Vents FB K2 UV User Manual

Bactericidal filter box with uv lamp for round air ducts
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S MANUAL
FB K2 UV
Bactericidal filter box with UV lamp for round air ducts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FB K2 UV and is the answer not in the manual?

Questions and answers

Related Manuals for Vents FB K2 UV

Summary of Contents for Vents FB K2 UV

  • Page 1 USER'S MANUAL FB K2 UV Bactericidal filter box with UV lamp for round air ducts...

  • Page 2: Table Of Contents

    Warranty card ....................................15 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the FB K2 UV unit and all its modifications.
  • Page 3 Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it. The information in this user’s manual was correct at the time of the document’s preparation.

  • Page 4: Purpose

    FB K2 UV PURPOSE The unit is a device with bactericidal ultraviolet lamps for quality cleaning and disinfection of air circulating in ventilation systems. The unit is a component part and is not designed for stand-alone operation. It is used for disinfecting the air in rooms with increased risk of spread of infectious agents: in medical, pre-school, school, industrial and public organisations, public catering and other premises with large concentrations of people.

  • Page 5: Technical Data

    TECHNICAL DATA The unit is designed for operation in an enclosed area at ambient temperatures from -25 ˚C to + +55 ˚C at relative humidity of up to 80 % (at +25 ˚C). The unit is rated as a Class I electrical appliance. Ingress protection rating against access to hazardous parts and water ingress is IPХ4.
  • Page 6 FB K2 UV Overall dimensions of the unit [mm] Weight Model [kg] 12.4 FB K2 150 G4/F7 UV 13.3 FB K2 150 G4/C/F7 UV 12.4 FB K2 150 G4/H11 UV 13.3 FB K2 150 G4/C/H11 UV 12.4 FB K2 150 G4/F8 UV 513.5...

  • Page 7: Design And Operating Principle

    DESIGN AND OPERATING PRINCIPLE The unit is a box with a UV lamp installed to clean the air from viruses and bacteria. For additional filtration, the unit includes up to three filters (optional) with different intake air filtration classes (from coarse to fine). The flow of non-disinfected air enters through the casing through the ventilation holes, the UV lamp disinfects the air in its enclosed space, and the disinfected air enters the room.

  • Page 8: Connection To Power Mains

    FB K2 UV CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.

  • Page 9: Technical Data

    TECHNICAL DATA DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION Maintenance operations of the unit are required 3-4 times per year. Technical maintenance includes regular cleaning of the unit and periodic cleaning of filters and UV lamps.

  • Page 10: Troubleshooting

    FB K2 UV TROUBLESHOOTING PROBLEM POSSIBLE REASONS TROUBLESHOOTING Make sure the power supply line is connected correctly, No power supply. otherwise troubleshoot a connection error. The plug or cable is damaged. Contact the Seller. When turned on, the UV lamp does not light up.

  • Page 11: Manufacturer's Warranty

    MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 12 FB K2 UV Log of operating hours for bactericidal lamps www.ventilation-system.com...
  • Page 13 www.ventilation-system.com...
  • Page 14 FB K2 UV www.ventilation-system.com...

  • Page 15: Certificate Of Acceptance

    CERTIFICATE OF ACCEPTANCE Unit Type Bactericidal filter box with UV lamp for round air ducts Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 16 V185-1EN-01...
