Multay Louvre Bed SB01 Assembly Instruction

Step By Step Assembly Instructions

PRE-ASSEMBLY PREPARATION

1.Please check the pack contents before attempting to assemble this product.

A full checklist of components is given in this leaflet. If any components are missing, please contact

the retailer from whom you bought this product.

2.This product is Heavy, it should be assembled as near as possible to the point of use.

TAKE CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.

3.This product takes approximately 45 minutes to assemble with 2 people.

4.This product already contains fitting which should be :

" KEPT AWAY FROM YOUNG CHILDREN "

5.Read this leaflet in full before commencing assembly.

Louvre Bed

( SB01 )

Assembly Instruction

Page 1

Table of Contents

Do you have a question about the Louvre Bed SB01 and is the answer not in the manual?

Page 1 Louvre Bed ( SB01 ) Assembly Instruction Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1.Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact the retailer from whom you bought this product.
Page 2 Louvre Bed ( SB01 ) Assembly Instruction (D) Slats (A) Headboard ( C ) Side Rail (E) Slats Support (B) Footboard ( C ) Side Rail HARDWARE IDENTIFICATION ITEM DESCRIPTION Q ty HEADBOARD FOOTBOARD SIDE RAILS SLATS ( Assembled ) SLATS SUPPORT BOLT CONNECTING RAIL(Embedded in side rail) Page 2...
Page 3 Louvre Bed ( SB01 ) Assembly Instruction 1. HEADBOARD AND SIDE RAIL ASSEMBLY # Step 1 1. “Left / Right” marked on headboard must be matched with “Left/Right” marked on each side rail. Note : - It’s required one person to hold (A) Headboard the headboard while the other attaches the side rail.
Page 4 Louvre Bed ( SB01 ) Assembly Instruction 2. FOOTBOARD AND SIDE RAIL ASSEMBLY # Step 2 1. “Left / Right” marked on footboard must be matched with “Left/Right” marked on each side rail. (B) Footboard ( C ) Side Rail 2.
