V-ZUG-Home
Install the app, network your appliances and
benefit from a wide range of useful functions.
Operating instructions
CombiCooler V4000 178NI | V4000
Refrigerator/freezer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CombiCooler V4000 178NI and is the answer not in the manual?

Questions and answers

Related Manuals for V-ZUG CombiCooler V4000 178NI

Summary of Contents for V-ZUG CombiCooler V4000 178NI

  • Page 1 V-ZUG-Home Install the app, network your appliances and benefit from a wide range of useful functions. Operating instructions CombiCooler V4000 178NI | V4000 Refrigerator/freezer...
  • Page 2 Type Model number Size system CombiCooler V4000 178NI CCO4T-51108 51108 SMS 55 / Euro 60 CombiCooler V4000 CCO4T-51087 51087 SMS 55 / Euro 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2022...

  • Page 3: Table Of Contents

    Setting the temperature ........ 10 Selecting appliance functions ...... 11 Cancelling settings .......... 11 Switching the appliance off........ 11 Appliance functions  12 Activating/Deactivating appliance functions .. 12 Description of functions........ 18 V-ZUG-Home  21 Conditions ............. 21 Initial set-up............ 21 Glass shelves and door trays  22 Storing food  22 How to arrange food in the appliance..... 22...

  • Page 4: Safety Precautions

    Safety precautions Symbols used Denotes important safety precau- ▪ This appliance can be used tions. Failure to observe said precautions by children aged 8 and above can result in injury or in damage to and by persons with reduced the appliance or fittings! physical, sensory or mental Information and precautions that capabilities, or lack of experi-...

  • Page 5: Appliance-Specific Safety Precautions

    1 Safety precautions ▪ Refer to the identification plate for in- turer or its Customer Services formation on the required mains or a similarly qualified person voltage, current type and fuse protec- in order to avoid hazard. tion. ▪ All plastering, plasterboarding, wall pa- Appliance-specific safety pering and painting work is to be car- precautions...
  • Page 6 1 Safety precautions ▪ WARNING: Do not locate multiple port- fect the functioning of the appliance. If able socket-outlets or portable power the appliance is not working properly or supplies at the rear of the appliance. in case a repair is needed, follow the in- ▪...
  • Page 7 1 Safety precautions Caution: Risk of injury! How to avoid damaging the appliance ▪ Be careful not to put fingers in the door ▪ Clean the appliance just with water or a hinges. as there is otherwise a risk of mild soapy solution (water and washing- injury if the appliance door is moved.

  • Page 8: Using For The First Time

    Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective film from the in- terior. ▸ Clean the interior and accessories with lukewarm water or a mild soapy solution (wa- ter and washing-up liquid) and dry thoroughly.

  • Page 9: Operating And Display Elements

    ON/OFF (hold depressed for 3 seconds) Display elements: Operating mode User setting MonoFridge Display brightness SilentPlus Switch off button tone PartyCooling V-ZUG-Home Holiday function Temperature unit Sabbath mode Value and status display Refrigerating/Freezing zone Freezing zone active Fast cooling/fast freezing active...

  • Page 10: Operation

    4 Operation Operation Switching the appliance on ▸ Plug in the appliance at the mains socket. – «OF» appears on the left- and right-hand side of the display for 30 seconds. ▸ Hold the button depressed for 3 seconds. – The appliance is switched on. A newly installed appliance takes around 10 hours (empty state / without any food inside) to reach normal operating temperatures.

  • Page 11: Selecting Appliance Functions

    4 Operation ▸ Confirm with the button to accept the entry. – The temperature setting has been entered successfully. – The temperature will be reached in a few hours, depending on the setting. The effective temperature may at times be different from the selected set value if the door is open for an extended period of time or if warm food has been placed inside.

  • Page 12: Appliance Functions Activating/Deactivating Appliance Functions

    5 Appliance functions Appliance functions Activating/Deactivating appliance functions Function Description Temperature set- Temperature selection for the zones ting ▸ Follow the instructions in the «Setting the tem- perature» section (see page 10). Timer Acoustic alarm emitted when the selected duration (from 0 hours 05 minutes to 9 hours 55 minutes) is up.
  • Page 13 5 Appliance functions Function Description Fast cooling/ Preparing the refrigerating zones ideally for loading food and food freezing items after a shopping trip. Activating ▸ Touch the button. ▸ Select the refrigerator or freezer compartment using the buttons. ▸ Confirm with the button.
  • Page 14 5 Appliance functions Function Description MonoFridge The freezer compartment operates as a second refrigerator com- partment or a cold storage compartment (2 °C). Activating ▸ Touch the button. – flashes in the display. ▸ Confirm with the button. ▸ Adjust the temperature for the freezer compart- ment or now newly defined as a refrigerator compartment using the buttons.
  • Page 15 5 Appliance functions Function Description PartyCooling Operation with increased cooling capacity Activating ▸ Touch the button. ▸ Touch the button repeatedly until flashes in the display. ▸ Confirm with the button. ▸ Select the desired duration (12, 24 or 48 hours) using the buttons.
  • Page 16 ▸ Hold the button depressed for 3 seconds. – The function is deactivated; the illumina- tion and display are switched on. V-ZUG-Home Interaction with the appliance via the app (see page 21). Activating ▸ Touch the button. ▸ Touch the...
  • Page 17 5 Appliance functions Function Description Display bright- Adjusting the level of brightness for the display ness Selection ▸ Touch the button. ▸ Touch the button repeatedly until flashes in the display. ▸ Confirm with the button. ▸ Select the desired level of brightness (1 / 2 / 3) using the buttons.

  • Page 18: Description Of Functions

    5 Appliance functions Function Description Demo mode* This setting enables specialist retailers to put the appliance into the showroom mode for demonstration purposes. The demo mode enables functions to be demonstrated without the appli- ance being switched on. Note(*): This setting is not recommended for private use because no cooling takes place in the refrigerator.
  • Page 19 5 Appliance functions SilentPlus This operating mode is designed to produce low noise emissions. The energy consump- tion of the appliance may be slightly increased. Since the appliance is quiet during nor- mal operation, the effect of SilentPlus is particularly perceptible at higher ambient tem- peratures.
  • Page 20 Check the quality of the food. Do not eat food that has thawed! Risk of food poisoning. V-ZUG-Home This function is available for specific countries. With V-ZUG-Home, you can access your appliances over the V-ZUG App to, for instance: ▪ query the appliance status ▪ receive push notifications ▪ change appliance settings...

  • Page 21: V-Zug-Home

    – A 6-digit PIN appears in the display of the household appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password.

  • Page 22: Glass Shelves And Door Trays

    7 Glass shelves and door trays Glass shelves and door trays The height of the glass shelves in the refrigerator compartment and the door trays on the inside of the refrigerator compartment door can be adjusted. The split shelf / half-shelf enables taller vessels to be stored.

  • Page 23: Packaging And Containers

    8 Storing food Packaging and containers ▸ Wrap or cover food in the refrigerator compartment to prevent it from drying out and flavours from transferring. ▸ Transfer the contents of opened tins to sealable containers. ▸ Store raw meat and fish in suitable containers in the refrigerator, so that they do not come into contact with or drip onto other food.

  • Page 24: Care And Maintenance

    9 Care and maintenance Care and maintenance For the hygienic storage of food, the interior should always be kept clean. Do not use any abrasive cleaning agents or scouring cloths to clean the appliance. Take care not to press too hard when cleaning the plastic surfaces. Do not use acidic or strongly alkaline cleaning agents on metal surfaces.

  • Page 25: Warnings

    10 Noises and warnings Unusual noises are often caused by improper installation. The appliance must be in- stalled on a level and stable surface. In open kitchens or in the case of appliances in- stalled in partitioned areas, normal operating noises may seem louder. This is not a fault but rather an effect of the design/architecture.

  • Page 26: Trouble-Shooting

    11 Trouble-shooting Trouble-shooting This section lists faults that can be solved simply by following the instructions given. If the fault cannot be remedied, please contact Customer Services. Before contacting Cus- tomer Services: ▸ please note down ▪ the serial number (SN), which is shown on the identification plate), ▪...
  • Page 27 11 Trouble-shooting Malfunction Possible cause Solution/Measures Illumination is flash- ▪ Appliance door is left open ▸ Close the appliance door. ing and an acoustic for longer than 5 minutes. – If the alarm is still being emit- signal is emitted. ▪...
  • Page 28 11 Trouble-shooting Malfunction Possible cause Solution/Measures Error message F_ _ ▪ Various situations can lead ▸ Contact Customer Services. to an F message. Malfunction Possible cause Solution/Measures The temperature and ▪ The refrigerator compart- ▸ Touch any button. refrigerating zone(s) ment temperature is 10 °C –...

  • Page 29: Tips And Tricks

    ▪ Store food that releases moisture in closed containers or covered in the refrigerator compartment. Moisture reduces the cooling capacity. ▪ For ideal air circulation: Do not store food and food items too close to each other. ▪ Turn the SilentPlus and V-ZUG-Home functions off when not in use.
  • Page 30 ▸ See identification plate Spare parts V-ZUG Ltd provides spare parts for 15 years after the making available on the market of the last appliance with this type designation. Deviations from this are subject to consider- ation of and compliance with the applicable ecodesign regulations on the availability of spare parts.
  • Page 31 14 Disposal Disposal 14.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 14.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
  • Page 32 6 Scotts Road Gridiron Building Scotts Square #03-11/12/13 N1C 4G London 228209 Singapore GREAT BRITAIN SINGAPORE HK/MO V-ZUG Hong Kong Co. Ltd. GÜRELLER 12/F, 8 Russell Street Anchor Sit.3A/1-2 Çayyolu Causeway Bay 06690 ÇANKAYA/ANKARA HONG KONG TURKEY Frigo 2000 S.p.A Private enterprise "Stirion"...
  • Page 33 Index Addresses of the importers ......32 Holiday function......... 15, 20 Appliance Disposal............ 31 Switching off .......... 11 Identification plate......... 8, 30, 35 Switching on .......... 10 Increased cooling capacity ......15 Appliance functions ......... 12 Initial set-up ............. 5, 8 Selecting............
  • Page 34 Trouble-shooting ..........26 Type............... 2 User setting............13 Using for the first time........5, 8 Validity..............2 Vegetable drawer..........24 V-ZUG App ............21 V-ZUG-Home........16, 20, 21 Warnings............25 Warranty claim..........30 Warranty extensions ........35 WLAN connection ..........21...
  • Page 35 V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive service agreements.
  • Page 36 MonoFridge Display brightness SilentPlus Switch off button tone PartyCooling V-ZUG-Home Holiday function Temperature unit Sabbath mode Value and status display Refrigerating/Freezing zone 10182918 Freezing zone active Fast cooling/fast freezing active 1109547-02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug info@vzug.com, www.vzug.com...
