Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1.Please check the pack contents before attempting this product.
A full checklist of component is given in this leaflet. If any component are missing, please contact
the retailer from whom you bought this product.
2.This product is
heavy
TAKE CARE WITH LIFTING to avoid personal in jury and (or) damage to the product.
3.This product takes approximately 45 minutes to assemble with 2 people.
4.This product already contain fitting which should be :
" KEPT AWAY FROM YOUNG CHILDREN "
5.Read this leaflet in full before commencing assembly.
Thank you for buying our product
, it should be assembled as near as possible to the point of use.
Mistral Bed 151cm / 181 cm
( MST01 )
Assembly Instruction
Advertisement
Table of Contents
Related Manuals for Multay Mistral MST01
Summary of Contents for Multay Mistral MST01
- Page 1 Mistral Bed 151cm / 181 cm ( MST01 ) Assembly Instruction Thank you for buying our product Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1.Please check the pack contents before attempting this product. A full checklist of component is given in this leaflet. If any component are missing, please contact the retailer from whom you bought this product.
- Page 2 Mistral Bed 151cm / 181 cm ( MST01 ) Assembly Instruction HEADBOARD SLAT FOOTBOARD SIDE RAIL SLAT SUPPORT BOLT CONNECTING RAILS HARDWARE IDENTIFICATION ITEM DESCRIPTION HEADBOARD FOOTBOARD SIDE RAILS SLATS SLATS SUPPORT BOLT CONNECTING RAIL (Embedded in side rail)
- Page 3 Mistral Bed 151cm / 181 cm ( MST01 ) Assembly Instruction Step - Remove Bolt Connecting rail from the Side Rail by hand. - Screw the eight threaded bolt into the Headboard an Footboard then tighten by hand. Fitting : Threaded Bolt BOLT CONNECTING RAILS Step...
- Page 4 Mistral Bed 151cm / 181 cm ( MST01 ) Assembly Instruction Step - Locate the side rails onto the threaded bolt protruding from the Footboard. Locate round washer and nut onto the threaded bolt and secure by hand at first. Tighten evenly using the open end spanner (Not provided) Step - Locate the Slat Support into the wooden brackets.
- Page 5 Mistral Bed 151cm / 181 cm ( MST01 ) Assembly Instruction PLASTIC CAP SLAT (Wooden) Step - Locate the Slats onto side rail cleat then push fit the plastic cup slat onto either holes of the Side Rails and Slat support. Repeat this step with the other slat holes. The assembly in now complete.
