- Page 2 CONTENTS User Safety Introduction and ARL516G™ Accessories ARL516G™Diagram Operating Instructions Batteries Power and Rotation Speed Scan Modes & Site Layout Laser Receiver LRG715 Calibration Self Check & Technical Specifications Care & Maintenance, Trouble Shooting Warranty User Safety • Laser output sign lies near the output aperture.
- Page 3 The ARL516G™ is ideal for general site levelling and internal fit out, simply set it up on a tripod, unlock the pendulum, it self levels and the laser starts rotating.
- Page 4 ARL516G DIAGRAMS ARL516G Laser Unit 1. Laser Output Window 2. Heavy Duty Rubberised Casing 3. Battery Pack (rechargeable) 4. Keypad 5. Recharging Socket 6. Levelling Knob Side Mounted 7. Side/Wall Mount 8. Datum Marker 9. Pendulum Locking Knob 10. 5/8” – 11tpi Screw...
- Page 5 Remote Control Operating LED Rotating Mode Speed Control Scan Mode (Rotation Mode) Scan Control (Scan Mode) Power Off (only) Receiver - LRG715 Magnetic Mounting Rubber Casing LCD Display Reception Sensors (Repeated on rear) Fine/Coarse Mode Bubble Vial Speaker Control Display back light Power On/Off www.redbacklasers.com.au...
- Page 6 OPERATING INSTRUCTIONS Battery Instructions The ARL516G has two battery options either 4 x standard “C” size Alkaline or the Ni-Mh rechargeable pack. For standard 4 x “C” alkaline operation simply insert into standard battery holder in the direction indicated and tighten the locking screw.
- Page 7 Turning Laser On (Horizontal Operation) Before the ARL516G can be powered up for normal horizontal rotation the pendulum locking knob first needs to be rotated to the “ON” position, this disengages the protective pendulum lock. Now when the power button...
- Page 8 90 degree square for site layout. The ARL516G can be placed on its side with the datum marker over the correct point and the laser levelled with the bubble vial and manual levelling knob.
- Page 9 LRG715 RECEIVER INSTRUCTIONS Laser Receiver LRG715 (refer to diagram page 5) The LRG715 is a heavy duty dual sided display rotating laser receiver, it can be either hand held or with the staff bracket clamped onto a staff. The bubble vials can be used to keep the receiver level. •...
- Page 10 We at Redback Lasers provide a once off free calibration and check within the duration of the warranty period see page 12 for details.
- Page 11 • Self check calibration from time to time. See page 9 • For service contact Redback Lasers. www.redbacklasers.com.au Trouble Shooting - FAQ I hear a continuous beeping in side (Vertical rotation) mode! Check the pendulum lock is in the “OFF” Locked position when used in vertical rotation mode on its side mount.
- Page 12 “Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in order to manufacture the products. “Warranty Period” For the ARL516G Two Years. Warranty period is from original purchase date, no extension is made in the event of warranty replacement products supplied or time spent being repaired.
