KOKEN LM-109FA Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Female
Catheterization and
Enema Simulator
(Strap-on type)
LM-109FA
Instruction Manual
Thank you for purchasing the Female Catheterization and Enema Simulator (Strap-on type).
Please read this instruction manual carefully to ensure correct use of the product,
and store it in a safe place for easy access.
KOKEN CO., LTD.
1-4-14 Koraku, Bunkyo-ku, Tokyo 112-0004 JAPAN
URL:http://www.kokenmpc.co.jp
E-mail:customer@kokenmpc.co.jp
© 2018-2020 KOKEN CO., LTD. C-1-1033-1-01-01

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM-109FA and is the answer not in the manual?

Questions and answers

Related Manuals for KOKEN LM-109FA

Summary of Contents for KOKEN LM-109FA

  • Page 1 Female Catheterization and Enema Simulator (Strap-on type) LM-109FA Instruction Manual Thank you for purchasing the Female Catheterization and Enema Simulator (Strap-on type). Please read this instruction manual carefully to ensure correct use of the product, and store it in a safe place for easy access. KOKEN CO., LTD. 1-4-14 Koraku, Bunkyo-ku, Tokyo 112-0004 JAPAN URL:http://www.kokenmpc.co.jp E-mail:customer@kokenmpc.co.jp © 2018-2020 KOKEN CO., LTD. C-1-1033-1-01-01...
  • Page 2 10000...
  • Page 3 Handling and Safety Precautions These precautions should be strictly observed in order to ensure safe, long-term use of the product. The following precautions should be observed particularly strictly: 1. This simulator is made to have the same feel as that of a living body. Undue handling may cause breakage of the simulator. 2. This model has a distinctive odor resulting from the materials it is made from however is not harmful to the body or indicate any problem with quality. This distinctive odor will weaken over time. The product is also coated in baby powder at the time of manufacture and the smell of baby powder may remain on the product. 3. When you practice cleaning or disinfecting of the pubic area, please use water. Use of alcohol may cause breakage of the simulator. Use of colored disinfectant liquid may cause pigment to be fixed to the simulator so that the pigment cannot be removed.
  • Page 4 11. After use, please wash the simulator and the catheter well with water. If the lubricant dries and hardens, it may interfere with the use of the simulator. 12. Please check the state of the valve at every use. If the valve is broken, it may cause a leakage of water. 13. Oil components may come out of the genital skin. After use, please do not keep the genital skin attached to the simulator. Please wrap it in cooking paper, gauze, etc., put it into an attached reclosable poly bag, and keep it. For a detailed storage method, please refer to the washing and storage methods on page 15. 14. Apply commercially available baby powder to reduce friction if you mind stickiness of the genital skin or after it is washed with water following use. 15. The genital skin may deform over time. Please check the state of the genital skin every three years after purchase. If any deformation that could affect the function of the simulator is found, consider replacing it with a new one. 16. You may observe air bubbles or darker areas in the genital skin. These were formed during production; however, they do not affect the strength of the genital skin because it is made of a material resistant to tearing. 17. Please do not place objects on the simulator. Otherwise, the simulator may be deformed. 18. Please do not keep the simulator in contact with printed matter. Print, such as letters, may transfer to the simulator and be fixed there. 19. W hen storing the simulator, please select a place that is not subject to direct sunlight and ultraviolet rays. 20. This product is intended for use in standard operating environments. Do not use it in heavy industrial settings. 21. T his model uses urethane foam for some of its parts, and may be susceptible to damage from pests that are attracted to urethane foam (such as insects in the ant family). When storing this model, ensure that thorough measures are taken to prevent pest damage before storing. The company will not be involved with or held liable for pest damage that occurs during storage. 1. The contents of this instruction manual are subject to change without notice. 2. This instruction manual may not be reproduced in part or in its entirety without permission. 3. Please contact the manufacturer in the event that any errors or omissions are found in the contents of this instruction manual. 4. This product should be used only as described in this instruction manual. In particular, the product should not be used in any way that contravenes the precautions noted in the instruction manual.

  • Page 5: Table Of Contents

    Table of Contents 1. Outline and Features 2. Components and Configuration 3. Handling Method 4. Washing and Storage Methods 5. Specifications 6. Replacement Parts (Sold Separately)

  • Page 6: Outline And Features

    1. Outline and Features Outline The simulator can be mounted on a human body or a doll so that a series of techniques regarding catheterization and enema can be practiced. The feel of the labia and resistance of the catheter to its insertion are closely similar to that of a living body. If a catheterization catheter is appropriately inserted, urine (water) flows out. Features ・ The simulator is of an actual size by which a catheterization and glycerine enema for an adult female can be practiced. ・ Since the simulator is of a strap-on type, it can be mounted on a human body or a model doll so that the practice can be performed. ・ By mounting the simulator on a human body, the feeling of a patient can be simulated. Also, by mounting the simulator on a simulation patient, techniques can be practiced while communicating with the simulation patient. ・ Since soft and stretchable materials are used for the pubic area, the appearance and feel are realistic to give presence when practicing. ・ A series of techniques of catheterization such as disinfecting of a pubic area, and inserting and removing of a catheter can be practiced. ・ Cleaning techniques can be performed. ・ The attached glycerine enemator can be inserted through the anus to the rectum. This enables the practice for the glycerine enema.

  • Page 7: Components And Configuration

    2. Components and Confi guration 1. Female Urethral part 8. Bag for irrigator 2. Female Genital skin 9. Tube for irrigator 3. Bladder Valve (Male/Female) 10. Drain tube 4. O-ring 11. Glycerine enemator 5. Strap-on type frame (with belt) 6. Female strap-on type bladder tube Storage bag 7. Strap-on type rectum connecting connector Instructions manual (this pamphlet)

  • Page 8: Handling Method

    3. Handling Method 3-1 Assembling of Simulator 1. Please connect the bag for irrigator to the female strap-on type bladder tube, and put water into the bag for irrigator. Please open a clamp, fi ll the female strap-on type bladder tube with water, close the clamp, and attach the bladder valve to the bag for irrigator. 2. Please insert the female strap-on type bladder tube into the strap-on type frame.
  • Page 9 3. Please insert the O-ring into the connector of the female urethral part. 4. Please connect the female urethral part and the female strap-on type bladder tube while adjusting their positions so that the female urethral part is fi xed in the opening of the strap-on type frame. 5. Please insert the strap-on type rectum connecting connector into the strap-on type frame.
  • Page 10 6. Please connect the strap-on type rectum connecting connector to the drain tube. 7. Please put the anal portion of the female genital skin on the strap-on type rectum connecting connector. After the connector is inserted deep into the anal portion, please fi t and fi x the position of the female genital skin to the strap-on type frame. 8. Please insert the projection of the female urethral part into the urethral canal located on the reverse side of the female genital skin so that the projection is covered. Then fi x the female urethral part and the female genital skin with hook and loop fasteners. Projection of the female urethral part 9. Please attach and fi x the position of the female genital skin to the strap-on type frame.
  • Page 11 3-2 Wearing Method 1. Please remove the front belt and rear belt from the waist belt. Waist belt Front belt Rear belt 2. Please wear the waist belt and adjust the adjuster according to waist size. 3. Please pass the rear belt through the waist belt, and fi t and fi x the position of the pubic area with hook and loop fasteners.
  • Page 12 4. Please pass the front belt through the waist belt, and fi x it with hook and loop fasteners such that the belts do not come loose. Position of the model during catheterization Please adjust the position of the urethral canal on the person who (or the doll that) has put on this model to the position of the urethral canal of the model. 5. When performing an enema technique, please remove the front belt once, fi t the position of the anus to the body, and adjust the length of the rear belt fi rst. the anus to the body, and adjust the length of the rear belt fi rst. Position of the model during enema Please adjust the position of the anus on the person who (or the doll that) has put on this model to the position of the anus of the model.
  • Page 13 3-3 Insertion of Catheterization Catheter 1. Please open the clamp for irrigator tube and check whether or not the water leaks from the simulator. * W hen practicing the cleaning or disinfecting of the pubic area, please use water instead of disinfection liquid. 2. Please apply lubricant on the distal end of the catheter for about 4 to 5 cm and insert the catheter. * If it is diffi cult to insert the catheter, please check the techniques and insert it again. In this case, please remove moisture from the catheter and increase the amount of the lubricant to be applied. Also, please consider using other types of catheters (fi rm silicone catheter or catheter with thinner baloon part etc). The simulator may be broken if he catheter is forced to be inserted. * If it is diffi cult to insert the catheter, please use water mixed with a small amount (approx 5%) of surfactant (neutral detergent) as urine. * If the insertion of the catheter is repeated a plurality of times, water may accumulate in the urethral canal. 3. Please check the outfl ow of the urine (water). If urine does not flow out, check the following: - Whether the catheter passes through the valve; - Whether the clamp for irrigator tube is open; and - The amount of water in the bag for irrigator is reduced to a small amount. 4. When indwelling the catheter, please inflate the balloon after inserting the catheter apart from the balloon end portion by a distance equal to or greater than 4 cm. Indwelling of the catheter in an intermediate of the valve causes the valve and the catheter to be broken. Please provide a marker on the catheter before commencing training to ensure that the catheter tip is inserted by a distance equal to or greater than 4 cm before infl ating the balloon. Marker...
  • Page 14 5. Once the catheter is inserted, please remove the moisture from its wet tip, apply the lubricant each time, and then insert the catheter. If the lubricant is applied where water remains, the lubricant slides easily off of the catheter. This makes it diffi cult to insert the catheter. 3-4 Enema 1. Please prepare a bucket etc. under a desk or a bed and put the distal end of the drain tube in it. 2. Please fi t and fi x the position of the anus of the strap-on type frame to the body, and adjust the length of the belt. Please refer to the position of the model during enema as shown in the Figure in Section 3-2 (5) on page 10. 3. Please apply lubricant to the distal end of a glycerine enemator, insert it into the anus, and pour enema liquid (water) into it. At this time, please lower the distal end of the drain tube to a position below the anus. Otherwise, the enema liquid (water) may fl ow backward and stain clothing. 3-5 Removal 1. Please close the clamp of the bag for irrigator . 2. Please remove the belts and the strap-on type frame, and then remove the drain tube from the strap-on type rectum connecting connector. * Please pay attention to the outfl ow of the water.
  • Page 15 3. Please remove the female genital skin from the strap-on type frame with the female urethral part, the female strap-on type bladder tube, and the strap-on type rectum connecting connector connected. At this time, please remove slowly while holding the area of the hook and loop fastener so that it does not peel off from the female genital skin. 4. Please remove the strap-on type rectum connecting connector from the female genital skin. 5. Please remove the female urethral part from the female genital skin. At this time, please remove slowly while holding the area of the hook and loop fastener so that it does not peel off from the female genital skin.
  • Page 16 6. Please remove the connector for connecting the female urethral part and the female strap-on type bladder tube. * At this time, please pay attention to a loss of the O-ring. 7. Please remove the bladder valve from the female strap-on type bladder tube, and drain the water in the tube. 8. Please wash the female urethral part, the bladder valve, the female strap-on type bladder tube, the female genital skin, and the strap-on type rectum connecting connector well with water after use.

  • Page 17: Washing And Storage Methods

    4. Washing and Storage Methods 1. Please fl ush the lubricant that has adhered to the female urethral part, the bladder valve, the female strap-on type bladder tube, etc. well with water. If the lubricant dries and hardens, it may interfere with the use of the simulator. 2. Please remove moisture well, dry the simulator and then put it into a storage bag. 3. Oil components may come out of the female genital skin. After using the simulator, please do not keep the female genital skin attached to the main body. Please wrap it in cooking paper,gauze, etc., put it into an attached reclosable poly bag, and keep it therein. Please wrap the female genital skin gently such that wrinkles are not generated on it. 4. Please apply baby powder that is commercially available, if you mind stickiness of the female genital skin. 5. As for stains on the simulator, please use neutral detergent that is watered down and wipe off the stains with wet gauze etc. * Please do not use solvents such as thinner and benzene.

  • Page 18: Specifications

    5. Specifications Product name  Length  Width  Height  Weight  Approx. 23 cm Main Body Approx. 13 cm Approx. 11 cm Approx. 0.6 kg Approx. 21 cm Approx. 47 cm Approx. 24 cm Storage Bag 6. Replacement Parts (Sold Separately) Product name  Product No.  Female Genital skin LM-109FB Bladder Valve (Male/Female) (3pcs/set) LM-109V Bag for irrigator (3pcs/set) LM-025J Tube for irrigator (3pcs/set) LM-025H Glycerine enemator (with cap/5pcs)  LM-0686...
