Multay SV14 Assembly Instruction

Large extending table

Thank you for buying our product

Step By Step Assembly Instructions

PRE-ASSEMBLY PREPARATION

1. Please check the pack contents before attempting to assemble this product.

A full checklist of components is given in this leaflet. If any components are missing,

please contact the retailer from whom you bought this product.

2. This product is VERY HEAVY, It should be assembled as near as possible to the

point of use. TAKE CARE WHEN LIFTING to avoid personal

injury and ( or ) damage to the product.

3. This product takes approximately 60 minutes to assemble with 3 people.

4. The fitting pack contains SMALL ITEMS which should be :

"KEPT AWAY FROM YOUNG CHILDREN"

5. Read this leaflet in full before commencing assembly.

6. You will require a 17 mm spanner (not supplied).

Large Extending Table ( SV14 )

Assembly Instruction

Page 1
