Summary of Contents for SICK VISIC100SF

  • Page 1 Title Page MMMOPERATING INSTRUCTIONS MMMI O P E R A T I N G I N S T R U C T I O N S VISIC100SF Tunnel Air Quality Sensors...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...
  • Page 3 Supplementary information Link to information at another place 8017171/115Z/V3-0/2019-01| SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 4: Table Of Contents

    VISIC100SF with terminal box ....................36 3.6.3 VISIC100SF connections with TAD control unit ..............36 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...
  • Page 5 Setting the Modbus baud rate with menu item “MB BdR”.............59 8017171/115Z/V3-0/2019-01| SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 6 6.8.4 Testing the “Maintenance Request” relay with submenu item “Maintenance Req.” ... 80 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...
  • Page 7 Declaration of Conformity ......................97 10.2 Dimensions ...............................98 10.3 Technical Data ............................103 8017171/115Z/V3-0/2019-01| SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 8: Important Information

    Must be available for reference. ● Must be conveyed to new owners. ● O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 9: Intended Use

    Generally in applications similar to tunnels for measuring visibility and gas ● concentrations 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 10: Product Description

    - Terminal box and/or TAD - Fog dissipation: Version with heating O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 11: Device Versions

     Electrical screw connection for cable (6 ... 12 mm)  Connection for functional grounding 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 12: Optional Equipment

    The measured component is printed clearly visible from all sides. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 13 Ready-made connection cables are available for both variants. (Further details on connection cables, see “Installation material”, page 20). 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 14  4 x 6 ... 12 mm (M20 x 1.5)  1 x 5 ... 10 mm (M16 x 1.5) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 15 Modbus-RTU is not available when a TAD control unit is used. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 16: Measuring Principle

     Measuring unit The enclosure cover can be held on the rear enclosure panel for maintenance purposes. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 17  Wiring block for 24 V and signals  Reset button  Display with keypad 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 18  Threads for gas sensors  Cable glands  Bracket for enclosure cover O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 19: Interfaces

    Modbus-RTU interface characteristics see “Modbus-RTU (integrated in the VISIC100SF standard version)”, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 20: Installation

    Connection VISIC100SF to terminal box, TAD control unit or tunnel control room. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 21: Preparing The Installation Location

    “Maximum allowable angle of inclination of fitted VISIC100SF”, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 22: Assembly

    Use a wall plate when the installation walls are extremely uneven. Consider this special solution during project planning. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 23 Carefully fold the measuring unit open. The cable connections can cause the hinge fixture to unhook from the hinge rail. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 24: Fitting The Terminal Box (Optional)

    “Terminal box wiring”, page 6 Screw the cover on. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 25: Installing The Tad Control Unit (Optional)

    3 Use the SW 8 Allen key to remove the black screw plug on the underside of the enclosure. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 26  Connection cables of gas sensors  Connection socket for connection cables of gas sensors O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 27 (10 ppm) (5000 ppm) (18 ppm) (100 ppm) < 15% 100% 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 28: Visic100Sf Wiring

    The main power switch is marked as disconnecting device. ● O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 29: Connecting The Led

    Switch position: Off (LED switched off) On (LED switched on) 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 30 Fig. 22: Grounding connection on VISIC100SF  Connection to fasten the functional grounding O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 31: Wiring Of Analog Outputs, Relay Outputs And Voltage Supply

    Observe the assignment of analog outputs for output of NO or temperature values, “Activating/deactivating the heating (optional)”, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 32: Bus Interface Wiring

    Fig. 25: Shielding in VISIC100SF Line shield  Cable gland with wires  O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...
  • Page 33  Connection for grounding cable  T-connector or terminal box 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 34: Terminal Box Wiring

    Observe the configuration of the analog outputs when using gas sensors, see “Activat- ing/deactivating the heating (optional)”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 35: Tad Control Unit Wiring

    Observe the configuration of the analog outputs when using gas sensors, see “Activat- ing/deactivating the heating (optional)”, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 36: Connections

     Power supply (230 V)  Analog and digital signals or data bus O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 37: Start-Up

    “Activating maintenance in menu item “Maint””, page 53 for further information. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 38 95 see “Description of maintenance requests”, page 96 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 39: Bus Connections

    ● 19.2 k ● 38.4 k ● 57.6 k ● 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 40 RX-> <65 03 04 3F 48 2B 67 0C ED> Current K-value = 0x3F482B67 ≈ 0.78 O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 41: Profibus Dp-V0 (Optional)

    “Measuring unit - circuit board with display and keypad”, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 42 The GSD file is delivered on a CD when the PROFIBUS module is ordered. It is also available as download on SICK's homepage. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 43 No cell present 0x23 Bad - passivated Inactive Inactive 1 mA 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 44: Rs-485 - Topology And Bus Termination

    If there are more than 32 nodes or the network span is being extended, power amplifiers (repeaters) allow linking the networks. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 45 Shielded cable type A is a twisted two-wire cable. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 46: Operation

    Fig. 32: Position of Reset button and “Maint” LED on circuit board  Maintenance LED  Reset button O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 47: Display Unit In The Tad Control Unit

    “Checking the operating state (visual control)”, page 4.5.1 Malfunction messages see “Device error coding”, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 48: Maintenance Request Messages

    4.5.2 Maintenance request messages see “Description of maintenance requests”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 49: Visic100Sf Menu Navigation

    Example of an input field with a blinking digit to be edited: 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 50: Measuring Operation Mode "Run

    K-value but as μg. The transmitted measuring range in μg is 0 to 1500μg. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 51: Set" Mode

    The device switches automatically to “RUN” mode when no user action is registered for 10 minutes. The background lighting goes off. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 52: Structure And Sequence Of "Set" Mode Submenu Items

    Activate/deactivate heating for fog dissipation (optional) 11 “Tuning” Tuning menu O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 53: Activating Maintenance In Menu Item "Maint

    NxtMRq= Next Maintenance Request (time remaining to next maintenance request). xxxxxd = number of days 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 54: Calling-Up The Operating Duration In Submenu Item "Uptime

    Fig. 37: Calling up the operating duration Maint XXXXXd Uptime XXXXXd XXXXXd XXXXXh XXXXXd O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 55: Calling Up The Software Version In Submenu Item "Swvers

    9xxxxxx_xx SwVers The software version is output as ticker text. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 56: Connecting The Bus Systems

    A second RS-485 interface is firmly assigned to an optional PROFIBUS module, “PROFIBUS DP-V0 (optional)”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 57: Setting Bus Parameters

    When the bus address has been entered completely, pressing “Set” switches the menu back directly to the “Bus” main menu. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 58: Setting The Modbus Address In "Mb Id

    MB ID MB Par Even No 2 SB No 1 SB O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 59: Setting The Modbus Baud Rate With Menu Item "Mb Bdr

    All “Bus” settings are first saved after a VISIC100SF restart. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 60: Testing Digital/Analog Outputs And Gas Sensors

    “Acti- vating the setting range via menu item “Maint””, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 61: Testing The Analog Outputs For The Gas Sensors

    Fig. 47: Setting the output current for AO4 (factory setting: AO4 = temperature measurement) Maint Test 12mA 20mA 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 62: Testing The "Maintenance Request" Relay With Submenu Item "Mrq

    Fig. 49: Setting and testing the device malfunction relay Maint Test Fail active inact. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 63: Assigning Analog Outputs With Menu Item "Iomap

    SICK Service technicians only. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 64: Displaying Visibility As "K-Value" Or "Μg

    Fig. 52: Activating/deactivating the external temperature sensor Maint Temp inact. active O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 65: Activating/Deactivating The Heating (Optional)

    The heating is always activated when the measuring unit (2071119) is delivered as spare part. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 66: Device Adjustment Using Submenu Item "Tuning

    The test takes 2 seconds. Afterwards the display shows for 1 second whether the test was successful (”ok”) or not successful (“Fail”). O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 67: Menu Navigation Tad Control Unit

    The message “Warmup” is shown in the status bar in the heating up phase. ● 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 68: Operating Elements

    A MRq code is active on at least one sensor. REQUEST O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 69: Function Buttons

    Move cursor to the right Table 19: Possible function button functions 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 70: Starting Operation

    Wait for FAILURE communication MAINTENANCE REQUEST 9172014 #YBR3 Mode MEAS O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 71: Measuring Screen

    The list display is automatically displayed after switching on. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 72: Displaying The Main Menu

    ● Password input, see “Changing numerical parameters (password input)”, page O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 73: Setting The Display Contrast

    4 To abort the process: Select “Back”. The password 1234 is predefined at the factory. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 74: Activating Maintenance Mode

    Maintenance mode is terminated by setting the maintenance signal to “Off” or restarting the device. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 75: Main Menu Item "Diagnosis

    Test” will not be displayed under menu item 2 “Diagnosis”. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 76: Maintenance Requests Of Gas Sensors: "Next Maintenance

    Only installed gas sensors will be displayed. ● O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 77: Retrieving Device Information With "Device Info

    The status of the peripheral equipment cannot be changed in this menu item. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 78: Error Messages/Maintenance Requests With "Messages

    The performance of the tests and extension of the operating hours are described in the Service Manual. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 79: Testing Digital/Analog Outputs

    VISIC100SF switches back automatically to measuring mode after 30 minutes, “Activating the setting range via menu item “Maint””, page 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 80: Testing The Analog Outputs Ao2 - Ao4

    “Activating Maintenance mode”, page 74 ▸ password prompt before setting the values. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 81: Scaling Analog Outputs With Menu Item "Scale Ao

    Enter the required value. ▸ Save the value with “Save”. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 82: Assigning Analog Outputs "Ao Mapping

    4 AO4 /Para/ /Para/MapAO/AO3 /Para/MapAO/ Enter Back Save Enter Back Back O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 83: Setting The Profibus Address In "Profibus Id

    NOTE: The new address is only active after a system restart. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 84: Conversion Visibility/Dust Concentration With Menu Item "Conversion Μg

    Enter the required value. ▸ Use “Save” to save the value. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 85: Activating/Deactivating Temperature Measurement With Menu Item "Temp

    5 Conv. to µg 6 Temp. /Para/ /Para/Temp/ Enter Back Back Enter 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 86: Shutdown

    Pay attention to the storage conditions for the measuring unit, the TAD control unit and the gas sensors. ▸ Store gas sensors airtight. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 87: Transport

    Never open the enclosures of the gas sensors during disposal. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 88: Maintenance

    Before starting any maintenance work on the device, make sure that all tunnel- specific safety precautions have been taken. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 89: Maintenance

    One test tool in value range k = 7 ... 15/ km (test set, Part No.2071541) ● 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 90 Fig. 88: Open VISIC100SF without gas sensors 4 Switch to Maintenance mode via the display: O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 91 5 Replace the measuring unit or send it to SICK for repair. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 92 Readjustment of gas sensors Gas sensors can be readjusted with the optional gas calibration case PN: 2080119. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 93: Maintenance Plan

    – LED plug – Electrochemical cells 3 Unhinge the defective measuring unit. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 94: Spare Parts

    The standard enclosure cover and enclosure cover with heating cannot be swapped onsite. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...

  • Page 95: Clearing Malfunctions

    The status is always shown in plain text on the basis display. 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 96: Description Of Maintenance Requests

    Master. O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 97: Specifications

    EN 50545 ● EN 50271 ● 10.1.3 Declaration of Conformity ● 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...

  • Page 98: Dimensions

    Dimensions Fig. 92: VISIC100SF dimensions (all units of measurement in mm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...
  • Page 99 Fig. 93: Tunnel Adapter Device dimension (all units of measurement in mm) Shown with the door open 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 100 Fig. 94: VISIC100SF drilling plan (all units of measurement in mm) Fig. 95: Terminal box for VISIC100SF dimensions (all units of measurement in mm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...
  • Page 101 Fig. 96: Drilling plan for terminal box for VISIC100SF (all units of measurement in mm) 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 102 Fig. 97: Drilling plan for TAD control unit for VISIC100SF (all units of measurement in mm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK...

  • Page 103: Technical Data

    2 x RS-485 Integrated: Modbus-RTU ● Bus protocol Optional: PROFIBUS DP-V0 ● 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 104 4 outputs: 4 ... 20 mA, electrically isolated (max. load Analog outputs 500 Ohm) O P E R A T I N G I N S T R U C T I O N S | VISIC100SF 8017171/115Z/V3-0/2019-01| SICK Subject to change without notice...
  • Page 105 Input Impedance: 3 kOhm Overvoltage Protection: ± 35 V DC 8017171/115Z/V3-0/2019-01/ SICK O P E R A T I N G I N S T R U C T I O N S | VISIC100SF Subject to change without notice...
  • Page 106 Phone +421 482 901 201 E-Mail ghk@sick.com.hk E-Mail mail@sick-sk.sk Hungary Slovenia Phone +36 1 371 2680 Phone +386 591 78849 E-Mail ertekesites@sick.hu E-Mail office@sick.si India South Africa Phone +91-22-6119 8900 Phone +27 (0)11 472 3733 Further locations at www.sick.com E-Mail info@sick-india.com E-Mail info@sickautomation.co.za...
