MONTPELLIER DINING COLLECTION
160/180 Cm Large Extending Table ( Product Code MO / 2875M / NNN )
Thank you for buying our product
Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1. Please check the pack contents before attempting this product. A full checklist of
components is given in this leaflet. If any components are missing, please contact
the retailer from whom you bought this product.
2. This product is VERY HEAVY, it should be assembled as near as possible to the
point of use. TAKE CARE WHEN LIFTING to avoid personal in jury and ( or )
damage to the product.
3. This product takes approximately 60 minutes to assemble with 3 people.
4. The fitting pack contain SMALL ITEM which should be
KEPT AWAY FROM YOUNG CHILDREN
5. Read this leaflet in full before commencing assembly.
6. You will require an Allen Key (provided) to assembly this product.
Page 1
Advertisement
Table of Contents
Related Manuals for Multay MONTPELLIER DINING MO-2875M-NNN
Summary of Contents for Multay MONTPELLIER DINING MO-2875M-NNN
- Page 1 MONTPELLIER DINING COLLECTION 160/180 Cm Large Extending Table ( Product Code MO / 2875M / NNN ) Thank you for buying our product Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1. Please check the pack contents before attempting this product. A full checklist of components is given in this leaflet.
- Page 2 MONTPELLIER DINING COLLECTION 160/180 Cm Large Extending Table ( Product Code MO / 2875M / NNN ) Thank you for buying our product Spring Clips (inside) Panel and Fittings Identification Item Description Table Top Pedestal Extension Leaf Allen Key Bolt 5 mm L : 5 Cm Washer...
- Page 3 MONTPELLIER DINING COLLECTION 160/180 Cm Large Extending Table ( Product Code MO / 2875M / NNN ) Step - With the help of 3 assistants locate the pedestals onto the underside of the table top. Align the legs as shown below ( i.e the single leg pointing inwards ), whilst ensuring that the dowels align to the holes in the table top.
- Page 4 MONTPELLIER DINING COLLECTION 160/180 Cm Large Extending Table ( Product Code MO / 2875M / NNN ) Step -To secure the pedestals, use the eight bolts with washers inserted up through the pedestal pilot holes and into the inserts located in the pedestal attachment plates.
- Page 5 MONTPELLIER DINING COLLECTION 160/180 Cm Large Extending Table ( Product Code MO / 2875M / NNN ) Step - Locate the extension leaf between the table leaves, noting the location pins as shown. Fold down the skirts on the leaf as per the diagram below. Finally push the main leaves back together ensuring that the pins locate into the holes.
