o Example: 10.10.10.0/24

Network Diagram

This example uses an external ADSL Modem for Internet Access. The ADSL Modem is
set for "Bridge Mode"; please consult the ADSL Modem's documentation or your service
provider for information explaining ADSL bridge mode. The ADSL Modem's private
Ethernet interface is connected to the NetVanta 2054's Public Interface. The NetVanta's
first switch port (Eth 0/2) is connected to a computer that will be used for configuration.
The following settings will be used for this example. You should evaluate your own
needs, and apply your own settings as necessary.
Option
Public IP Address (Mask)
Private IP Address (Mask)
Public Interface Mode

Configuring via the Web Interface

The NetVanta 2054 has a Web Interface that can be used to complete Internet Access
configuration. The NetVanta 2054's factory default configuration has an IP Address of
10.10.10.1 applied to its Private interface. You can connect a computer with an IP
Address of 10.10.10.2 to any of four switch ports. To access the Web Interface, connect a
computer with an IP Address of 10.10.10.2 to any of the four switch ports, and enter the
following URL in the address bar of a web browser.
Web Interface Access URL:
Username: admin
Password: password

Resetting the NetVanta 2054:

If you are unable to connect to the Web Interface using the instructions above, the
NetVanta can be reset to its factory default configuration. To reset the NetVanta follow
these instructions:
1) Power on the NetVanta 2054 and let sit for 60 seconds
2) Using a Ball Point Pin, press the reset button
a. Located between the Eth 0/1 and Console Port
3) Hold the button for exactly 45 seconds
4) After 45 seconds the unit should reboot
a. Indicated by flashing all lights on the front of the unit
5) Release the button immediately after reboot
Setting
5.5.5.5 (255.255.255.252)
10.10.10.1 (255.255.255.0)
PPPoE
http://10.10.10.1
Note
Your ISP Will Assign
Your LAN Network
Example for ADSL
