T9600
PARAMETER SETTING (PART 2/2)
T9600-
T9603-
T9601-
TF20-
T000-
TF20-
Code
1JS0
1JF0
1JS0
■
09
■
■
10
■
■
■
11
■
■
■
1
12
■
■
13
■
■
14
■
■
15
■
■
16
■
■
17
■
■
■
18
■
■
■
19
■
■
■
20
■
■
21
■
22
Note
• Terminal blocks changes depending on the application selected, check the table beside first
• The relay output are line voltage, they are connected with Terminal "L" internally
• The digital input "OCC" can assume different meaning depending on parameter 12 setting
• The T9603-T000-1JF0 does not feature the
button to scroll through the list. Under User Setting menu, press the
through the list.
1. T9603-T000-1JF0 BI Input default 04 Warning. Options: 00: Occupancy Input, 04: Warning
ALARM CODE DESCRIPTION
Item
Code
Description
1
E1
Internal sensor warning.
2
HI
High temperature warning. Room temperature >55°C (>131°F)
3
LO
Low temperature warning. Room temperature <0°C (<32°F) or internal sensor opened.
4
E5
Dew point risk warning. Valves and fan are shut off when error is active.
8
E6
Filter alarm
9
E7
BI warning
flashes when there is a communication error.
P/N 24-11447-00004 Rev. B Issue Date: 11 2020
T9600-
TF21-
1JS0
Parameter Name
ECM-MAX-V
STG-DFFR
■
HTRSS
■
BI-FUNCTION
■
MODE-RST
■
FAN-RST
■
FAN-DB
■
UNOCC-FAN
HTG-STG
■
BI-PLRT
■
OCC-OVRD
■
SNS-TYPE
■
FAN-DELAY
ECM-RLY
M
and
button. To access the User Setting parameter list, press the
Default
Function
ECM Max voltage.
Max voltage below which the fan output is 100%.
10 V
Step: 0.5 V
Range: 0 V~10 V
floor heater Stage temperature difference
3°C/5°F
Step: 0.5°C (1°F)
Range: 0°C~10°C (0°F-18°F)
Hysteresis for ON/OFF control
1°C/2°F
Range: 1~5
00: Occupancy Input
01: Dew Point Risk Input
02
02: Filter Alarm Input
03: Change Over Sensor Input
04: Warning
00: No Restriction
00
01: Cooling only
02: Heating only
00: No Fan
01: One Speed Fan
03
02: Two Speed Fan
03: Three Speed Fan
Fan operation in deadband:
01
00: OFF
01: Low
Fan mode in unoccupied:
00
00: OFF
01: Low
00: One Heating Stage - Fan Coil
02
01: One Heating Stage - Floor Heating
02: Two heating stage
BI polarity:
01
00: Normally Close
01: Normally Open
Override the OCC-S value:
00: No Override
00
01: Occupied
02: Unoccupied
00: JCI type 10K NTC
00
01: China type 10K NTC
00
Fan off delay after valve closed, in seconds(0-99 s)
00: Disable
00
01: Enable
button 5 s to access Service Setting parameter list. Press the
English
button 5 s instead. Press the
button to scroll
