Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1.Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing, please contact
the retailer from whom you bought this product.
2.This product is Heavy, it should be assembled as near as possible to the point of use.
TAKE CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.
3.This product takes approximately 45 minutes to assemble with 2 people.
4.This product already contains fitting which should be :
" KEPT AWAY FROM YOUNG CHILDREN "
5.Read this leaflet in full before commencing assembly.
Montego Bed
MG01
Assembly Instruction
Page 1
Advertisement
Related Manuals for Multay Montego MG01
Summary of Contents for Multay Montego MG01
- Page 1 Montego Bed MG01 Assembly Instruction Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1.Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact the retailer from whom you bought this product.
- Page 2 Montego Bed MG01 Assembly Instruction (A) Headboard ( C ) Side Rail (D) Slats ( C ) Side Rail (B) Footboard (E) Slats Support HARDWARE IDENTIFICATION ITEM DESCRIPTION Q ty HEADBOARD FOOTBOARD SIDE RAILS SLATS ( Assembled ) SLATS SUPPORT / CENTRE RAIL BOLT CONNECTING RAIL (Embedded in side rail) Page 2...
- Page 3 Montego Bed MG01 Assembly Instruction 1. HEADBOARD AND SIDE RAIL ASSEMBLY # Step 1 1. “Left / Right” marked on headboard must be matched with “Left/Right” marked on each side rail. 2. Remove bolt connecting rail from the Side Rail by hand 3.
- Page 4 Montego Bed MG01 Assembly Instruction 2. FOOTBOARD AND SIDE RAIL ASSEMBLY # Step 2 1. “Left / Right” marked on footboard must be matched with “Left/Right” marked on each side rail. 2. Locating the Side Rails onto the threaded bolt protruding from the Footboard, Locating round washer and nut onto the threaded bolt and secure by hand first, Tighten evenly using spanner (not provided) ( C ) Side Rail...
- Page 5 Montego Bed MG01 Assembly Instruction 3. CENTRE RAIL ASSEMBLY ( Turn clockwise to tighten ) - Insert the Centre legs into Centre Rail - Locate the Centre Rail into the wooden brackets Centre Leg (E) Slats Support Centre Rail Slat Support Centre Rail 4.
