Summary of Contents for SystemAir TControl POD glass EC
- Page 1 Installation and maintenance manual TControl POD glass EC Controller for Fan Coil Units...
- Page 3 INSTALLATION INSTRUCTION English NOTICE D’INSTALLATION Français INSTALLATIONSHANDBUCH Deutsch ISTRUZIONI INSTALLAZIONE Italiano INSTRUCCIONES DE INSTALACIÓN Español...
-
Page 4: Table Of Contents
2 TControl POD glass EC CONTENTS 1. DEVICE PRESENTATION ..................................3 2. TECHNICAL DATA ....................................3 3. CONNECTION DIAGRAM ................................... 3 4. DIMENSIONS ....................................4 5. GENERAL ......................................5 5.1. DESCRIPTION..............................................5 5.2. PHYSICAL INSTALLATION RS-485 ........................................ 5 5.3. RS-485 TRANSMISSION ..........................................5 5.4. -
Page 5: Device Presentation
TControl POD glass EC 1. DEVICE PRESENTATION Controller type TControl POD glass EC (EC Fan, 0-10 V, 230 V) 2. TECHNICAL DATA Measured value Temperature Modbus RS485; Transmission speed: 9600, 19200, 38400 or 57600; Parity: no parity (2 stop bits), even or... -
Page 6: Dimensions
The POD connection box is screwed into the upper part of the box with the 4 screws provided (M3x8) (Figure 3). Wire in accordance with the wiring diagram. Place the TControl POD glass EC on the top of the unit and attach it to the rear of the unit (by clipping it on). Figure 1... -
Page 7: General
This constraint is only due to a current reading ability of the material. 5.4. PROTOCOL The TControl POD glass EC is a “Slave” participant in the network. It only responds to the requests of the “Master”. The protocol corresponds to the default values specified in the Modbus tables (Refer to the §... -
Page 8: Display
6 TControl POD glass EC 6. DISPLAY 6.1. MAIN DISPLAY The main screen is divided into 3 areas: header, central value and footer. 00:20 Th 07.01.16 Header 22.3°C Central value Footer AUTO 6.2. HEADER The header shows the time, day and date. In addition, an information symbol is available on request or for certain states/modes. -
Page 9: Fan Speed Adjustment
TControl POD glass EC 6.3.2. FAN SPEED ADJUSTMENT Parameter menu access Fan speed adjustment After activating one of the 2 buttons, the value on the screen changes to the fan speed adjustment window. Pressing one of the buttons again adapts the fan speed. -
Page 10: Parameter Menu
8 TControl POD glass EC 7.1. PARAMETER MENU 7.1.1. PARAMETER MENU ACCESS Press the 3 buttons shown below simultaneously for about 5 seconds to access this menu. The button combination can be locked by the “button access menu” parameter (Refer to the § MODBUS TABLES, page 22 - address 124), so that a user will not be able to change the parameters afterwards. -
Page 11: Navigation
TControl POD glass EC 7.1.3. NAVIGATION Navigation is performed using the UP, DOWN, LEFT, RIGHT and ENTER buttons. The menus are structured hierarchically. The highest level is the main menu. From this menu, the user can navigate through different submenus. From there, access to other submenus is made possible. To return to the previous level, “header”... -
Page 12: Hourly Programming Menu
10 TControl POD glass EC 7.2. HOURLY PROGRAMMING MENU The description of the various sub-menus is detailed in the following paragraphs. MENU MENU Time slot Time slot Time/Date Time/Date Alarm Alarm Configuration Configuration Language Language General view of the parameter menu “Time slot selection”... -
Page 13: Date And Time
TControl POD glass EC 7.2.1.2. TIME SLOT MENU Time slot selection Day selection TIME SLOT TIME SLOT/TIMER 1 Time slot 1 Week Mo-Su Time slot 2 Working week Mo-Fr Time slot 3 From day To day Periods Overview/Selecting the time slot period... -
Page 14: Alarm Mode
12 TControl POD glass EC 7.4. ALARM MODE 7.4.1. OVERVIEW Alarm MENU Time slot Tolerance 1.0°C Time/Date Period 30 mm Alarm Alarm triggering Alarm reset Configuration Language At the top of the main screen, a fault symbol will appear if the “over threshold” alarm is validated. This symbol is located in the same place as the ECO symbol. -
Page 15: Fan Menu
Assignment concerns the 2-pipe configuration: ² C/F: heating and cooling mode that allows use of an external heating source controlled by the TControl POD glass EC. Cold: cooling alone. Heat: heating alone. Lev. Start: Sets the start level after power off. -
Page 16: Configuration Menu
Example: for a minimum value of 30%, you must enter +30 - 32 768 in register 111, i.e. -32 738. Information As standard, the TControl POD glass EC is configured for cyclic ventilation. Configuration via the display is only done by setting the minimum speed value. The TControl POD glass EC automatically integrates the correction. 7.6. CONFIGURATION MENU... -
Page 17: Language Menu
TControl POD glass EC 7.7. LANGUAGE MENU You can change the language by clicking on “Language” in the language menu. Three languages are available: German ² English ² French. ² English is set by default. MENU SELECT THE LANGUAGE Time slot... -
Page 18: Operating Mode
16 TControl POD glass EC 10. OPERATING MODE 10.1. STAND-BY Activated by Modbus or a button. In stand-by mode, the controller is not active and the display is off. The buttons, except the ENTER button, are locked. The building protection systems remain functional. -
Page 19: Configuration
TControl POD glass EC 11. CONFIGURATION 11.1. TEMPERATURE By default, the value of the built-in sensor is used. A universal input can be configured as an input for a temperature sensor. In this case, the value of this sensor will be used as a reference sensor and will replace the value of the internal sensor on the main screen. -
Page 20: Change-Over
18 TControl POD glass EC 11.2.1. CHANGE-OVER The Change-Over function can be performed by the installer by using: a sensor ² that must be connected to universal input 1 a contactor ² connected to either universal input 1 or input 2... -
Page 21: Dew Point
TControl POD glass EC 11.2.4. DEW POINT The dew point contact can be connected at the installer’s choice to: universal input 1 ² input 2 ² The dew point function is activated via the configuration of a digital input (address 18 or 19) or via Modbus (address 258). -
Page 22: Setpoint
20 TControl POD glass EC 12. SETPOINT 12.1. GENERAL The active setpoint is determined by the time slot configuration. If no time slot is configured, the “setpoint after power-up” parameter is used as a reference. The user can change the values within the defined limits. -
Page 23: Modbus Parameter Menu
TControl POD glass EC 14. MODBUS PARAMETER MENU The Modbus parameters menu is accessed by simultaneously pressing the buttons shown below for about 3 seconds. The combination must be made from the main screen. The LED in the center ring lights up when the combination is detected. -
Page 24: Modbus Tables
22 TControl POD glass EC 15. MODBUS TABLES Registers marked with a are stored in the EEPROM. They may only be written during device configuration, not during operation! Modbus Holding Register (R/W) Address-H Min. Max. Gain Name Description EEPROM 0: German... - Page 25 TControl POD glass EC Modbus Holding Register (R/W) 0-100 ≙ 0.0 - 10.0°C Address-H Min. Max. Gain Name Description EEPROM 0-150 ≙ 0.0 - 15.0°C Setpoint range Factory setting: 0.5°C 0-150 ≙ 0.0 - 15.0°C Comfort dead band Factory setting: 2.0°C 0-150 ≙...
- Page 26 24 TControl POD glass EC Modbus Holding Register (R/W) Address-H Min. Max. Gain Name Description EEPROM Time slot 2 setpoint period 4 (#) Time slot 2 period 4 Time slot 2 AC fan period 4 (#) Time slot 2 period 4...
- Page 27 TControl POD glass EC Modbus Holding Register (R/W) Address-H Min. Max. Gain Name Description EEPROM 0: with AUTOMATIC (Factory setting) Fan stage button with/without AUTO 1: without AUTOMATIC 0: Keep the value (Factory setting) Setpoint offset at change of in-use...
- Page 28 26 TControl POD glass EC Modbus Input Register (R) 0-500 ≙ 0-50.0°C Address-I Min. Max. Gain Name Description 0-500 ≙ 0-50.0°C Heat setpoint Example: 21.5°C = 215 0-150 ≙ 0-15.0°C Cold setpoint Example: 21.5°C = 215 0-500 ≙ 0-50.0°C Setpoint offset Example: 3.0°C = 30...
- Page 30 As part of our ongoing product improvement programme, our products are subject to change without prior notice. Non contractual photos. Systemair AC SAS Route de Verneuil 27570 Tillières-sur-Avre FRANCE & : +33 (0)2 32 60 61 00 6 : +33 (0)2 32 32 55 13...
