1. Getting Acquainted
The HPT401BT is a rugged and very powerful external radio transceiver 5.75 x 2.95 x 1.73 inches (146 x
75 x 44 mm),
weighs 1.3 lbs (0.
(79 x 151 x 73 mm), and it weights 2.2 lbs (1 kg).

1.1. LEDs

External LED's are used for Link and Line status indication:
LED
Position
Name
1 PWR Green
2 RX Green
3 TX Green
4 BT Blue

1.2. Data and Power Port

The HPT401BT data and power port is placed on the front of the unit (Figure 2).
Through the DB15 port the HPT401BT can be connected to PC with Accessory Data-Ser-Pwr Cable,
DB9/DB15/SAE (6ft/1.8m) p/n 14-578108-02 and can be powered.
10
488 kg); HPT401BT with battery dimensions are 3.11 x 5.94 x 2.87 inches
Color
Solid - external power is connected, battery charger is off.
Blinking every 1 second - external power is connected, the battery is being charged
Blinking every 4 seconds - external power is not connected, internal battery is being used
as power source
Blinking every 0.5 second - external power is not connected, the battery is near to full
discharge
OFF - external power is not connected
ON - radio receives data
ON - radio transmits data
OFF - Bluetooth® is OFF;
Solid blue - Bluetooth® is ON;
Blinking if radio receives or transmits data over Bluetooth®
Figure 2. HPT401BT front side
Description
Data and
power port
On/Off button
