- Page 3 Product Features C-Clamp Mounting Grommet Mounting...
- Page 4 TENSION ADJUSTMENT SHOULD BE DONE ONLY AFTER MOUNT INSTALLATION Do not adjust tension without monitor. 1. Ensure monitor has been attached to the mount. 3. Ensure the net weight of monitor (including accessories) is between 2.2~26.4 Ibs (1-12 kg). Adjustment Sign Clockwise to reduce Counter-clockwise to increase tension(carry less weight)
- Page 5 Tools Needed (Not lncluded) Wood Drill Phillips Screwdriver Drill 10-15mm (25/64 in.-19/32 in.) Supplied Parts and Hardware Warning:This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. Do not use damaged or defective parts.
-
Page 6: Install The Base
1. Install the Base A. For Clamp Mounting Warning: Ensure bolts are (Medium Allen Key) (Medium Allen Key) 15/64 in.(6mm) - Page 7 N (Large Allen Key) B. For Grommet Mounting Warning: Ensure bolts are (Medium Allen Key) N (Large Allen Key) N (Large Allen Key)
- Page 8 2. Install the Arms and Arm Extensions to Base ±135° ±135° ±135° ±135° L (Small Allen Key) L (Small Allen Key) L (Small Allen Key)
- Page 9 3. Attach Monitors to the Arms For Monitor with Flat Back Phillips Screwdriver [not included] For Monitor with Curved or Recessed Back Note: If needed, pull the lock HEAVY! You may need plate back and lift the TV to assistance with this step. seperate the TV from the arm.
- Page 10 4. Adjust Gas Spring Tension 1. If the monitor can stay at the desired height by itself, no adjustment needed. 2. If the monitor rises up, press the arm to keep it in horizontal position and then use the Large Allen Key (N) to turn the bolt clockwise(“-”...
-
Page 11: Tilt Adjustment
5. Tilt Adjustment 1. Slightly loosen two preassembled bolts [T]. 2. Adjust TV to your desired tilt angle. N (Large Allen Key) 3. Retighten both bolts [T] to secure the TV in place. 6. Rotation Adjustment 180° Rotation This function works better for monitors with the center of gravity. - Page 12 7. Route Cables along the Arms Phillips Screwdriver [not included]...
