JEMMA 3'
Assembly Instructions
1000mm
Do not throw away any of the packing or the instruction book until you have checked all the
components and fittings and the furniture is fully assembled.
In the unlikely event that this product has missing or damaged parts, please call 0870 3333 612 to
obtain spares.
2020mm
Page 1 of 6
Date: 27-03-2008
982mm
Jemma 3'
Advertisement
Table of Contents
Related Manuals for DREAMS JEMMA 3
Summary of Contents for DREAMS JEMMA 3
- Page 1 JEMMA 3' Assembly Instructions Date: 27-03-2008 1000mm 2020mm 982mm Do not throw away any of the packing or the instruction book until you have checked all the components and fittings and the furniture is fully assembled. In the unlikely event that this product has missing or damaged parts, please call 0870 3333 612 to obtain spares.
- Page 2 Hazard Warning ! Keep small components out of the reach of children. Parts Footboard Headboard 1 pc. 1 pc. 219 / 0072 219 / 0071 Siderail 2 pcs. 108 / 0088 1900 x 115mm Page 2 of 6 Jemma 3'...
- Page 3 Key diagram and tools needed. Key diagram. Tools needed. Page 3 of 6 Jemma 3'...
- Page 4 "1" using bolts "A" as shown. Tighten the bolts using the allen key "B". Fix the footboard "2" to the Step 2 siderail using bolts "A" as shown. Tighten the bolts using the allen key "B". Page 4 of 6 Jemma 3'...
- Page 5 Assembly DREAMS SPRUNG SLAT Step 3 SYSTEM Open the metal Slat Frame outwards. Turn the metal Slat Frame falling upward and carefully lower the Slat frame into the bed. Ensure that the frame sits on the guides located on the Side Rails "3".
- Page 6 Any flexing that has occurred during transport will re-correct it self once this product is correctly assembled. Tighten all joins of furniture after six months. Please keep these instructions in a safe place for future use. Page 6 of 6 Jemma 3'...
