µ-Dimension 1706 Assembly Instructions

Oval back settee

Thank you for purchasing our fine product!

This package contains all tools necessary for assembly.

WARNING

: Failure to follow these directions and warnings can result in serious injury

and/or product damage.

Assistance is required to assemble this settee.

Never stand on the settee or use it as a ladder.

Do not tip the settee when seated.

Periodically re-tighten all bolts and legs.

Do not exceed 250 lbs. (113.4 kg) weight limit on the settee.

If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.

Always seek assistance before moving furniture.

#1706 Oval Back Settee

Assembly Instructions

Give us a chance to make it right.

Do not return this item to the store. Contact our friendly customer

service department with any

for missing or damaged parts are normally shipped the same day!

TOLL FREE: 1-866-528-8364

Monday - Friday, 8am-5pm, ET. After business hours, leave a message.

We will return your call the next business day.

#1706 Oval Back Settee

problems or comments

Furniture

. Replacements

Page 1

Table of Contents

Need help?

Do you have a question about the 1706 and is the answer not in the manual?

Page 1 #1706 Oval Back Settee Assembly Instructions Furniture Furniture Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right. Do not return this item to the store. Contact our friendly customer...
Page 2 #1706 Oval Back Settee Assembly Instructions PARTS LIST Part Drawing Part Name Qty. Part Drawing Part Name Qty. Allen Back Wrench Long Bolt Seat with Washers Short Bolt Left Arm Wood Plug Right Arm Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
Page 3 #1706 Oval Back Settee Assembly Instructions Step 2 - Lay the Settee Back (Part A) on a flat surface. Align the bolt holes in the back of the Settee Seat (Part B) with the bolt holes in the front of the Settee Back. Insert five Long Bolts with Washers (Part F) clockwise through the seat and into the Settee Back.
Page 4 #1706 Oval Back Settee Assembly Instructions Step 4 - With help, turn Settee upright. Align the bolt holes in the end of the Settee Left Arm (Part C) with the bolt holes in the side of the Settee Back (Part A). Insert a...
