- Page 2 Redback Lasers. • This instrument complies with the safety Classification standards of laser radiation. 3D3XR CAUTION: Class 3r laser <5mW at 635nm. 3D3XG CAUTION: Class 3r laser <5mW at 522nm. Do NOT stare into laser beam or aim at another person.
- Page 3 Both the 3D3XR and 3D3XG feature three full 360 lines, one horizontal and two vertical at 90 degrees to each other. The 3D3XR has an ultra bright red beam laser and the 3D3XG has an ultra bright green beam laser.
- Page 4 3D3X DIAGRAMS 3D3XR & 3D3XG Laser Units 1. Laser Output Windows 2. Control Keypad 3. Pendulum Locking Knob 4. Battery Compartment 5. Tripod/Mounting Threads 5/8”, 1/4”...
- Page 5 Keypad Pulse Mode & Manual Mode Function Button Select Horizontal Line Toggle Switch Manual Mode Pulse Mode Select Vertical Line 1 Select Vertical Line 1 Power & Low Service power Access Battery LED (Not compatible with supplied charger) www.redbacklasers.com.au...
- Page 6 3D3X DIAGRAMS Mounting Bracket 5/8” Thread Magnetic Mount Locking Knob 3D3X to Bracket Lock for Elevating Laser Level Platform Tripod Mounts 5/8” Thread & 1/4” Thread...
- Page 7 3D3X OPERATING INSTRUCTIONS Battery Instructions The 3D3X’s have two battery options either 4 x standard “AA” size Alkaline or the Li-ion rechargeable pack. For standard 4 x “AA” alkaline operation simply insert “AA” batteries into standard battery holder in the direction indicated and slide the holder into battery recess and close the battery compartment cover.
- Page 8 3D3X OPERATING INSTRUCTIONS cont. Turning On the 3D3XR or 3D3XG To power up, simply unlock the pendulum by moving it to the “ON” position, this will automatically self level the laser. If when you unlock the pendulum all laser flash and a beeping sound is emitted then the laser is out of self levelling range, place the laser on a more level surface for the device to self level.
- Page 9 Note that the 3D3X top right button has two functions, Manual Mode and Pulse Mode. See page 10 Unit featured is 3D3XR in manual mode. Also pictured is an optional iet68 elevating tripod and optional GD12 grade dial plate; a camera style tripod with pan and tilt will provide a similar result.
- Page 10 3D3X OPERATING INSTRUCTIONS cont. Pulse Mode Pulse mode allows the 3D3XR or 3D3XG to be used with a line receiver such as the RedBack LLR705 or LLRMM30 and so allowing the laser to be used outside for general site levelling, patios, decking etc.
- Page 11 Laser Receiver LLR705 (OPTIONAL Accessory) The RedBack LLR705 is an OPTIONAL receiver for the 3D3XR & 3D3XG models. It allows the laser beam to be picked up outside at up to 150m 3D3XR and 50m 3D3XG in any lighting conditions. Ideal for decking, sheds, slabs, framing and much more.
- Page 12 3D3X OPERATING INSTRUCTIONS cont. 3D3X Mounting Options The 3D3X’s come with a magnetic mounting bracket and this mounting bracket features an elevating plate which allows the height of the horizontal laser line to be finely adjusted. The elevating plate also features a locking knob to prevent the lasers height changing once set.
- Page 13 3D3X TECHNICAL SPECIFICATIONS Technical Specifications 3D3XR - Red Beam Laser Wavelength 635nm Red Laser Class 3r <5mW Visible Range (light dependent) Up To 35m Range with Optional Receiver Up to 150m radius (Full Sunlight) Accuracy ±2mm/10m Number 360 lines Self Levelling Range ±3...
- Page 14 Power LED Flash Calibration & Self Check All Redback Lasers have been checked for calibration and certified by one of our technicians here in Australia prior to despatch and should under normal conditions not go out of calibration. A calibration certified sticker with the date and name of technician is located on the laser itself.
- Page 15 (battery leakage not covered by warranty) • The 3D3X is a precision instrument and should not be subjected to excessive knocks, drops or vibrations. • Self check calibration from time to time. See page 14 For service contact Redback Lasers. www.redbacklasers.com.au • www.redbacklasers.com.au...
- Page 16 “Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in order to manufacture the products. “Warranty Period” For the 3D3XR and 3D3XG is Two Years. Warranty period is from original purchase date, no extension is made in the event of warranty replacement products supplied or time spent being repaired.
