- Page 1 Installation instruction VAV duct pressure control kit...
-
Page 2: Table Of Contents
Table of content 1 Introduction ............1 Product description ........1 Intended use ..........1 Document description........1 Product overview......... 1 2 Product liability ............1 3 Safety ..............1 Safety definitions ......... 1 Safety instructions ........2 Personal protective equipment ....... 2 4 Installation............ -
Page 3: Introduction
Tubes Pressure measuring taps Product liability Safety Systemair is not liable for damages that the product causes Safety definitions in these conditions: Warnings, cautions and notes are used to point out specially • The product is incorrectly installed, operated or important parts of the manual. -
Page 4: Safety Instructions
Safety instructions Installation To do before the installation Warning of the product Read the warning instructions that follow before you do work on the product. • Examine the packaging for transportation damage and re- move the packaging from the product carefully. •... -
Page 5: Description Of The Pressure Transmitter
Connect the other end of the tubes to the differential DIP-switches pressure transmitter’s inlet ports. Push button C. Status LED Caution D. Sensor 1 Be careful when connecting the hoses to the inlet ports, the thin inner connections Terminals of the inlets are very sensitive. The lid should be kept closed while performing the connections, or the thin tubing might 4.3.1... -
Page 6: Technical Data
Technical data Wiring diagrams Abbreviation in wiring diagram Cable colour Yellow White Green Brown Pressure transmitter extract air Pressure transmitter supply air T15, T16 Terminals in Topvex SR, TR, SC, TC control unit G0, G, 42, 40 Terminals in Topvex FR, FC, SF control unit Topvex SR/TR, SC/TC 1 2 3 4 1 2 3 4... -
Page 7: Topvex Fr, Fc, Sf
Topvex FR, FC, SF 1 2 3 4 1 2 3 4 To configure the pressure transmitter in the air handling unit controller For SR/TR, SC/TC, FC, FR 6.1.1 To log in 1. Open the log in window 2. Select service from drop down list 3. -
Page 8: To Start The Configuration Wizard
6.1.2 To start the configuration wizard A configuration wizard is available from software version 4.1. By using the wizard, the following steps in 6.1.3 To activate the pressure control function 6.1.4 To allocate differential pres- sure sensors can be omitted. Configuration >... -
Page 9: To Adjust The Fan Pressure Set Points
Topvex SR, TR, SC, TC Pressure supply air Controller Pressure extract air Topvex FR, FC Pressure supply air Controller Pressure extract air Configuration > Analog inputs > Pressure supply air 2022-08-29 Sensor value at V Sensor value at V 500.0 Select Configuration from the navigation icons Select I/O allocation settings Select Analog inputs... -
Page 10: For Sf Units
Save commissioning settings Select Configuration from the navigation icons Select System settings Select Save and restore Select Yes on Save commissioning settings. For SF units 6.2.1 To log in Log in to Administrator level with password 3333. Menu level 1 Menu level 2 Menu level 3 Temperature... -
Page 11: To Set Alarm Limit
Menu level 1 Menu level 2 Menu level 3 Running mode Pressure ctrl SAF Pressure ctrl SAF Temperature Actual: 0 Pa Setp 1/1: 200 Pa → Air control Setp: 0 Pa → Setp 1/2: 100 Pa Time settings ↓ ← Pressure ctrl EAF Pressure ctrl EAF Actual: 0 Pa... - Page 12 © Copyright Systemair AB All rights reserved Systemair AB reserves the rights to alter their products without notice. This also applies to products already ordered, as long as it does not affect the previously agreed specifications. Document in original language...
