- Page 1 Operating instructions CombiCooler V4000 | V400 Refrigerator/freezer...
- Page 2 These operating instructions apply to: Model designation Type Size system CombiCooler V4000 CCO4T-51086 SMS 55 / Euro 60 CCOI178NBH6 CombiCooler V400 CCO4H-51101 SMS 55 / Euro 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2019...
- Page 3 Basic procedure .......... 10 Switching the appliance on ....... 10 Setting the temperature ........ 10 Switching the appliance off........ 11 Using the appliance functions 12 Brief description of the appliance functions... 17 V-ZUG-Home 19 Conditions ............. 19 Initial set-up............ 19 Glass shelves and door trays 20 Tips and tricks 20...
- Page 4 Safety precautions Symbols used Denotes important safety precau- ▪ This appliance can be used tions. Failure to observe said precautions by children aged 8 and above can result in injury or in damage to and by persons with reduced the appliance or fittings! physical, sensory or mental Information and precautions that capabilities, or lack of experi-...
- Page 5 1 Safety precautions ▪ Refer to the identification plate for in- turer or its Customer Services formation on the required mains or a similarly qualified person voltage, current type and fuse protec- in order to avoid hazard. tion. ▪ All plastering, plasterboarding, wall pa- Appliance-specific safety pering or painting work is to be carried precautions...
- Page 6 1 Safety precautions ▪ WARNING: Do not locate multiple port- the appliance and fittings, as well as af- able socket-outlets or portable power fect the functioning of the appliance. If supplies at the rear of the appliance. the appliance is not working properly or ▪...
- Page 7 1 Safety precautions ▪ Avoid prolonged skin contact with frozen food. Never consume frozen food or ice cubes that are straight out of the freezer compartment or too cold. Risk of burns from freezing! ▪ Do not remove the evaporation tray on the compressor.
- Page 8 Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective film from the in- terior. ▸ Clean the interior and accessories with lukewarm water or a mild soapy solution (wa- ter and washing-up liquid) and dry thoroughly.
- Page 9 ON/OFF (hold depressed for 3 seconds) Display elements: Operating User setting mode MonoFridge Display brightness SilentPlus Switch off button tone PartyCooling V-ZUG-Home Holiday function Temperature unit Sabbath mode Value and status display Refrigerating/Freezing zone Freezing zone active Fast cooling/fast freezing...
- Page 10 4 Operation Operation Basic procedure ▪ Use the navigation arrows (up/left) and (down/right) to select a settable value and to navigate through the operating steps. ▪ The selected set values are displayed for 5 seconds when the door is opened, and then the actual temperature values are displayed.
- Page 11 4 Operation Procedure ▸ Touch the button. – The temperature display for the refrigerator compartment flashes on the left-hand side of the display. ▸ Touch the button and select the desired temperature for the refrigerator compartment. ▸ Confirm with the button to accept the entry.
- Page 12 5 Using the appliance functions Using the appliance functions Function Description Temperature set- Temperature selection for the zones. ting According to section: Operation, Setting the tem- perature (see page 10). Timer Acoustic alarm emitted after the selected duration (from 0 hours 00 minutes to 9 hours 55 minutes) is up.
- Page 13 5 Using the appliance functions Function Description Setting Accessing the functions and user settings For more information: Brief description of the appliance functions (see page 17). Selecting ▸ Touch the button. ▸ Select the desired function or user setting (flashing) using ▸...
- Page 14 5 Using the appliance functions Function Description SilentPlus Noise-reduced operation Activating ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button. ▸ Adjust the temperature selected for the freezer compartment using the buttons if ne- cessary.
- Page 15 5 Using the appliance functions Function Description Holiday function Reduced cooling capacity for the refrigerator compartment (14 °C). The freezer compartment remains at the set temperature value. Activating ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button.
- Page 16 5 Using the appliance functions Function Description V-ZUG-Home Interaction with the appliance via the app (see page 19). Activating ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button and select «On» in the display using ▸...
- Page 17 5 Using the appliance functions Function Description Temperature unit Switching between the unit of temperature. °C / °F ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button. Demo mode* This setting enables specialist retailers to put the appliance into the showroom mode for demonstration purposes.
- Page 18 5 Using the appliance functions SilentPlus This operating mode is designed to produce low noise emissions. Energy efficiency may be slightly reduced. Since the appliance is quiet during normal operation, the effect of Si- lentPlus is particularly perceptible at higher ambient temperatures. In addition, the appli- ance reacts to the door being frequently opened or warm food being stored in a particu- larly noise-optimized way in the SilentPlus mode compared to normal operation.
- Page 19 Check the quality of the food. Do not eat food that has thawed! Risk of food poisoning. V-ZUG-Home With V-ZUG-Home, you can access your appliances over the V-ZUG App to, for instance: ▪ query the appliance status ▪ receive push notifications ▪...
- Page 20 – A bluetooth pairing request appears in the V-ZUG App. – A 6-digit PIN appears in the display of the appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – All available wireless networks appear in the V-ZUG App.
- Page 21 8 Tips and tricks ▪ Placing very warm or very cold items (e.g. warm, bottled sauces or frozen food for de- frosting) directly in front of a temperature sensor (integrated in the LED light strip in the refrigerator compartment and in the LED cover in the freezer compartment) can af- fect the temperature regulation of the appliance adversely: it may cool too little or too much.
- Page 22 ▪ Store food that releases moisture in closed containers or covered in the refrigerator compartment. Moisture reduces the cooling capacity. ▪ For ideal air circulation: Do not store food and food items too close to each other. ▪ Turn the SilentPlus and V-ZUG-Home functions off when not in use. Care and maintenance Cleaning For the hygienic storage of food, the interior should always be kept clean.
- Page 23 10 Noises and warnings ▸ Condensation can form in the vegetable drawer and on the glass shelves, depending on the kind and quantity of food being stored. Regularly wipe away any condensation with a dry cloth. ▸ Clean the interior at regular intervals with a mild soapy solution and wipe dry thor- oughly.
- Page 24 11 Trouble-shooting 10.2 Warnings Warnings when the appliance doors are open If the refrigerator or freezer compartment door remains open for a time, the following warning is given: After 3 minutes The LEDs flash with the intensity of the brightness gradually increas- ing and decreasing.
- Page 25 11 Trouble-shooting Malfunction Possible cause Solution/Measures Illumination is not ▪ Sabbath mode is active. ▸ Hold the button depressed working. for 3 seconds. ▪ If the illumination turns on: The problem is remedied. ▪ If the appliance switches off («OF» in the display): ▸...
- Page 26 11 Trouble-shooting Malfunction Possible cause Solution/Measures Error messages ▪ Temperature sensor is de- ▸ Contact Customer Services. F10–F15 fective. – The appliance switches to the emergency mode. The con- tents are kept refrigerated, but the appliance cannot record the current temperature value. Malfunction Possible cause Solution/Measure...
- Page 27 12 Technical data Malfunction Possible cause Solution/Measures The temperature and ▪ The refrigerator compart- ▸ Touch any button. refrigerating zone(s) ment temperature is 10 °C – The current temperature value flash and/or an higher than the set temper- is displayed; flashes until acoustic signal is ature or the freezer com- the set temperature is reached.
- Page 28 13 Disposal Disposal 13.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 13.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
- Page 29 Index Appliance disposal .......... 28 Model designation ..........2 Appliance functions ......... 12 Model number ............. 2 Appliance installation ......... 5 MonoFridge............13 Button tone on/off..........16 Noise-reduced operation........ 14 Noises ..............23 Care and maintenance ........22 Cleaning............. 22 ON/OFF ............
- Page 30 Using for the first time........5, 8 Validity..............2 V-ZUG App ............19 V-ZUG-Home..........16, 19 Warnings............24 WLAN connection ..........19...
- Page 31 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
- Page 32 Value and status display Refrigerating/Freezing zone Freezing zone active Fast cooling/fast freezing active 1061561-R03 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
