µ-Dimension 1508 Assembly Instructions

Arm chair

Table of Contents

Download this manual

Thank you for purchasing our fine product!

This package contains all tools necessary for assembly.

WARNING

: Failure to follow these directions and warnings can result in serious injury

and/or product damage.

Assistance is required to assemble this chair.

Never stand on the chair or use it as a ladder.

Do not tip the chair when seated.

Periodically re-tighten all bolts and legs.

Do not exceed 250 lbs. (113.4 kg) weight limit on the chair.

If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.

Always seek assistance before moving furniture.

#1508 Arm Chair

Assembly Instructions

Give us a chance to make it right.

Do not return this item to the store. Contact our friendly customer

service department with any

for missing or damaged parts are normally shipped the same day!

TOLL FREE: 1-866-528-8364

Monday - Friday, 8am-5pm, ET. After business hours, leave a message.

We will return your call the next business day.

#1508 Arm Chair

problems or comments

. Replacements

Page 1

Table of Contents

Need help?

Do you have a question about the 1508 and is the answer not in the manual?

Page 1 #1508 Arm Chair Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right. Do not return this item to the store. Contact our friendly customer...
Page 2 #1508 Arm Chair Assembly Instructions PARTS LIST Part Drawing Part Name Qty. Part Drawing Part Name Qty. Long Bolt Back with Washers Medium Bolt Seat with Washers Short Bolt Right Arm with Washers Allen Wrench Left Arm Front Leg Wood Plug Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
Page 3 #1508 Arm Chair Assembly Instructions Step 2 - Lay the Seat (Part B) on a flat surface. Align the bolt holes in the front corner of the Seat and the bolt holes in the Front Legs (Part E). Hand thread four Medium Bolts with Washers (Part G) through the Seat and into the Front Legs.
Page 4 #1508 Arm Chair Assembly Instructions Step 4 - Align the the bolts holes in the Right Arm (Part C) with the bolts holes in right side of the Seat (Part B). Insert a Short Bolt with Washers (Part H) clockwise through the Seat and into the Arm.
Page 5 #1508 Arm Chair Assembly Instructions Step 6 - Fully tighten all the bolts inserted in steps 3 and 4 using the Allen Wrench (Part I) . Do not over tighten the bolts. Step 7 - Insert two Wood Plugs (Part J) into the bolt holes in the back-side of the Back (Part A).
