Multay Marseille Bed 150 Low Footboard Assembly Instruction

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Thank you for buying our product
Step By Step Assembly Instructions

PRE-ASSEMBLY PREPARATION

1.Please check the pack contents before attempting this product.
A full checklist of component is given in this leaflet. If any component are missing, please contact
the retailer from whom you bought this product.
2.This product is heavy, it should be assembled as near as possible to the point of use.
TAKE CARE WITH LIFTING to affoid personal in jury and (or) damage to the product.
3.This product takes approximately 30 minutes to assemble with 2 people.
4.This product already contain fitting which should be :
" KEPT AWAY FROM YOUNG CHILDREN "
5.Read this leaflet in full before commencing assembly.
Marseille Bed 150 Low Footboard
Assembly Instruction
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Marseille Bed 150 Low Footboard and is the answer not in the manual?

Questions and answers

Related Manuals for Multay Marseille Bed 150 Low Footboard

Summary of Contents for Multay Marseille Bed 150 Low Footboard

  • Page 1 Marseille Bed 150 Low Footboard Assembly Instruction Thank you for buying our product Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1.Please check the pack contents before attempting this product. A full checklist of component is given in this leaflet. If any component are missing, please contact the retailer from whom you bought this product.
  • Page 2 Marseille Bed 150 Low Footboard Assembly Instruction (D) Slat (A) Headboard ( C ) Side Rail (B) Footboard ( C ) Side Rail (F) Bolt Connecting Rails (E) Slat Support HARDWARE IDENTIFICATION ITEM DESCRIPTION HEADBOARD FOOTBOARD SIDE RAILS SLATS ( Assembled )
  • Page 3 Marseille Bed 150 Low Footboard Assembly Instruction 1. HEADBOARD AND SIDE RAIL ASSEMBLY # Step 1 1. “Left / Right” marked on headboard must be matched with “Left/Right” marked on each side rail. Note : - Its required one person to hold...
  • Page 4 Marseille Bed 150 Low Footboard Assembly Instruction 2. FOOTBOARD AND SIDE RAIL ASSEMBLY # Step 2 1. “Left / Right” marked on footboard must be matched with “Left/Right” marked on each side rail. Side Rail Footboard 2. The side rail must be pushed down hardly to get in one level with footboard.
  • Page 5 Marseille Bed 150 Low Footboard Assembly Instruction 3. SLAT SUPPORT ASSEMBLY Slat Support 4. SLAT ASSEMBLY Slat Page 5...
