SICK VISIC100SF Operating Instructions Manual
  1. Manuals
  2. Brands
  3. SICK Manuals
  4. Accessories
  5. VISIC100SF
  6. Operating instructions manual

SICK VISIC100SF Operating Instructions Manual

Tunnel air quality sensors
Hide thumbs Also See for VISIC100SF:
Table of Contents

Advertisement

Quick Links

Download this manual
Title Page
MMMOPERATING INSTRUCTIONS
MMMI
O P E R A T I N G I N S T R U C T I O N S
VISIC100SF
Tunnel Air Quality Sensors

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISIC100SF and is the answer not in the manual?

Questions and answers

Related Manuals for SICK VISIC100SF

Summary of Contents for SICK VISIC100SF

  • Page 1 Title Page MMMOPERATING INSTRUCTIONS MMMI O P E R A T I N G I N S T R U C T I O N S VISIC100SF Tunnel Air Quality Sensors...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...
  • Page 3 8017171/194 V/V4-0/2022-09| SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 4: Table Of Contents

    3.6.3 VISIC100SF connections with TAD control unit ..............36 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...
  • Page 5 Setting the RS-485 interface with submenu item “Bus” ............56 8017171/194 V/V4-0/2022-09| SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 6 7.8.4 Testing the “Maintenance Request” relay with submenu item “Maintenance Req.” ... 80 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...
  • Page 7 Declaration of Conformity ......................97 11.2 Dimensions ...............................98 11.3 Technical Data ............................103 8017171/194 V/V4-0/2022-09| SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 8: Important Information

    Must be available for reference. ● Must be conveyed to new owners. ● O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 9: Intended Use

    Generally in applications similar to tunnels for measuring visibility and gas ● concentrations 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 10: Product Description

    - Connection unit and/or TAD - Fog dissipation: Version with heating O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 11: Device Versions

     Electrical screw fitting for cable (6 ... 12 mm)  Connection for functional grounding 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 12: Optional Equipment

    Fig. 3: “Gas sensor type plate” O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...
  • Page 13 Ready-made connection cables are available for both variants. (Further details on connection cables, see “Installation material”, page 20). 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 14  4 x 6 ... 12 mm (M20 x 1.5)  1 x 5 ... 10 mm (M16 x 1.5) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 15 RTU is not available when a TAD control unit is used. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 16: Measuring Principle

    The enclosure cover can be held on the rear enclosure panel for maintenance purposes. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 17  Wiring block for 24 V and signals  Reset button  Display with keypad 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 18  Threads for gas sensors  Cable glands  Bracket for enclosure cover O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 19: Interfaces

    ® RTU (integrated in the VISIC100SF standard version)”, page 39 see “Modbus 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 20: Mounting And Electrical Installation

    Connection VISIC100SF to connection unit, TAD control unit or tunnel control room. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 21: Preparing The Installation Location

    “Maximum allowable angle of rotation of fitted VISIC100SF”, page 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 22: Mounting

    Use a wall plate when the installation walls are extremely uneven. Consider this special solution during project planning. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 23 Carefully fold the measuring unit open. The cable connections can cause the hinge fixture to unhook from the hinge rail. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 24: Mounting The Connection Unit (Optional)

    “Connection unit wiring”, page 6 Screw the cover on. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 25: Mounting The Tad Control Unit (Optional)

    – Digits 1 and 2: Year of production – Digits 3 and 4: Week of production 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 26 Do not screw the screw plugs in again after fitting the gas sensors. Otherwise, no sample gas can reach the electrochemical cells. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 27 100% < 10% 100% < 2% < 10% (100%) 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 28: Visic100Sf Wiring

    The main power switch is marked as disconnecting device. ● O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 29: Connecting The Led

    Switch position: Off (LED switched off) On (LED switched on) 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 30 Fig. 22: Grounding connection on VISIC100SF  Connection to fasten the functional grounding O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 31: Wiring Of Analog Outputs, Relay Outputs And Voltage Supply

    “Assigning analog outputs with menu item “IOMap””, page 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 32: Bus Interface Wiring

    The cable shield only serves to shield against high-frequency interference and may not be used as potential equalization. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 33  Connection for grounding conductor  T-connector or connection unit terminal 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 34: Connection Unit Wiring

    Observe the configuration of the analog outputs when using gas sensors, “Assigning analog outputs with menu item “IOMap””, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 35: Tad Control Unit Wiring

    Observe the configuration of the analog outputs when using gas sensors, “Activating/deactivating the heating (optional)”, page 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 36: Connections

    5 Voltage supply (230 V) 6 Analog and digital signals or data bus O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 37: Commissioning

    “Activating maintenance in menu item “Maint””, page 53 for further information. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 38 95 see “Description of maintenance requests”, page 96 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 39: Bus Connections

    19.2 k ● 38.4 k ● 57.6 k ● 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 40: Read Holding Register (0X03)

    RX-> <65 03 04 3F 48 2B 67 0C ED> Current K-value = 0x3F482B67 ≈ 0.78 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 41: Modbus ® Rtu Read Coil (0X01)

    “Measuring unit - circuit board with display and keypad”, page 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 42: Profibus Dp-V0 Baud Rates

    The GSD file is delivered on a data medium when the PROFIBUS module is ordered. It is also available as download on SICK's homepage. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 43: Coding Of Visibility Measured Value Status

    [1] When the TAD control unit is used with I/O modules 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 44: Rs-485 - Topology And Bus Termination

    If there are more than 32 nodes or the network span is being extended, power amplifiers (repeaters) allow linking the networks. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 45 Shielded cable type A is a twisted two-wire cable. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 46: Operation

    Fig. 32: Position of Reset button and “Maint” LED on circuit board  Maintenance LED  Reset button O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 47: Display Unit In The Tad Control Unit

    “Checking the operating state (visual control)”, page 5.5.1 Malfunction messages see “Device error coding”, page 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 48: Maintenance Request Messages

    Maintenance request messages see “Description of maintenance requests”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 49: Visic100Sf Menu Navigation

    Example of an input field with a blinking digit to be edited: 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 50: Measuring Operation Mode "Run

    K-value but as μg. The transmitted measuring range in μg is 0 to 1500μg. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 51: Set" Mode

    The device switches automatically to “RUN” mode when no user action is registered for 10 minutes. The background lighting goes off. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 52: Structure And Sequence Of "Set" Mode Submenu Items

    Activate/deactivate heating for fog dissipation (optional). 12 “Tuning” Adjustment menu O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 53: Activating Maintenance In Menu Item "Maint

    NxtMRq= Next Maintenance Request (time remaining to next maintenance request). xxxxxd = number of days 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 54: Calling-Up The Operating Duration In Submenu Item "Uptime

    Fig. 37: Calling up the operating duration Maint XXXXXd Uptime XXXXXd XXXXXd XXXXXh XXXXXd O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 55: Calling Up The Software Version In Submenu Item "Swvers

    SwVers The software version is output as ticker text. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 56: Connecting The Bus Systems

    A second RS-485 interface is firmly assigned to an optional PROFIBUS module, “PROFIBUS DP-V0 (optional)”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 57: Setting Bus Parameters

    When the bus address has been entered completely, pressing “Set” switches the menu back directly to the “Bus” main menu. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 58: Setting The Modbus ® Address In "Mb Id

    MB Par Even No 2 SB No 1 SB O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 59: Setting The Modbus Baud Rate With Menu Item "Mb Bdr

    All “Bus” settings are first saved after a VISIC100SF restart. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 60: Testing Digital/Analog Outputs And Gas Sensors

    30 minutes, the VISIC100SF switches back automatically to measuring mode, “Activating the setting range via menu item “Maint””, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 61 Fig. 47: Setting the output current for AO4 (factory setting: AO4 = temperature measurement) Maint Test 12mA 20mA 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 62 Fig. 49: Setting and testing the device malfunction relay Maint Test Fail active inact. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 63: Assigning Analog Outputs With Menu Item "Iomap

    Fig. 50: Assigning analog outputs Maint k/µg IOMap Temp 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 64: Scaling Analog Outputs

    Fig. 51: Setting the scaling values for the analog outputs Maint 1. - 3. k/µg AOscl O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 65: Output Visibility As "K-Value" Or "Μg

    Fig. 53: Activating/deactivating the external temperature sensor Maint Temp inact. active 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 66: Activating/Deactivating The Heating (Optional)

    The test takes 2 seconds. Afterwards the display shows for 1 second whether the test was successful (”ok”) or not successful (“Fail”). O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 67: Tad Control Unit Menu Navigation

    The message “Warmup” is shown in the status bar in the heating up phase. ● 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 68: Operating Elements

    A MRq code is active on at least one sensor. REQUEST O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 69: Function Buttons

    Move cursor to the right Table 18: Possible function button functions 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 70: Starting Operation

    Wait for FAILURE communication MAINTENANCE REQUEST 9172014 #YBR3 Mode MEAS O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 71: Measuring Screen

    The list display is automatically displayed after switching on. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 72: Displaying The Main Menu

    Password input, see “Changing numerical parameters (password input)”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 73: Setting The Display Contrast

    4 To abort the process: Select “Back”. The password 1234 is predefined at the factory. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 74: Activating Maintenance Mode

    Maintenance mode is terminated by setting the maintenance signal to “Off” or restarting the device. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 75: Main Menu Item "Diagnosis

    Test” will not be displayed under menu item 2 “Diagnosis”. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 76: Maintenance Requests Of Gas Sensors: "Next Maintenance

    Only installed gas sensors will be displayed. ● O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 77: Retrieving Device Information With "Device Info

    The status of the peripheral equipment cannot be changed in this menu item. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 78: Error Messages/Maintenance Requests With "Messages

    Table for explanation of specified codes under Maintenance request, see “Description of maintenance requests”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 79: Testing Digital/Analog Outputs

    “Activating the setting range via menu item “Maint””, page 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 80: Testing The Analog Outputs Ao2 - Ao4

    74 ▸ password prompt before setting the values. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 81: Scaling Analog Outputs With Menu Item "Scale Ao

    Enter the required value. ▸ Save the value with “Save”. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 82: Assigning Analog Outputs "Ao Mapping

    /Para/ /Para/MapAO/AO3 /Para/MapAO/ Back Enter Back Enter Back Save O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 83: Setting The Profibus Address In "Profibus Id

    NOTE: The new address is only active after a system restart. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 84: Conversion Visibility/Dust Concentration With Menu Item "Conversion Μg

    Enter the required value. ▸ Use “Save” to save the value. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 85: Activating/Deactivating Temperature Measurement With Menu Item "Temp

    5 Conv. to µg 6 Temp. /Para/ /Para/Temp/ Enter Back Back Enter 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 86: Shutdown

    Pay attention to the storage conditions for the measuring unit, the TAD control unit and the gas sensors. ▸ Store gas sensors airtight. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 87: Transport

    Never open the enclosures of the gas sensors during disposal. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 88: Maintenance

    Before starting any maintenance work on the device, make sure that all tunnel- specific safety precautions have been taken. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 89: Maintenance

    One test tool in value range k = 7 ... 15/ km (test set, Part No. 2071541) ● 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 90 Fig. 89: Open VISIC100SF without gas sensors 4 Switch to Maintenance mode via the display: O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 91 5 Replace the measuring unit or send it to SICK for repair. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 92 Recalibration of gas sensors Gas sensors can be recalibrated with the optional gas adjustment kit PN: 2125690. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 93: Maintenance Plan

    – Electrochemical cells 3 Unhinge the defective measuring unit. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 94: Spare Parts

    The standard enclosure cover and enclosure cover with heating cannot be swapped onsite. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...

  • Page 95: Clearing Malfunctions

    The status is always shown in plain text on the basis display. 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 96: Description Of Maintenance Requests

    O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 97: Specifications

    ● EN 50271 ● 11.1.3 Declaration of Conformity ● 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 98: Dimensions

    Dimensions Fig. 93: VISIC100SF dimensions (all units of measurement in mm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...
  • Page 99 Fig. 94: Control unit dimensions (all units of measurement in mm) Shown with the door open 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 100 Fig. 96: Dimensions of control unit for VISIC100SF (all units of measurement in mm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...
  • Page 101 Fig. 97: Drilling plan of control unit for VISIC100SF (all units of measurement in mm) 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 102 Fig. 98: Drilling plan for TAD control unit for VISIC100SF (all units of measurement in mm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK...

  • Page 103: Technical Data

    Integrated: Modbus ® ● Bus protocol Optional: PROFIBUS DP-V0 ● 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 104 Temperature class A: -40… +85 °C Cross-section: 3 x 1.5 mm O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/194 V/V4-0/2022-09| SICK Subject to change without notice...
  • Page 105 Input Impedance: 3 kOhm Overvoltage Protection: ± 35 V DC 8017171/194 V/V4-0/2022-09/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 106 Phone +7 495 283 09 90 E-Mail info@sick.com E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com...
