Installation
(a)
Dimensions
Furnace Size/
Casing 9
MBH
Length
Height
90-130 Ton
1000
267-3/16"
10-11/32"
(a) The length dimension is from the exhaust end of the unit. The height dimension
is from the bottom of the unit base rail.
Figure 9.
W_HE casing 9 (90-130 ton)
24
RT-SVX35H-EN
