µ-Dimension 1025 Assembly Instructions

Armless tufted chair

Advertisement

Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
Assistance is required to assemble this chair.
!
Never stand on the chair or use it as a ladder.
!
Do not tip the chair when seated.
!
!
Periodically re-tighten all bolts and legs.
Do not exceed 250 lbs. (113.4 kg) weight limit on the chair.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance before moving furniture.
!
#1025 Armless Tufted Chair
Assembly Instructions
Give us a chance to make it right.
Do not return this item to the store. Contact our friendly customer
service department with any
for missing or damaged parts are normally shipped the same day!
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#1025 Armless Tufted Chair
problems or comments
. Replacements
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1025 and is the answer not in the manual?

Questions and answers

Summary of Contents for µ-Dimension 1025

  • Page 1 #1025 Armless Tufted Chair Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right. Do not return this item to the store. Contact our friendly customer...
  • Page 2 #1025 Armless Tufted Chair Assembly Instructions PARTS LIST Part Drawing Part Name Qty. Part Drawing Part Name Qty. Right Back Leg Chair Body Bolt with Left Front Leg Washers Allen Right Front Leg Wrench Left Back Leg Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
  • Page 3 #1025 Armless Tufted Chair Assembly Instructions Step 2 - Lay the Chair Body (Part A) on a flat surface like shown below. Pull the Velcro® attached dust cover on the bottom of the seat back to expose the inner frame. Insert the Left Front Leg (Part B), Right Front Leg (Part C), Left Back Leg (Part D) and Right Back Leg (Part E) into the corresponding notches in the Chair Body frame.
