Summary of Contents for Festo DNCKE S Series
- Page 1 DNCKE-...-S / KEC-...-S Cylinder with clamping unit / Clamping unit Operating instructions 8145483 8145483 2020-10e [8145485]...
- Page 2 Translation of the original instructions Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
-
Page 3: Table Of Contents
Test run......................... 16 Checking clamping force/overtravel................18 Operation........................23 10.1 Regular adjustment of the clamping unit..............24 10.2 Characteristic curves....................25 Cleaning........................26 Malfunctions....................... 26 12.1 Fault clearance......................26 12.2 Repair..........................27 Disposal........................28 Technical data......................28 Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 4: About This Document
About this document About this document Applicable Documents All available documents for the product è www.festo.com/sp. Specified standards Version DIN EN ISO 12100:2011-03 DIN EN ISO 4414:2011-04 DIN EN ISO 13849-1:2016-06 DIN EN ISO 13849-2:2013-02 Tab. 1 Safety Safety instructions – Only use the product in original status without unauthorised modifications. – Only use the product if it is in perfect technical condition. -
Page 5: Intended Use
Further information – Accessories è www.festo.com/catalogue. – Spare parts è www.festo.com/spareparts. Service Contact your regional Festo contact person if you have technical questions è www.festo.com. Product design All available documents for the product è www.festo.com/sp. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... - Page 6 KEC • the design type DNCKE integrated in the cylinder In these operating instructions, the designation round material is used for: • The transportation lock for KEC • The piston rod for DNCKE Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
-
Page 7: Function
Lateral loads and bending moments exerted on the round material damage its function and destroy the internal clamping component. • Load the round material only in the direction of movement. The use of a self-aligning rod coupler (è 3 Further information) prevents lateral forces. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 8: Mounting The Clamping Unit
HNC (only permissible e.g. with flange mounting FNC (approved for use for use as a holding device) as a holding and braking device – observe brak- ing direction r) Tab. 2 Festo — DNCKE-...-S / KEC-...-S — 2020-10e... - Page 9 Tab. 4 Size DNCKE [mm] 208.5 ZJ+ (plus stroke length) [mm] [mm] 56.5 [mm] Screw-in depth [mm] 9.5 15 12.5 14 14 17 … … … Screw M6 (4x) M8 (4x) M10 (4x) Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
-
Page 10: Mounting Attachments
1. Place the proximity switches in the grooves 8 of the cylinder. 2. Mount the proximity switches in the desired switching positions. Fig. 6 Installation Pneumatic installation Requirements • Check the following accessories for use: Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 11: Functional Tests
(emergency stop). The frequency or test interval of a dynamic braking test is to be determined based on the applica- tion/risk assessment and the category selected in accordance with DIN EN ISO 13849. In addition, the Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 12: Connecting Tubing To The Clamping Unit
2 Supply port for clamping unit 1 Supply port for cylinder Fig. 8 Size DNCKE Supply port for clamp- G1/8 G1/4 G3/8 ing unit Supply port for cylinder G1/4 G3/8 G1/2 (DNCKE only) Tab. 7 Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 13: Commissioning
KEC is exhausted when the round material is not inserted, the high spring force will deform the internal clamping component until it cannot function. Dismantling the round material (only required for KEC) 1. Pressurise the supply port 2 to at least 3.8 bar. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... - Page 14 If the round material is inserted at an angle, the scraper and seals might be damaged. • A 15° chamfer at least 3 mm wide at the end of the round material ensures it can be slid on easily. Rod quality è 14 Technical data. Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
-
Page 15: Adjustment Of The Clamping Unit
2. Pressurise the supply port 2 to at least 3.8 bar. 3. Loosen the locking screw 3 using an Allen key. Size DNCKE Spanner size for intern- [mm] al hexagon socket 1 ß Tab. 9 Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 16: Test Run
Fig. 16 7. Re-tighten the locking screw 3. – Tightening torque: 7 Nm. 8. Exhaust the clamping unit. The round material is then clamped. Test run • Comply with critical limits for all loads. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... - Page 17 7. Check during the test run whether the following equipment settings need to be modified: – Speed of the payload – Pneumatic cushioning – Clamping force 8. After completing the required adjustments: – End the test run. Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
-
Page 18: Checking Clamping Force/Overtravel
The overtravel in the dynamic braking test must be less than the tolerable overtravel from the application/risk analysis. – The piston rod must not slip during a testing period of 60 s. Remedy in case of slipping: readjust the clamping unit è 9.2 Adjustment of the clamping unit. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... - Page 19 This path equals the overtravel. Test force for testing with KEC Tab. 10. è The test force (test pressure) should act for 60 s. During this time, the piston must not move any fur- ther. Tab. 11 Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
- Page 20 [MPa, psi, bar] Test force Payload [kg] Acceleration due to gravity [9.81] m/s Piston surface Tab. 12 Size DNCKE Test force F 1300 3200 8000 Piston surface A 1257 3117 7854 advancing direction Tab. 13 Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
- Page 21 The test force (test pressure) should act for 60 s. During this time, the piston must not move any fur- ther. Tab. 14 Case 3: test with additional weight force, standing orientation: Fig. 20 – Calculate the required test pressure P using the following formula: Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
- Page 22 – This path equals the overtravel. The test force (test pressure) should act for 60 s. During this time, the piston must not move any fur- ther. Tab. 17 Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
-
Page 23: Operation
Diagrams è 10.2 Characteristic curves. NOTICE! A permanently pressurised clamping unit may impair operational reliability. • Exhaust the clamping unit at least once per day. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 24: Regular Adjustment Of The Clamping Unit
– Grease-solvent fluids or vapours nearby • Avoid contamination of the round material or exhaust port 7 (è Fig.1). This is the only way to ensure normal function will not be impaired. Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 25: Characteristic Curves
Fig. 21 DNCKE 40 characteristic curve Overtravel s [mm] with exhausted clamping unit until standstill with vertical mounting position as a factor of the speed v [m/s] at 6 bar. Fig. 22 DNCKE 63 characteristic curve Festo — DNCKE-...-S / KEC-...-S — 2020-10e... -
Page 26: Cleaning
Fault clearance Malfunction Possible cause Remedy Clamp does not Clamping unit leaky Send clamping unit to Festo with a open. description of the fault. Insufficient operating pressure Increase operating pressure to maxim- um permitted value. Clamping unit not correctly adjusted Readjust round material 9.2 Adjustment of the clamping unit. -
Page 27: Repair
9.2 Adjustment of the clamping unit. è Clamping component worn or clamping Replace clamping unit or send it to mechanism defective Festo with a description of the fault. Malfunctions in Incorrect position of proximity Correct position of proximity switches. position sensing... -
Page 28: Disposal
Disposal If repairs are required: – Send the clamping unit to Festo or contact Festo service è www.festo.com. Information about spare parts and accessories è www.festo.com/spareparts. Disposal ENVIRONMENT! Send the packaging and product for environmentally sound recycling in accordance with the current regulations è www.festo.com/sp. - Page 29 11 ms duration with IEC 60068 part 5 shocks per direction 2–27 Continuous shock in 150 m/s acceleration at 6 ms duration accordance with 1000 shocks per direction IEC 60068 part 2–29 Materials Housing, cover Aluminium Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
- Page 30 Piston rod DNCKE Steel (hard-chromium-plated) Tie rods, collar nuts Steel Seals TPE-U, NBR Weight Basic weight [kg] 16.8 Basic weight DNCKE [kg] 18.2 per 10 mm stroke DNCKE [kg] 0.045 0.073 0.11 Tab. 20 Festo — DNCKE-...-S / KEC-...-S — 2020-10e...
- Page 32 Festo SE & Co. KG Ruiter Straße 82 73734 Esslingen Germany Phone: +49 711 347-0 Internet: www.festo.com © 2020 all rights reserved to Festo SE & Co. KG...
