Fenix HT18R Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
Technical Parameters
ANSI/ PLATO
Turbo
FL1
2800
lumens
Output
1 hour 40
minutes
Runtime
1100
meters
Distance
300000
candela
Intensity
Impact
Resistance
Submersible
Note: The above specifications are from the results produced by Fenix through its laboratory testing using the
Fenix ARB-L21-5000 V2.0 battery, under the temperature of 21±3°C and humidity of 50% - 80%. The true
performance of this product may vary according to different working environments and the actual battery used.
*The Turbo output is measured in total of runtime including output at reduced levels due to the built-in
temperature protection mechanism.
(ENGLISH)Fenix HT18R Flashlight
High
1000 lumens
350 lumens
2 hours 15
minutes
*
670 meters
400 meters
113000
candela
Med
Low
30 lumens
6 hours 30
42 hours
minutes
100 meters
40000
3000
candela
candela
1 meter
IP68
Strobe
SOS
2600
150
lumens
lumens
/
40 hours
200
/
meters
10000
/
candela

Advertisement

loading
Need help?

Need help?

Do you have a question about the HT18R and is the answer not in the manual?

Questions and answers

Related Manuals for Fenix HT18R

Summary of Contents for Fenix HT18R

  • Page 1 IP68 Submersible Note: The above specifications are from the results produced by Fenix through its laboratory testing using the Fenix ARB-L21-5000 V2.0 battery, under the temperature of 21±3°C and humidity of 50% - 80%. The true performance of this product may vary according to different working environments and the actual battery used.

  • Page 2: Product Features

    ◎2800 lumens maximum output and 1100 meters maximum beam distance. ◎Utilizes one Luminus SFT70 LED with a lifespan of 50,000 hours. ◎Included a Fenix ARB-L21-5000 V2.0 rechargeable battery. ◎Inner waterproof USB Type-C charging port. ◎Included red and green filter adapters.
  • Page 3 ◎Dual tail switch for fast, single-handed operation. ◎Boot-up battery level indication and low-voltage warning. ◎Made of durable A6061-T6 aluminum. ◎Premium type HAIII hard-anodized anti-abrasive finish. ◎Size: 7.42'' x 2.68'' x 1.00''/188.5 × 68 × 25.4 mm. ◎Weight: 8.91 oz/252.7 g (excluding battery). Operating Instructions Switches The round tail switch is the tactical switch for instant activation.

  • Page 4: Battery Specifications

    Only using quality batteries with circuit protection will reduce the potential for combustion or explosion. Cell abuse or short circuiting are considered user induced damage and are not covered by any Fenix warranty or liability. Battery Replacement Unscrew the tail cap and insert the battery with the anode side (+) towards the light head, then screw the tail cap back on.

  • Page 5: Battery Level Indication

    3. Recharge a stored light every four months to maintain the optimum performance of the battery. *Note: These features only works with a Fenix ARB-L21 series rechargeable battery. Battery level indication Each time the light is turned on, the indicator will indicate the battery level and will last for 3 seconds.
  • Page 6 Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol. If the above methods don't work, please contact your authorized distributor. Included Fenix HT18R flashlight, ARB-L21-5000 V2.0 battery, USB Type-C charging cable, Lanyard, Holster, Spare O-ring, Red light filter adapter, Green light filter adapter, User manual, Warranty card...
