Code No. LIT-12012271
Issued September 27, 2017
Owner
Owner
and Installation
Instructions
Digital Thermostat
with Humidity Control
,
,
s Manual
s Manual
model T9100
Commercial

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T9100 and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls T9100

Summary of Contents for Johnson Controls T9100

  • Page 1 T9100 Commercial Digital Thermostat with Humidity Control High Resolution Touch Screen Owner Owner s Manual s Manual and Installation Instructions Code No. LIT-12012271 Issued September 27, 2017...
  • Page 2 5.10. Firmware releases after rev. 5.10 may not be adequately depicted in this manual. Please refer to the appropriate website or contact your place of purchase to learn about changes to the thermostat after firmware release 5.10. T9100...
  • Page 3 Glossary of Terms Auto-Changeover: A mode in which the thermostat will turn on the heating or cooling based on room temperature demand. Cool Setpoint: The warmest temperature that the space should rise to before cooling is turned on (without regard to deadband). Deadband: The number of degrees the thermostat will wait, once a setpoint has been reached, before energizing heating or cooling.

  • Page 4: Table Of Contents

    Table of Contents GET TO KNOW YOUR THERMOSTAT Home Screen ....................1 Menu Screens .....................1 Dropdown Dashboard ................2 Care and use of your thermostat .............5 QUICK START Selecting your desired temperature and mode ........6 Using the Fan button ................6 Using the Override button ................7 Setting the time ..................9 Setting the date..................
  • Page 5 Table of Contents DISPLAY ....................23 Active Brightness ..................24 Idle Brightness ..................24 Night Dimmer ..................24 Maintenance .................... 25 PREFERENCES ..................26 User Interface Themes ................27 Custom Wallpaper ................... 27 Heat/Cool Indicator ................. 27 Sound Options ..................27 HUMIDITY ....................
  • Page 6 Table of Contents General Setup ..................42 Units (F or C) ..................42 Language ....................43 Smart Recovery On/Off ..............43 Installation Settings ................43 Heat & Cool Stages ................43 Heat & Cool Stages ................ 43 Compressor Stages ................. 43 Aux Heat Stages ................
  • Page 7 Making 4 Wires Work When 5 Wires Are Required ......77 Making 5 Wires Work When 6 Wires Are Required ......78 The T9100 Thermostat Backplate ............79 Explanation Of the Thermostat Dip Switches ........80 Sample Wiring Diagrams ................ 81 TROUBLESHOOTING ................

  • Page 8: Get To Know Your Thermostat

    Get To Know Your Thermostat Home Screen Indoor Humidity Reading Backlit Color Touch Screen Display Outdoor Temperature (If optional accessory is used Dropdown or connected to Skyport) Sensor Button Connectivity Symbol Table Connectivity Symbol Warmer Not connected Button to Wi-Fi SD Card Connected to local Slot...

  • Page 9: Dropdown Dashboard

    Get To Know Your Thermostat Dropdown Dashboard The Dropdown Dashboard displays temperature, humidity, and other readings. It will also show the high and low readings of the day. Dropdown Wi-Fi Dashboard Connection Button Connectivity Symbol Table Icon Not connected to Wi-Fi Connected to local access point w/IP address without...
  • Page 10 Get To Know Your Thermostat Dropdown Dashboard (The contents of your Dashboard may vary) Weather Display with forecast for the following 3 days (Skyport connection required for weather) Weather Display This page displays sensor information. Select ‘Onboard’ to view room temperature, and if equipped, humidity sensors that are...
  • Page 11 Get To Know Your Thermostat These 3 screens are for informational purposes only. Settings may not be changed from these screens. Thermostat Info Equipment Configuration Thermostat Outputs...

  • Page 12: Care And Use Of Your Thermostat

    Get To Know Your Thermostat Care and Use of Your Thermostat Pencils, pens and other sharp objects should never be used on your thermostat; these may damage your touch screen. Only use your finger tip to press the screen buttons. Use a soft, damp cloth to clean the screen.

  • Page 13: Quick Start

    Quick Start - Temperature, Modes and Fan Selecting Your Desired Temperature and Mode Press to adjust temperature Cool Setpoint The Heat or Cool Setpoint is Warmer Button the temperature the room has to reach before heating or cooling will turn off. Cooler Button Override...

  • Page 14: Using The Override Button

    Quick Start - Override Using the Override Button OVERRIDE NOTE: Override may only be used when the thermostat is set to Program RUN or Holiday ON modes. Override Unoccupied Operation - During programmed, unoccupied periods, pressing the OVERRIDE button will force the thermostat into Occupied 1 settings. When the OVERRIDE button is pressed, a timer screen will appear and allow the user to choose from 30 minutes to up to 4 hours of override time.
  • Page 15 Quick Start - Set Time & Date NOTE: When the thermostat is connected to the Skyport; the Time & Date are automatically synchronized to the Skyport Cloud, including automatic Daylight Savings adjustments. Set Time & Date Your time zone is selected in the Skyport web application. Set Current Time Use AM/PM - ON Set Current Date...

  • Page 16: Setting The Time

    Quick Start - Set Time & Date Setting the Time Press then MENU Press Set Time & Date Press Set Current Time (12:00 AM) hr + min + Press to set the current time. hr - min - Press when finished. BACK Choose Use AM/PM - ON...

  • Page 17: Setting The Date

    Quick Start - Set Time & Date Setting the Date Press Set Current Date 6/1/2013 Press to set the current month and year. Press the day on the calendar Press BACK when finished. Daylight Savings Setup Turn Daylight Savings Daylight Savings Time - OFF Time on or off.

  • Page 18: Connect To Wi-Fi

    Quick Start - Connect to Wi-Fi Connect to Wi-Fi (from initial start up) When power is connected to the thermostat and it has not been configured to connect to a Wi-Fi Access point, the following message appears: Wi-Fi Set Up No Wi-Fi access points are configured for your thermostat.

  • Page 19: • Wi Fi Setup

    Quick Start - Connect to Wi-Fi (from menus) MENU Press MENU Press DOWN Press Wi-Fi • Wi Fi Setup Press Wi-Fi Setup Select the access point from the list that you want to connect to. Enter the password for the Wi-Fi Access Point and press NEXT. Select automatic setup and press NEXT.
  • Page 20 Quick Start - Connect to Wi-Fi (from menus) Although there is more than one way to create a Skyport account, the steps below illustrate creation from a browser. If the thermostat is connected to the local Wi-Fi Access Point, but not yet joined to a Skyport account, you may join the thermostat to an account by doing the following: Select MENU from the thermostat’s home screen.
  • Page 21 Main Menu Buttons - Schedule Schedule View My Schedule Edit My Schedule Unoccupied Settings Mode (Auto) Auto Heat Cool Heat Setpoint (55˚) Cool Setpoint (85˚)

  • Page 22: View My Schedule

    Main Menu Buttons - Schedule This thermostat features up to 3 Occupied time periods per 24 hour day. Schedule View My Schedule Press a day of the week to view its settings. This may be repeated for each day. Edit My Schedule Press and select day(s) to program Select individual day(s) Select groups of day(s)

  • Page 23: Unoccupied Settings

    Main Menu Buttons - Schedule Edit My Schedule (Continued) Adjust Mode, Start Time, Stop Time, and Heat and Cool Setpoints to desired settings. The Time Period May also be Enabled or Disabled. Un-check the enabled box for Time Periods you don’t want to use. Press DONE when finished.

  • Page 24: Fan Settings

    Main Menu Buttons - Fan Settings Fan Settings Fan - Auto Who To Call For Service Occupied Fan State (Auto) Auto Fan Purge - OFF View Runtime Graphs Preoccupancy Purge Time (15 mins)

  • Page 25: Fan On/Auto

    Main Menu Buttons - Fan Settings The fan may be set to run continuously during Heat, Cool, Auto, and Occupied modes. A Preoccupancy Fan Purge Fan Settings schedule may also be set. Press to turn fan On to run continuously or Auto for fan to run only with heating or cooling.

  • Page 26: Screensaver

    Main Menu Buttons - Screensaver Screensaver Screensaver - OFF Who To Call For Service Screensaver Setup View Runtime Graphs Screensaver Turn On Delay Screensaver Type Slideshow Digital Clock Analog Clock Change Image After... Use Theme Images - Off Randomize Slideshow - Off Show Clock - OFF Home Screen Info - OFF Screensaver Preview...

  • Page 27: Screensaver Setup

    Main Menu Buttons - Screensaver The Screensaver allows you to create custom slideshows. Screensaver Screensaver - OFF Screensaver - ON Screensaver Setup Screensaver Turn On Delay (5m) How long after a button press for the Screensaver to appear. 1, 3, 5, or 30 minutes Screensaver Type (Slideshow) Slideshow, Digital Clock, Analog Clock...

  • Page 28: Alerts

    Main Menu Buttons - Alerts Alerts View Current Alerts Reset Alerts Reset Air Filter Alert Reset UV Lamp Alert Reset Humidity Pad Alert Set/Edit Reminders Service Call - OFF Days Until Service Call (360 days) Air Filter Reminder - OFF Set Max Filter Runtime (500 hrs) Set Max Filter Days...

  • Page 29: View Current Alerts

    Main Menu Buttons - Alerts The alerts let you know when your system needs service. Alerts View Current Alerts View and reset current service alerts here. Alerts appear on the Press to view and bottom bar of the reset current alerts. Home Screen.

  • Page 30: Display

    Main Menu Buttons - Display Display Active Brightness Idle Brightness Night Dimmer Auto Night Dimmer - OFF Set Idle Brightness Set Dimmer Schedule Maintenance Screen Cleaning Touch Calibration...

  • Page 31: Active Brightness

    Main Menu Buttons - Display The display brightness options may be adjusted in this menu. Display Active Brightness (80%) You may select how bright the backlight is while the thermostat is active. The display is active for 3 minutes after last touch, it then goes idle. Idle Brightness (30%) You may select how bright the backlight is while the thermostat is idle.

  • Page 32: Maintenance

    Main Menu Buttons - Display Maintenance Maintenance allows you to clean and calibrate the touch screen. Screen Cleaning Screen Cleaning Mode disables the touch feature for 15 seconds so the screen may be cleaned without altering any settings. Use a soft cloth without solvents or abrasive cleaners. Touch Calibration Under normal circumstances, the touch screen should not need to be calibrated.

  • Page 33: Preferences

    Main Menu Buttons - Preferences Preferences User Interface Themes Custom Wallpaper Heat/Cool Indicator Heat/Cool Indicator OFF Taskbar red/white OFF Room Temp red/blue OFF Mode Status red/blue OFF Sound Options Beep - OFF Beep Sound...

  • Page 34: User Interface Themes

    Main Menu Buttons - Preferences You may set the type of background that appears on the thermostat Home Screen. Preferences User Interface Themes (Buildings) This thermostat has several high quality background themes to choose from. NOTE: At 7 PM, the background will change to an evening scene. At 7 AM it will return to a daytime scene.

  • Page 35: Humidity

    Main Menu Buttons - Humidity Humidity Humidification Settings Humidify setpoint (0%) Humidify with heat - OFF Run fan w/humidity demand - OFF Dehumidification Settings Dehumidity setpoint (99%) Run A/C to dehumidify - OFF Maximum Overcool (0°) Reheat - OFF Dehumidify only when cooling - ON...

  • Page 36: Humidification Settings

    Main Menu Buttons - Humidity The Humidity feature allows the thermostat to control a humidifier or use your air conditioner to dehumidify the space. Humidity IMPORTANT: Aux Output Usage must be set for Hum or Dehum for these settings to take effect. See: AUX Output Settings on page 60.

  • Page 37: Holidays

    Main Menu Buttons - Holidays Holidays Holiday Schedule - OFF Edit Holidays Preset Holidays...

  • Page 38: Holiday Schedule On/Off

    Main Menu Buttons - Holidays The Holiday Schedule allows the Color Touch Screen to follow a fully customizable preset, weekly, monthly, and yearly holiday program. The thermostat will Holidays stay in Unoccupied settings while Holiday is active. Holiday Schedule - OFF Press to turn Holiday Schedule On or Off.
  • Page 39 Main Menu Buttons - Holidays Edit Holidays (Continued) Deselecting Holidays You may deselect a holiday simply by pressing on it. Press BACK to save your changes and return to the Holiday menu. If you choose to deselect a holiday that is part of a Custom Repeating Program, the screen below will appear.

  • Page 40: Preset Holidays

    Main Menu Buttons - Holidays Edit Holidays (Continued) Editing Repeating Holidays (continued) You may now delete all repeating custom holidays in this group by pressing the ON box to un-check your selection. Press SAVE to return to Holiday editing screens. Preset Holidays You may choose from several standard preset holidays to observe.

  • Page 41: Security

    Main Menu Buttons - Security Security Auto Screenlock Auto Screenlock - OFF Set Passcode Lock After... Allow fan/mode changes - NO Allow setpoint changes - NO Allow override - NO Setpoint Limits Setpoint Limits - OFF Minimum Cool Setpoint Maximum Heat Setpoint Maximum Override Time...

  • Page 42: Auto Screenlock

    Main Menu Buttons - Security Security settings may be set to limit or prevent changes to your thermostat. Security Auto Screenlock Auto Screenlock - OFF NOTE: Auto Screenlock - ON Code must be set before Auto Screenlock can be turned on. Set Passcode (code not set ) Use keypad to enter and confirm passcode.

  • Page 43: Information

    Main Menu Buttons - Information Information View Runtime Graphs Last 7 Days - Cooling Last 7 Days - Heating Last 7 Days - Override Delete Runtime Data Who To Call For Service...

  • Page 44: View Runtime Graphs

    Main Menu Buttons - Information This button contains valuable service and system runtime information. Information View Runtime Graphs Track your system’s runtime/energy usage. Last 7 Days - Cooling Press the information icon to learn more about each graph. *NOTE: The runtime graphs are updated Last 7 Days - Heating at 12:00 AM each day.

  • Page 45: Settings

    Main Menu Buttons - Settings Settings Thermostat Name Available Modes All Modes Including Auto Heat and Cool Heat Only Cool Only SD Card Import Settings from SD Card Export Settings to SD Card General Setup Units Fahrenheit Celsius Language English Spanish/Espanol French/Francais Smart Recovery - ON/OFF...
  • Page 46 Main Menu Buttons - Settings Settings (Continued) Installation Settings Timers & Deadbands Cycles Per Hour Min Heat/Cool Difference Compressor Min Off Time 1st Stage Deadband 2nd Stage Deadband 2nd Stage Deadband 2nd Stage Timer 2nd Stage Turnoff Point Deadband Setpoint 3rd Stage Deadband 3rd Stage Deadband 3rd Stage Timer...
  • Page 47 Main Menu Buttons - Settings Settings (Continued) Installation Settings Heat Pump Settings Heat Pump Lockout - Enabled/Disabled HP Lockout Outdoor Temp Aux Heat Lockout - Enabled/Disabled Aux Heat Lockout Temp Fan Off Delay Sensor Settings Control Source Thermostat Sensor Only Wired Sensor Only Average All Wireless Sensors Average Wired/Thermostat...
  • Page 48 Main Menu Buttons - Settings Settings Installation Settings (Continued) Test Outputs Dealer Information Dealer Name Contact Name Dealer Phone Dealer Email Dealer Website Upgrade Firmware Delete Custom Images Factory Defaults Restart Thermostat...

  • Page 49: Thermostat Name

    Main Menu Buttons - Settings Thermostat heating and cooling options are found in this menu. Settings Thermostat Name Use keypad to name your thermostat. The name is displayed on the Home Screen. (Up to 14 characters) Name appears here Available Modes (all) Choose the desired modes the thermostat will use: Heat, Cool, Heat &...

  • Page 50: Language

    Main Menu Buttons - Settings General Setup (Continued) Language (en) English Spanish/Español French/Français Smart Recovery - OFF Smart Recovery - ON Smart Recovery turns on the heat before the Occupied start time to bring the room temperature to the Occupied setpoint at the start of the Occupied time period.
  • Page 51 Main Menu Buttons - Settings Installation Settings (Continued) Timers & Deadbands (Continued) The Deadband is the number of degrees or minutes that the thermostat waits before it initiates the stages of heating or cooling. 1st Stage Deadband Specifies the minimum temperature difference between the room temperature and the desired setpoint before the first stage of heating or cooling is allowed to turn on.

  • Page 52: Automated Demand Response

    Main Menu Buttons - Settings Overview Automated Demand Response ColorDisplay thermostats support the handling of specific signals from the utility provider. The utility generated signals carry pricing information and/or setback actions that alter the comfort settings of the thermostat in order to reduce energy usage on demand.
  • Page 53 Main Menu Buttons - Settings The Demand Response configuration page, shown below, is where the thermostat is configured to respond to the energy provider’s signals. It also sets operational parameters for the thermostat. The left column of the ADR configuration page allows or prevents access by the utility.
  • Page 54 Main Menu Buttons - Settings The right column of the ADR configuration page is where the occupant adjusts the operational parameters for ADR. The utility may send up to 3 types of ADR signals to Skyport. These are: 1) Pricing for the cost of energy, 2) An Offset to the occupants’...
  • Page 55 Main Menu Buttons - Settings Selecting the Overview tab of the ADR page will cause a summary of ADR events to be displayed. Office - Configuration...
  • Page 56 Main Menu Buttons - Settings Automated Demand Response Utility and Program setup must be done at the Skyport Cloud Services account. From the thermostat Home Screen, press the ‘Menu’ button, then select ‘Settings’. From the above screen the ‘Automated Demand Response’ button is pressed.
  • Page 57 Main Menu Buttons - Settings Selecting the ‘Price Dependent Action’ button allows the user to determine what action is taken when the price rises above the set threshold. In the above example; if the price threshold is exceeded, the thermostat will invoke the ‘Offset Setpoints’ configured for an ADR event until the event is over.
  • Page 58 Main Menu Buttons - Settings The user may limit the maximum Cooling Setpoint.
  • Page 59 Main Menu Buttons - Settings The user may limit the minimum Heating Setpoint.
  • Page 60 Main Menu Buttons - Settings The user may adjust the ADR Cooling ‘static’ Setpoint.
  • Page 61 Main Menu Buttons - Settings The user may adjust the ADR Heating ‘static’ Setpoint.
  • Page 62 Main Menu Buttons - Settings The user may adjust the ADR Cool offset. During an ADR event the cooling setpoint will be adjusted by the amount of degrees configured in this step.
  • Page 63 Main Menu Buttons - Settings The user may adjust the ADR Heat offset. During an ADR event the heating setpoint will be adjusted by the amount of degrees configured in this step.
  • Page 64 Main Menu Buttons - Settings When an ADR event is pending, and hasn’t started yet, there will be a yellow leaf on the top bar. This will be accompanied by associated text as shown below. During an ADR event there will be a green leaf on the top bar. This will be accompanied by associated text as shown below.
  • Page 65 Main Menu Buttons - Settings If a Warmer or Cooler button is pressed during an active ADR event, then the user is presented with this opt-out screen. If a pricing triggered ADR event is enabled, there will be a green leaf on the top bar along with the actual cost of energy.

  • Page 66: Heat Pump Settings

    Main Menu Buttons - Settings (Continued) Installation Settings (Only available Heat Pump Settings when dip switch is set for Heat Pump operation.) Heat Pump Lockout - DISABLED Heat Pump Lockout - ENABLED Turns on Heat Pump Lockout. HP Lockout Outdoor Temp (65˚) Heat Pump will not run below this temp.

  • Page 67: Aux Output Settings

    Main Menu Buttons - Settings (Continued) Installation Settings AUX Output Settings Allows the W3/AUX output to be used for Heating, Humidification, or Dehumidification. AUX output usage (W3) IMPORTANT: Aux Output Usage must be set for Hum or Dehum before any settings will take effect in the Humidity Main Menu.

  • Page 68: Fan Off Delay

    Main Menu Buttons - Settings (Continued) Installation Settings Fan Off Delay (0s) Runs the fan for a short time after Cooling or electric strip heat turns off to increase system efficiency. (0 - 120 Secs.) Sensor Settings Control Sensor (thermostat ) When a remote sensor is connected to the thermostat, the user may choose which sensor source is used to measure room temperature.

  • Page 69: Calibrate Sensors

    Main Menu Buttons - Settings Calibrate Sensors (0˚) The thermostat and wired sensor may be calibrated -7 to +7 degrees F . The integral humidity sensor may be calibrated -20% to +20% RH • Thermostat • Wired Sensor • Humidity Test Outputs The installer or service technician can use this...

  • Page 70: Dealer Information

    Main Menu Buttons - Settings Dealer Information A Dealer may enter their company contact information for the customer to use when they need service. This will appear when the “Who To Call For Service” button is pressed in the Information Menu. Use the keyboard to enter your information.
  • Page 71 Main Menu Buttons - Wi-Fi Wi-Fi Enabled Wi-Fi Status Wi-Fi Setup Choose Network Password Entry Local API Option Local API - OFF API Protocol HTTP HTTPS...

  • Page 72: Wi-Fi

    Main Menu Buttons - Wi-Fi Wi-Fi Wi-Fi Enabled This option allows the wifi radio to be turned off or on. Wi-Fi Status It is here that you will find helpful information regarding the connectivity myoffice status of your thermostat, including the thermostat’s ID. Wi-Fi Setup Choose your network from the list and enter...
  • Page 73 Main Menu Buttons - Wi-Fi This is the default with the local API OFF . • Local API - OFF • API Protocol (http) To turn on the HTTP Local API select Local API • Local API - ON • API Protocol (http) Press BACK to return to previous screen.
  • Page 74 Main Menu Buttons - Settings Upon pressing BACK, the screen will look like this. • Local API - OFF • API Protocol API Protocol (https) (http) • Basic Auth User PRESS • Basic Auth Password API Protocol (http) • Basic Auth User Select Basic Auth User, and enter (64 remaining) the appropriate information...
  • Page 75 Main Menu Buttons - Wi-Fi • Basic Auth Password Select Basic Auth Password and (64 remaining) enter the appropriate information on the screen below and press DONE to save. Shift 123!? SPACE BACK Basic Auth Password DONE The last step is to turn the Local API on as shown below. •...

  • Page 76: Skyport

    Main Menu Buttons - Skyport Skyport Skyport Services - ON Weather Updates - ON Skyport Account Skyport Account Pressing this button will let you know if you are paired with a Skyport account. If not, then you may follow prompt and instructions to create an account and add the thermostat to the account.

  • Page 77: Emergency Heat

    Main Menu Buttons - Emergency Heat The Emergency Heat function is only available if your thermostat is set to control a Heat Pump. Emergency Heat To initiate the Emergency Heat feature, press the Emergency Heat button. During Emergency Heat operation, the thermostat will turn on the fan and substitute auxiliary stages of heat for the first/second stages of heat.

  • Page 78: Colordisplay Desktop App

    ColorDisplay Desktop App may be downloaded at no charge at: http://jcithermostats.com/colordisplay/desktop-app/ Every time the user runs the ColorDisplay Desktop App software, it automatically connects to the Johnson Controls ColorDisplay website ® in the background and updates the software and firmware (the operating system for touch screen) at no cost.

  • Page 79: Uploading Photos

    The ColorDisplay Desktop App Uploading Photos and Settings to your thermostat When you are finished adding and editing photos and settings, click on Save to SD. When prompted, remove the SD card from the SD card reader on your computer. Save to SD *NOTE: A 2GB SD card is recommended.

  • Page 80: Installation Instructions

    Installation Instructions Remove and Replace the Old Thermostat To install the thermostat properly, please follow these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. • Assemble tools: Flat blade screwdriver, wire cutters and wire strippers.

  • Page 81: Wire Connections

    Installation Instructions Wire Connections If the terminal designations on your old thermostat do not match those refer to the chart below or the wiring on the new thermostat, diagrams that follow. Wire from the Install on the old thermostat Function new thermostat terminal marked connector marked...

  • Page 82: Determining Your Existing Wiring And Equipment

    Installation Instructions Before you go any further, determine what your existing wiring and equipment situation is. If you have a Heating only system without Air Conditioning, the JCI thermostat will require 3 wires: R (24Vac), C (24Vac) and W (Heat). Most systems that only have Heating use very simple thermostats that require 2 wires: the R (24Vac) and W (Heat).
  • Page 83 Installation Instructions If you have a heat pump without aux heat, the JCI model will require 5 wires: R (24Vac), C (24Vac), W1/O/B (Reversing Value), Y (1 Stage Compressor), and G (Fan). If you are short 1 wire, there are at least 2 options available to connect the JCI thermostat: 1.

  • Page 84: Making 4 Wires Work When 5 Wires Are Required

    Installation Instructions Making 4 Wires Work When 5 Wires Are Required If you would like to install the JCI thermostat using only 4 wires when 5 are required, follow the directions below. You will need a screwdriver along with a 3" long piece of thermostat wire to use as a jumper: 1.

  • Page 85: Making 5 Wires Work When 6 Wires Are Required

    Installation Instructions Making 5 Wires Work When 6 Wires Are Required If you have a system that requires 6 wires, and you would like to install the JCI thermostat using only 5 wires, follow the directions below. You will need a screwdriver along with a 3" long piece of thermostat wire to use as a jumper: 1.

  • Page 86: The T9100 Thermostat Backplate

    Installation Instructions 9100 The T Thermostat Backplate NOTE: The backplate does not fully cover a full size vertical junction box. The ACC-WALLPLT touch screen wallplate or a single-gang, horizontally mounted junction box would be needed for that type of SENSOR installation.

  • Page 87: Explanation Of The Thermostat Dip Switches

    Installation Instructions Explanation of Thermostat Dip Switches Dip switches are located on the back of the thermostat GAS/EL ELEC This dip switch configures the thermostat to control a GAS/EL GAS/EL conventional gas/electric system or a heat pump. If your system is anything other than a heat pump, leave this switch set for GAS/EL.* *For some commercial heat pumps, this switch may need to be set for GAS/EL.

  • Page 88: Sample Wiring Diagrams

    Installation Instructions Sample Wiring Diagrams with Dip Switch Positions Conventional Heating and Cooling Systems 3 Wire, Heat Only 2 Wire, Heat Only Residential & Commercial 1 Stage Heating Residential & Commercial 1 Stage Heating with no Fan. with no Fan. The thermostat will not work with 24VAC Power 2 wires.
  • Page 89 Installation Instructions Sample Wiring Diagrams with Dip Switch Positions Heat Pump Systems 5 Wire, 1 Stage Cooling, 1 Stage Heat 6 Wire, 1 Stage Cooling, 2 Stage Heat Residential & Commercial Heat Pump with Residential & Commercial Heat Pump with ‘O’...
  • Page 90 Installation Instructions Sample Wiring Diagrams Outdoor Sensor: ACC-RSEN Temperature Sensor 10K ohm sensor at 77F/25C. Negative Temperature Coefficient. Use 18-22 gauge thermostat wire. 10K Thermistor SENSOR Outdoor Sensor ACC-RSEN Indoor Remote Sensor with Override Button: ACC-RSEN-OVR Temperature Sensor 10K ohm sensor at 77F/25C. Negative Temperature Coefficient. (see page 59 for setup instructions) Use 18-22 gauge thermostat wire.
  • Page 91 Installation Instructions Sample Wiring Diagrams Humidification Use 16-24 gauge AUX Output Usage thermostat wire. must be set for Hum SENSOR Humidification System Dehumidification AUX Output Usage must be set for Dehum Use 16-24 gauge thermostat wire. SENSOR Dehumidification Terminal on Equipment DEHUM/...

  • Page 92: Troubleshooting

    Troubleshooting • SYMPTOM: The thermostat touch screen buttons are not responsive. CAUSE: The touch screen is out of calibration. REMEDY: Remove the thermostat from the backplate. Push the thermostat back onto the backplate, while keeping your finger pressed firmly against the center of the touch screen, until the Calibration screen appears.

  • Page 93: Index

    Index Menu, 1 Deadband Override, 7 1st stage, 44 Warmer, 1 2nd stage, 44 3rd stage, 44 4th stage, 44 Dealer Information, 37, 63 Accessories 61 Delay Active Brightness, 23 Fan-off, see Fan Alerts, 22 Time between stages, view current, 22 Connections, 74 see Time Delay reset, 22...
  • Page 94 Index Emergency Heat, 70 Energy Usage Cool, 37 Heat, 37 Aux heat, 37 Heat Idle Brightness, 24 1st stage Information, 37 deadband, see Installation Settings, 43 Deadband Installation, 73 emergency heat, 70 hours of runtime, 37 2nd stage deadband, Factory Defaults see Deadband resetting, 63 electric strip heat,...
  • Page 95 Index sensor, 61 viewing temp, 1 Overcool, 29 Override, 7 Main Menu, 1 Schedule turn on/off, 15 Maintenance, 25 view, 15 Manual edit, 15 changeover, 6 Screen Cleaning, 5, 25 cool, 6 Screensaver heat, 6 Passcode, 35 turn on/off, 20 Mode, 1, 6 Photos, 20, 63, 72 setup,20...
  • Page 96 Index Terminals, W1, 74 see Backplate W2, 74 Test Outputs, 62 W3, 74 Themes, 27 Wallpaper, 27 Thermostat Sensor Warranty, 91 calibrate, 59 Wiring, 74 Three Stage Heat, 44 gas/electric, 80 Time, see Clock heat pump, 82 Timers, 43 Time Delay, compressor lockout, 59 cycles per hour, 43 1st stage to 2nd stage, 44...
  • Page 97 Notes...

  • Page 98: Warranty

    Warranty Three-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within three years from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option to replace any defective part, will be provided without charge for the part itself provided the defective part is returned to the distributor through a qualified servicing dealer.

  • Page 99: Technical Specifications

    Technical Specifications ColorDisplay Series Thermostat Controllers Touch Screen Series Thermostat Controllers Power Requirements 20 - 30 VAC 50/60 Hz, 4.8 VA @ 24V nominal. Output Rating W1, W2, W3 = 0.2A max, 0.01A min, 3A inrush, 20 - 30 VAC Y1, Y2, G = 0.4A max, 0.01A min, 3A inrush, 20 - 30 VAC Local Temperature Thermistor, NTC 10K @ 25C...
  • Page 100 Printed on recycled paper. 12012271 Rev. 3 09/17...
