Part
Drawing
A
C
E
G
Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed
above. If any parts are damaged or missing, please call our Customer Service Department at 1-866-
528-8364.
#107 Chair
Assembly Instructions
PARTS LIST
Part Name Qty. Part
SEAT
1
CUSHION
1
RIGHT
FRONT
LEG
1
LEFT
LONG
4
BOLT
DOWEL
1
Step 2 - Insert the Dowel (Part G) into the top-
center hole in the back of the Seat Cushion (Part
A).
F - Short Bolt
Step 3 - Lay the Back Cushion (Part B) on a soft,
flat surface such as a carpeted floor and align the
dowel in the Seat Cushion with the top-center hole
in the Back Cushion.
Step 4 - Insert one Short Bolt (Part F) into each of
the three holes at the rear of the Seat Cushion.
Thread the bolts clockwise by hand. Do not
tighten the Bolts at this time.
G - Dowel
Give us a chance to make it right.
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET.
Drawing
B
D
F
H
Part Name Qty.
BACK
1
CUSHION
PILLOW
1
SHORT
7
BOLT
ALLEN
1
WRENCH
Page 2
Advertisement
Table of Contents
Related Manuals for µ-Dimension Chair 107
Summary of Contents for µ-Dimension Chair 107
- Page 1 #107 Chair Assembly Instructions PARTS LIST Part Name Qty. Part Part Drawing Drawing Part Name Qty. SEAT BACK CUSHION CUSHION RIGHT FRONT PILLOW LEFT LONG SHORT BOLT BOLT ALLEN DOWEL WRENCH Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
- Page 2 #107 Chair Assembly Instructions Step 5 - Insert one Long Bolt (Part E) through each of the four holes in the corner blocks located on the E - Long Bolt underside of the Seat Cushion frame. Thread the Long Bolts clockwise by hand. Step 6 - Once all seven bolts have been hand threaded, fully tighten them using the Allen Wrench (Part H).
- Page 3 #107 Chair Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right. Do not return this item to the store. Contact our friendly customer service department with any problems or comments .
