Iceland Single Bed
Assembly Instructions
Dimensions
Width - 101cm
Length - 203cm
Height - 112cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 077 8888
- Please keep for future reference
279721
279723
279724
Issue 1 - 06/06/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Iceland 279721
Summary of Contents for Argos Iceland 279721
- Page 1 Iceland Single Bed Assembly Instructions 279721 - Please keep for future reference 279723 279724 Dimensions Width - 101cm Length - 203cm Height - 112cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Homebase = 0345 077 8888 Issue 1 - 06/06/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce the components and tools listed on or put weight on the product, this likelihood of the following pages.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: Homebase = 0345 077 8888 Please check you have all the parts listed below 1 Headboard 2 Footboard (101 x 112 x 8cm) (101 x 94 x 8cm) 3 Side rail A x 2 4 Side rail B x 2 (95.5 x 12 x 5cm) - Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. M8 x 20mm Bolt x 8 M6 x 16mm Bolt x 16 Allen key x 2 Ruler - Use this ruler to help correctly identify the screws...
- Page 5 Assembly Instructions Step 1 Assembling side rails Insert the side rail connector into the side rail A as shown. Align holes and fix using bolts Then insert the side rail B into the side rail connector as shown. Align holes and fix using bolts Note: Fasten bolts using allen...
- Page 6 Assembly Instructions Step 3 Assembling round centre legs Position the round centre legs on the centre rail as shown. Align holes and fix using bolts fully tighten with allen Step 4 Attaching headboard With the help of an assistant, position the assembled side rails &...
- Page 7 Assembly Instructions Step 5 Attaching footboard With the help of an assistant, position the assembled side rails & and headboard as shown. Align holes and fix using bolts Note: Fasten bolts using allen but do not fully tighten at this stage.
- Page 8 Assembly Instructions Step 7 Adjusting legs Ensure the legs are in contact with the ground. Turn adjustable footings on the 2 centre legs to adjust the height. adjustable footing Note: Fully tighten all bolts fixed in previous steps using allen Assembly is complete.
