outline and Features Outline The simulator imitates the shape of the urethral canal peculiar to a male. A catheterization catheter is inserted according to a suitable technique to reach the bladder. This causes urine (water) to flow out. The feel of the penis is closely similar to that of a living body penis. Techniques such as disinfecting of surroundings of the urethral exit and cleaning of the pubic area can be performed. -
Page 7: Components And Configuration
２， 部品名称と構成 ①尿道部品 ②陰部表皮 2. Components and Configuration ③陰部フレーム ④本体 ⑤膀胱 ⑥膀胱弁 1. Urethral part 11. Bag for irrigator ⑦Ｏリング 2. Male Genital skin 12. Tube for irrigator ⑧直腸プレート ⑨膀胱チューブ 3. Pubic Area Frame 13. Stand for lateral decubitus ⑩直腸接続コネクタ... - Page 8 3. Handling the Model 3-1 Assembly of Simulator 1. Please connect the bag for irrigator with the bladder tube, and put water into the bag for irrigator. Please open a clamp, fill the bladder tube with water, close the clamp, and attach the bladder valve to it.
- Page 9 3. Please attach the genital skin to the pubic area frame. 4. Please apply lubricant to the distal end of the glans and insert it into the genital skin. Please check whether or not the glans is twisted and then fix the urethral part and the genital skin with hook and loop fasteners.
- Page 10 6. Please attach the bladder to the bladder tube, and fit and fix the bladder to the hook and loop fasteners of the right part of the main body. 7. Please cover the connector for connecting the urethral part and the bladder tube with the prostate.
- Page 11 8. Please connect the rectum connecting connector with the drain tube. 9. Please insert the rectum connecting connector from the rear side of the genital skin. 10. Please fit and fix the rectal plate to the right part of the main body. 11.
- Page 12 12. When performing a catheterization, please hang the bag for irrigator at a position higher than that of the simulator main body. If the bag is hung at a lower position, water dose not flow out. 13. When performing an enema, please prepare a bucket etc. under a desk or a bed and put the distal end of the drain tube in it.
- Page 13 3. Please apply lubricant on the distal end of the catheter for about 4 to 5 cm and insert the catheter. If you feel resistance, please slant the penis forward at about 60 degrees, and advance the catheter such that you slightly draw the penis to yourself. about 60 degrees.
- Page 14 * When indwelling the catheter, please inflate the balloon after inserting the catheter apart from the balloon end portion by a distance equal to or greater than 23 cm. Inflating the balloon in an intermediate of the valve may cause the valve and the catheter to be broken. 6.
- Page 15 3-4 Removal 1. Please separate the main body and remove the rectal plate. 2. Please remove the pubic area frame from the main body, and remove the prostate, the bladder, and the rectum connecting connector. * Please pay attention to the outflow of the water. 3.
- Page 16 4. Please remove the connector for connecting the bladder tube with the urethral part. * At this time, please pay attention to a loss of the O-ring. 5. Please remove the bladder valve from the bladder tube, and drain the water in the tube. 6.
-
Page 17: Washing And Storage Methods
4. Washing and Storage Methods 1. Please flush the lubricant that has adhered to the urethral part, the bladder valve, the bladder tube, etc. well with water. If the lubricant dries and hardens, it may interfere with the use of the simulator. -
Page 18: Specifications
5. Specifications Product name Length Width Height Weight Approx. 25 cm Main Body Approx. 39 cm Approx. 21 cm Approx. 2.3 kg Approx. 29 cm Approx. 53 cm Approx. 32 cm Storage Bag 6. Replacement Parts (Sold Separately) Product name Product No. Male Genital skin LM-109MB Bladder Valve (Male/Female) LM-109V Bag for irrigator (3pcs/set) LM-025J Tube for irrigator (3pcs/set) LM-025H Glycerine enemator (with cap/5pcs) LM-0686...
