T9600
PARAMETER SETTING (PART 2/2)
T9600- T9603- T9601-
TF20- T000- TF20-
Code 1JS0 1JF0 1JS0
■ ■ ■
16
■ ■ ■
17
■ ■ ■
18
■
19
■ ■ ■
20
SERVICE SETTING (Setting through professional)
In the Setting page press button for 3 seconds to get in Service page, the occupancy icon
scroll backward in the list and
the parameter list and press
PARAMETER SETTING (PART 1/2)
T9600- T9603- T9601-
TF20- T000- TF20-
Code 1JS0 1JF0 1JS0
■ ■ ■
02
■ ■
03
■ ■
04
■ ■ ■
05
■ ■ ■
06
■ ■ ■
07
■
08
...Continued...
P/N 24-11447-00004 Rev. B Issue Date: 11 2020
T9600-
TF21-
1JS0 Parameter Name
■
KEY-LOCK
■
TEMP-DISP
■
UNIT
DAMP-OPEN-TIME
■
SF-VERSION
use and button to change parameter value.
to scroll foward through the list.
T9600-
TF21-
1JS0 Parameter name
■
FRST-PRT
FH-FAN
■
APPLICATION
■
DOWN-SET-LIMIT
■
UP-SET-LIMIT
■
FP-SP
ECM-MIN-V
Default Function
Key lock function:
00: No Lockout
01: Level 1 ->Lock all keys
00 02: Level 2 ->Lock the keys except Fan Speed and Temp
Adjustment keys
03: Level 3 ->Lock the ON/OFF and Clock keys
04: Level 4 ->Lock the keys except ON/OFF key
UI display room temperature or set point:
00 00: Room Temperature
01: Setpoint
Unit selection:
01 00: IP
01: SI
Damper opening time, for AHU application
0
range 0-99 (0=75 s, 99=174 s)
Software version, read only
Press to scroll forward and M button to
shows.
For T9603-T000-1JF0, press and hold
Default Function
Frost protection:
00 00: No
01: Yes
Enable/disable fan output when floor heater
00 00: Disable
01: Enable
T9600- TF20-1JS0:
00: 2pipe FCU (relay)
01: 4pipe FCU (relay)
02: 2pipe 3 wire (relay)
03: 2pipe FCU (relay) with floor heating
04: 2pipe FCU (relay) with TiO2/ESP
05: water source heat pump
T9601- TF20-1JS0:
00: 2-pipe FCU (relay), ECM fan
01: 4-pipe FCU (relay), ECM fan
00 02: 2-pipe 3 wire (relay), ECM fan
03: 2-pipe FCU with floor heater, ECM fan
04: 2-pipe FCU with TiO2/ESP, ECM fan
05: water source heat pump, ECM fan
06: 2-pipe FCU (prop), ECM fan
07: 2-pipe FCU (prop) with floor heater, ECM fan
08: 2-pipe FCU (prop) with radiator, ECM fan
09. AHU
T9600- TF21-1JS0:
00: 2-pipe FCU, three speed fan
01: 4-pipe FCU, three speed fan
5°C/
lower setpoint limit
Range: 0°C~36°C (32°F-97°F)
41°F
35°C/
Upper setpoint limit
Range: 2°C~37°C (36°F~99°F)
95°F
Frost protection setpoint.
5°C/
Step: 0.5°C (1°F)
41°F
Range: 0°C~20°C (32°F-68°F)
ECM Min voltage.
Min voltage below which the fan output is 0%.
3 V
Step: 0.5 V
Range: 0 V~10 V
English
for 3 seconds to access
