Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
!
Assistance is required to assemble this table.
!
Never stand on the table or use it as a ladder.
!
Do not place hot items directly on the table.
!
Periodically re-tighten all bolts and legs.
!
Do not esceed 100 lbs .(45.4kg) weight limit on the table.
!
If any parts become missing, damaged or worn,discontinue use until they are replaced with identical
!
Always seek assistance before moving fumiture.
#8514 Tray Table
Assembly Instructions
Give us a chance to make it right.
Do not return this item to the store. Contact our friendly customer
service department with any
for missing or damaged parts are normally shipped the same day!
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#8514 Tray Table
problems or comments
. Replacements
Page 1
Advertisement
Table of Contents
Related Manuals for µ-Dimension 8514
Summary of Contents for µ-Dimension 8514
- Page 1 #8514 Tray Table Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right. Do not return this item to the store. Contact our friendly customer...
- Page 2 #8514 Tray Table Assembly Instructions PARTS LIST Part Drawing Part Name Qty. Part Drawing Part Name Qty. Bolt with Top Tray Washer Top Frame Bolt Allen Base Wrench Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above.
- Page 3 #8514 Tray Table Assembly Instructions Step 2 - With help, align the bolt holes in the Base (Part C) with the bolt holes in the Legs (Part D). Insert four Bolts with Washers (Part E) clockwise through the Base and into the Legs. Do not fully tighten the bolts at this time.
- Page 4 #8514 Tray Table Assembly Instructions Step 4 - Fully tighten all of the bolts inserted in steps 2 and 3. Do not over tighten the bolts. Step 5 - Place the Top Tray (Part A) onto the tray lip on the assembled frame.
