µ-Dimension Oliver Occasional Chair 1184 Assembly Instructions

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
!
Assistance is required to assemble this chair.
!
Never stand on the chair or use it as a ladder.
!
Do not tip the chair when seated.
!
Periodically re-tighten all bolts and legs.
!
Do not exceed 250 lbs. (113.4 kg) weight limit on the chair.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance before moving furniture.
#1184 Oliver Occasional Chair
Assembly Instructions
Give us a chance to make it right.
Do not return this item to the store. Contact our friendly customer
service department with any
for missing or damaged parts are normally shipped the same day!
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#1184 Oliver Occasional Chair
problems or comments
. Replacements
Page 1
