Thank you for buying our product
Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1. Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing,
please contact the retailer from whom you bought this product.
2. This product is VERY HEAVY, It should be assembled as near as possible to the
point of use. TAKE CARE WHEN LIFTING to avoid personal
injury and ( or ) damage to the product.
3. This product takes approximately 60 minutes to assemble with 3 people.
4. The fitting pack contains SMALL ITEMS which should be :
"KEPT AWAY FROM YOUNG CHILDREN"
5. Read this leaflet in full before commencing assembly.
6. You will require a 17 mm spanner (not supplied).
Large Extending Table ( SV02 )
Assembly Instruction
Page 1
Advertisement
Table of Contents
Related Manuals for Multay SV02
Summary of Contents for Multay SV02
- Page 1 Large Extending Table ( SV02 ) Assembly Instruction Thank you for buying our product Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1. Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact the retailer from whom you bought this product.
- Page 2 Large Extending Table ( SV Assembly Instruction ( C ) Extension Leaf (A) Table Top (B) Leg ( D ) Nut, Washer, Bolt HARDWARE IDENTIFICATION ITEM DESCRIPTION Table Top Extension Leaf Nut, Washer, Bolt Page 2...
- Page 3 Large Extending Table ( SV Assembly Instruction 1. Step Place protective cardboard or blankets on the floor ( make sure there is no debris ) and place the top of the table upside down as per the diagram below ( Fig.1 ) Fig.1 (Shows the table upside down on the floor ready for assembling) There are 4 x table leg marked clearly with white stickers ( 1, 2, 3 and 4 ).
- Page 4 Large Extending Table ( SV Assembly Instruction marks 1 marks 1 Fig.2 Shows the underside of the table with clear markings of 1 with 1, and 2 with 2 and also show bolts, nut and washer. Important Notice : Ensure the bolts are inserted as below Tighten the bolts firmly ( make sure the washer is on the outside of the corner ) Page 4...
- Page 5 Large Extending Table ( SV Assembly Instruction 2. Step Turn the table over. First onto one side then carefully using at least 2 men turn the table into its final operating position. THIS PRODUCT IS HEAVY. Finaly re - tighten the 8 nuts and bolts from underneath. Fig.
